Avalue Technology ARC-1200 Bedienungsanleitung

Part No. E2017A121A0R

ARC-1200/1500/1700

/10W00/15W00/21W00

Rugged PCAP Multi-Touch Monitor

Quick Reference Guide

1st Ed –07 September 2021

ARC-1200/1500/1700/10W00/15W00/21W00

2 ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide
ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide


Content

Getting Started ........................................................................................................4
1 Safety Precautions....................................................................................................4
2 Packing List...............................................................................................................4
3 System Specifications...............................................................................................5
4 System Overview....................................................................................................10
4.1 I/O View................................................................................................................................. 10
5 System Dimensions (with Panel Mounting’s Bracket) .............................................12
5.1 ARC-1200 Front and Rear side............................................................................................. 12
5.2 ARC-1500 Front and Rear side............................................................................................. 13
5.3 ARC-1700 Front and Rear side............................................................................................. 14
5.4 ARC-10W00 Front and Rear side.......................................................................................... 15
5.5 ARC-15W00 Front and Rear side.......................................................................................... 17
5.6 ARC-21W00 Front and Rear side.......................................................................................... 18
Hardware Configuration .......................................................................................19
1 ARC-1200/1500/1700/10W00/15W00/21W00 connector mapping.........................20
1.1 VGA connector (VGA) ........................................................................................................... 20
2 OSD Key Setting.....................................................................................................21
2.1 OSD Key Function:................................................................................................................ 21
2.2 OSD Key TREE Table:.......................................................................................................... 22


ARC-1200/1500/1700/10W00/15W00/21W00

4 ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x ARC-1200/1500/1700/10W00/15W00/21W00 Rugged PCAP

Multi-Touch Monitor

1 x Power Adapter

1 x Power cord

1 x HDMI cable

1 x USB cable for Touch (type B)

4 x screws for VESA

8~12 x screws for Panel Mount

8~12 x brackets for Panel Mount

8~12 x plastics spacer for Panel Mount

Quick Reference Guide

ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

1.3 System Specifications

Component

Model

ARC-1200

ARC-1500

ARC-1700

Mother Board

ACC-ADBOARD-11R

ACC-ADBOARD-10R

ACC-ADBOARD-16R

Optional DC to DC convert Board 9V to 36V(ACC-POWERBOARD-01R)

Chipset

RTD2556T

CPU Cooler(Type)

Fanless

Power Supply

DC in

Adapter

ACC-ADP-060N-07R

(AC/DC adapter 12V/5A 90 Plug Type)

Speaker

2 x Speaker(2W)

Other Component

OSD control board (OSD-5KEY-A001)

Optional DC to DC converter Board 9V to 36V (PB-GL01)

Optional Millitronic WiFi 6 Media Server Module

Panel

LCD Panel

12.1" XGA LED PANEL

InnoLux G121XCE-L01

15" XGA TFT LED Panel

CMI G150XNE-L03

17" SXGA TFT LCD

AUO G170EG01 V1

LCD Control Board

Built in

B/L Inverter/Converter

N/A

Touch Screen

12.1" PCAP YFO

H8573C+EETI

EXC84H4254

15" PCAP Touch YFO

H8900A COF

YFO 17" PCAP Touch,

YoungFast H8539D

Touch Controller

EETI EXC84H4254

ILITEK ILI2511

EETI

External I/O

USB Port

1 x USB type B for touch function

Video Port

1 x VGA, 1 xHDMI 1.4a (HDCP 1.3), 1 x DP 1.2 (HDCP 1.3) input connectors

Audio Port

1 x Audio phone jack in

Indicator Light

1 x LED (from OSD 5 keys)

Others

OSD key(5 keys)

Mechanical

Power Type

12V DC in (optional 9~36V)

Power Connector

Type

12V DC jack in

(Option for wide voltage 9~36V DC jack & phoenix connector in)

Dimension

293.77 x 226.31 x 61.5

350.51 x 274.51 x 63.5

392.72 x 325.32 x 70.25

Weight

2.5 Kg

3.7 Kg

4.6 Kg

Color

Black

ARC-1200/1500/1700/10W00/15W00/21W00

6 ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

Fanless

OS Support

Windows, Linux

Reliability

EMI Test

CE/ FCC Class A

Vibration Test

Random Vibration Operation

1 Test PSD : 0.00454G²/Hz , 1.5 Grms

2 System condition : operation mode

3 Test frequency : 5~500 Hz

4 Test axis : X,Y and Z axis

5 Test time : 30 minutes per each axis

6 IEC60068-2-64 Test Fh

6 Storage : mSATA

Sine Vibration test (Non-operation)

1 Test Acceleration : 2G

2 Test frequency : 5~500 Hz

3 Sweep：1 Oct/ per one minute. (logarithmic)

4 Test Axis : X,Y and Z axis

5 Test time :30 min. each axis

6 System condition : Non-Operating mode

7. Reference IEC 60068-2-6 Testing procedures

Package Vibration Test:

1 Test PSD : 0.026G²/Hz , 2.16 Grms

2 Test frequency : 5~500 Hz

3 Test axis : X,Y and Z axis

4 Test time : 30 minutes per each axis

5 IEC 60068-2-64 Test Fh

Mechanical Shock

Test

1 Wave from : Half Sine wave

2 Acceleration Rate : 10g for operation mode

3 Duration Time : 11ms

4 No. of shock : Z axis 300 times

5 Test Axis : Z axis

6 operation mode

7 Reference IEC 60068-2-27 testing procedures

Test Eb : Shock Test

Drop Test

Package drop test

Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed

Test Ea : Drop Test

1 Test phase : One corner, three edges, six faces

Quick Reference Guide

ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

2 Test high : 96.5cm

3 Package weight : 5Kg

4 Test drawing

4-feet drop resistance without package

MIL-STD-810G

Operating

Temperature

-10°C ~ 50°C

(0 to 40 °C with adapter Safety)

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Component

Model

ARC-10W00

ARC-15W00

ARC-21W00

Mother Board

ACC-ADBOARD-13R

ACC-ADBOARD-15R

ACC-ADBOARD-12R

Optional DC to DC convert Board 9V to 36V(ACC-POWERBOARD-01R)

Chipset

RTD2556T

CPU Cooler(Type)

Fanless

Power Supply

DC in

Adapter

ACC-ADP-060N-07R

(AC/DC adapter 12V/5A 90 Plug Type)

Speaker

2 x Speaker(2W)

Other Component

OSD control board (OSD-5KEY-A001)

Optional DC to DC converter Board 9V to 36V (PB-GL01)

Optional Millitronic WiFi 6 Media Server Module

Panel

LCD Panel

10.1" TIANMA

TM101JDHP03

1280x800

15.6" TFT LED Panel

CMI G156BGE-L01

(option for Full HD

version)

21.5" INNOLUX

M215HJJ-L30 TFT LCD

LCD Control Board

Built in

B/L Inverter/Converter

N/A

LED driving board for

D2626514G1PA

Touch Screen

Sense 10.1" PCAP

Touch, ST-101C26E

15.6" YFO H8811C

PCAP GF1 COB+Weida

WDT8752A

YFO 21.5" PCAP Touch

for ARC-21W H8593H

Touch Controller

EETI

YW52H456P5656

Control board (Weida

WDT8752A)

EETI EXC84H5680

External I/O

ARC-1200/1500/1700/10W00/15W00/21W00

8 ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

USB Port

1 x USB type B for touch function

Video Port

1 x VGA, 1 xHDMI 1.4a (HDCP 1.3), 1 x DP 1.2 (HDCP 1.3) input connectors

Audio Port

1 x Audio phone jack in

Indicator Light

1 x LED (from OSD 5 keys)

Others

OSD key(5 keys)

Mechanical

Power Type

12V DC in (optional 9~36V)

Power Connector

Type

12V DC jack in

(Option for wide voltage 9~36V DC jack & phoenix connector in)

Dimension

282.36 x 201 x 61.4 mm

391.21 x 239.21 x 68 mm

538.05 x 341.05 x 71 mm

Weight

2 Kg

3.2 Kg

6.5 Kg

Color

Black

Fanless

OS Support

Windows, Linux

Reliability

EMI Test

CE/ FCC Class A

Vibration Test

Random Vibration Operation

1 Test PSD : 0.00454G²/Hz , 1.5 Grms

2 System condition : operation mode

3 Test frequency : 5~500 Hz

4 Test axis : X,Y and Z axis

5 Test time : 30 minutes per each axis

6 IEC60068-2-64 Test Fh

6 Storage : mSATA

Sine Vibration test (Non-operation)

1 Test Acceleration : 2G

2 Test frequency : 5~500 Hz

3 Sweep：1 Oct/ per one minute. (logarithmic)

4 Test Axis : X,Y and Z axis

5 Test time :30 min. each axis

6 System condition : Non-Operating mode

7. Reference IEC 60068-2-6 Testing procedures

Package Vibration Test:

1 Test PSD : 0.026G²/Hz , 2.16 Grms

2 Test frequency : 5~500 Hz

3 Test axis : X,Y and Z axis

4 Test time : 30 minutes per each axis

5 IEC 60068-2-64 Test Fh

Quick Reference Guide

ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

Mechanical Shock

Test

1 Wave from : Half Sine wave

2 Acceleration Rate : 10g for operation mode

3 Duration Time : 11ms

4 No. of shock : Z axis 300 times

5 Test Axis : Z axis

6 operation mode

7 Reference IEC 60068-2-27 testing procedures

Test Eb : Shock Test

Drop Test

Package drop test

Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed

Test Ea : Drop Test

1 Test phase : One corner, three edges, six faces

2 Test high : 96.5cm

3 Package weight : 5Kg

4 Test drawing

4-feet drop resistance without package

MIL-STD-810G

Operating

Temperature

-10°C ~ 50°C

(0 to 40 °C with adapter Safety)

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Note: Specifications are subject to change without notice.

ARC-1200/1500/1700/10W00/15W00/21W00

10 ARC-1200/1500/1700/10W00/15W00/21W00 Quick Reference Guide

1.4 System Overview

1.4.1 I/O View

ARC-1200

ARC-1500

ARC-1700

ARC-10W00

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Avalue Technology Touch-Screen Handbücher

Avalue Technology

Avalue Technology HID-2100 Bedienungsanleitung

Beliebte Touch-Screen Handbücher anderer Marken

Elecro Engineering

Elecro Engineering Poolsmart Plus Montageanleitung

Johnson Controls

Johnson Controls IQ4 HUB Bedienungsanleitung

Elo TouchSystems

Elo TouchSystems ET2270L Bedienungsanleitung

Elo TouchSystems

Elo TouchSystems ET1002L Bedienungsanleitung

Elo TouchSystems

Elo TouchSystems 3201L Bedienungsanleitung

Duratec

Duratec S15 Bedienungsanleitung

Crestron

Crestron TPMC-3SM Bedienungsanleitung

Racelogic

Racelogic MFD Touch Bedienungsanleitung

J2 580 Benutzerhandbuch

HAI

HAI OmniTouch 10p Bedienungsanleitung

panel

panel PC PSR108-FM Series Bedienungsanleitung

Tipro

Tipro FREE+ Bedienungsanleitung

Systemline

Systemline Commander Bedienungsanleitung

Interactive Technologies

Interactive Technologies Insite Bedienungsanleitung

GVision

GVision Legacy Bedienungsanleitung

BeiJer

BeiJer T21C-C24 Bedienungsanleitung

Advantech

Advantech ITM-5117 Series Bedienungsanleitung

Edge

Edge CS Bedienungsanleitung
