BizEye 50

1080P Ultra-Wide-Angle USB Camera

User Manual

Introduction

www.avaccess.com 2 info@avaccess.com

Introduction

Overview

This product is a 1080P ultra-wide-angle USB webcam. It supports auto

color-correction and white balance which makes the light always look

great in the stream. Its built-in auto noise reducing mic can pick up

realistic sound from multiple angles within the distance of 3m and make

the sound clear.

It is fully compatible with most operating systems like Windows 7/8/10,

Mac OS, Android OS and Chrome OS. It can work with popular calling (e.g.

Skype, Zoom) and streaming platforms (e.g. OBS, YouTube) for

applications including video conferencing and live streaming.

Features

Supports MJPG, YUY2 and H.264 video compression format to be

compatible with most application platforms.

Supports video resolutions up to 1080P@30Hz.

85° Wide-angle distortion-less lens support to capture more people

and surroundings for better performance.

Fixed focus lens shows excellent image with the depth of field

ranges from 0.3m to 5m during live streaming or video

conferencing.

Built-in auto noise reducing mic to make the sound clear and to

allow for sound pick-up within the distance of 3m.

Supports UC and web conferencing platform like Skype, Zoom,

WebEx, etc.

Introduction

www.avaccess.com 3 info@avaccess.com

Can work with popular streaming platforms like OBS, Facebook and

YouTube to share content.

Compatible with mainstream OS, including Windows 7/8/10, MAC

OS, Android OS, Chrome OS, etc.

Plug and play.

Equips multiple-purpose mounting clip for easy installation on the

top of a laptop, a display or a universal tripod.

Package Contents

Before you start the installation of the product, please check the package

contents:

USB Camera (with Lens Cap) x 1

User Manual x 1

Introduction

www.avaccess.com 4 info@avaccess.com

Panel

USB-A Cable

Camera LensMIC In

LED

Bracket When USB camera is powered on,

two seconds later, the LED will be

on for four seconds and then off.

When USB camera is transferring

data, the LED is on.

Application

www.avaccess.com 5 info@avaccess.com

Application

The USB Camera can be mounted on the top of a display screen as the

following shown:

Display

Note: After the USB camera is connected to a computer, its camera and MIC can

be detected by the system and specific application in the name of the following:

Camera Name: AVA BizEye 50

MIC Name: AVA BizEye 50

Specifications

www.avaccess.com 6 info@avaccess.com

Specifications

Camera

Sensor 1/3.08'', CMOS, Effective Pixel: 2.0M

Scanning Mode Progressive

Lens Mount M12

Diagonal Field of View

(dfov)

100° (F2.4, f3.0, AGC ON)

Horizontal Rotation

Range

Leftward: 30°

Rightward: 30°

Vertical Rotation Range Upward: 10°

Downward: 60°

Shutter 1/30s ~ 1/10000s

White Balance Auto

Backlight Compensation Support

Digital Noise Reduction Yes

USB

Operating System Windows 7/8/10, Mac OS, Android OS, Chrome OS

Color System/

Compression

MJPEG (default)/YUY2/H.264

Resolutions

MJPEG: 640x480, 160x120, 176x144, 320x180,

320x240, 352x288, 424x240, 480x272, 640x360,

720x576, 800x448, 800x600, 848x480, 960x540,

1024x576, 1024x768, 1280x720, 1600x896,

1920x1080 (default)

YUY2: 640x480

H.264: 640x480, 320x180, 320x240, 352x288,

480x272, 640x360, 720x576, 800x448, 800x600,

848x480, 960x540, 1024x576, 1024x768,

1280x720, 1600x896, 1920x1080 (default)

USB Video

Communication

Protocol

UVC 1.0

USB Cable Length 1.5m

USB Port 1 x USB 2.0 Type A

Specifications

www.avaccess.com 7 info@avaccess.com

General

Operating Temperature 0°C ~ 40°C (32°F to 104°F)

Storage Temperature -20°C ~ 60°C (-4°F to 140°F)

Input Voltage 5V (USB power supply)

Current Consumption 0.3A

Power Consumption 1.5W (Max)

MTBF >30000h

Device Dimensions

(W x H x D)

140mm x 49.7mm x 70.1mm/5.51’’ x 1.96’’ x 2.76’’

(with bracket)

Product Weight 0.03kg/0.066lb (with bracket)

Troubleshooting

1. How to deal with image dithering after the USB camera is

properly installed?

Check and ensure the USB camera is installed firmly in a

location.

Remove vibrating apparatus or objects nearby (if any) so to

prevent potential interferences on the USB camera.

AV Access Technology Limited

V1.0.1
