Introduction
Introduction
Overview
This product is a 4x1 USB-C & HDMI KVM Switcher. It supports sharing
among 4 different computers using a set of KVM devices. It supports one
USB-C input and three HDMI 2.0+USB 3.0 inputs. The USB-C port provides
full-featured support, including data, video, and charging functions, and can
provide up to 60W of charging power to the connected laptop.
The device provides a variety of peripheral interfaces to meet the needs of
the work and home office. It supports one HDMI 2.0 video output, two USB
3.0 and one USB 2.0 data port, one USB 1.1 hotkey dedicated port, one Mic,
and one headphone port.
It also provides a variety of manual control functions, including button
control, IR remote control, and hotkey control.
It provides a wide compatible choice for different operating systems, such
as Windows, Mac OS, and Linux, no driver required, and simple
plug-and-play.
Features
4x1 USB-C & HDMI + USB 3.0 KVM Switch.
One full-featured USB-C input supports 4K@60Hz video transmission,
USB 3.0 data, and 60W charging.
All HDMI inputs and output support resolutions up to 4K@60Hz 4:4:4
8bit, HDR 10, Dolby Vision, and HDCP 2.2 compatibility.
Supports high refresh rates such as 240Hz, 165Hz, and 144Hz.
Support 1080P@240Hz/165Hz/144Hz/120Hz/60Hz,
2560x1440@144Hz/120Hz/60Hz, 4K@60Hz and other resolutions.
Support EDID simulation function, the average switching time is about
2s.
Support automatic wake-up function, which automatically wakes up the
standby computer when switching.
HDMI output supports automatic CEC power on/off the connected
display.
Supports multiple peripheral ports, including:
Two USB 3.0 type-A ports, supports maximum 5Gbps data rate, and
maximum 5V/1A power output;
One USB 2.0 type-A port, supports maximum 480Mbps data rate,
and maximum 5V/0.5A power output;
One USB 1.1 type-A port, is used to be connected to a USB
