Avantco 177FBF1824LP Bedienungsanleitung
User Manual
www.AvantcoEquipment.com 1
Gas Donut Fryers
Models: 177FBF1824LP, 177FBF1824NG,
177FBF2424LP, 177FBF2424NG
Please read and keep these instructions. Indoor use only.
09/2021
User Manual
WARNING
Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death.
Read the installation, operating, and maintenance instructions thoroughly before installing or servicing this equipment.
User Manual
2 www.AvantcoEquipment.com
IMPORTANT FOR YOUR SAFETY
This manual has been prepared for personnel qualified to install gas equipment, who should perform
the initial field start-up and adjustments of the equipment covered by this manual.
Post in a prominent location the instructions to be followed in the event the smell of gas is detected.
This information can be obtained from the local gas supplier.
GENERAL
Our gas tube donut fryers are produced with quality workmanship and material. Proper installation,
usage, and maintenance will result in years of satisfactory performance.
Before installing the fryer, thoroughly read this manual and carefully follow all instructions.
This manual is applicable to models listed below. Procedures in this manual will apply to all models
unless specified. Pictures and illustrations can be of any model unless the picture or illustration needs
to be model specific.
UNPACKING
This fryer was carefully inspected before leaving the factory. Upon acceptance of the shipment, the
transportation company assumes full responsibility for safe delivery.
Immediately after unpacking the fryer, check for possible shipping damage. If the fryer is damaged,
save the packaging material and contact the carrier immediately.
In the event a gas odor is detected, shut down units at the main shutoff valve and
contact the local gas company or gas supplier for service.
Do not store or use gasoline or other flammable vapors or liquids
in the vicinity of this or any other appliance.
IMPORTANT
FOR YOUR SAFETY
User Manual
3 www.AvantcoEquipment.com
Safety2
General 2
Unpacking 2
Specifications 4
Installation 5
Codes and Standards 7
Assembly8
Flue Connection8
Gas Connection9
Leveling the Fryer 10
Operation11-15
Cleaning 15
Boil Out Procedure 16
Maintenance 17
Flue Vent Inspection17
Index
Supply pressure should be minimum of 4"W.C. for natural gas or 10"W.C. for propane. The fryer comes with 3/ 4"
NPT male connector on a 1/ 2" pipe, allowing you to connect with either 3/ 4" or 1/ 2" NPT female connector.
*Minimum supply pressure 4" is W.C. for natural gas and 10"W.C. for propane.
User Manual
4 www.AvantcoEquipment.com
SPECIFICATIONS
DIMENSIONS
177FBF1824LP
177FBF1824NG
177FBF2424LP
177FBF2424NG
MODEL
29 / "
29 / "
WIDTH
DEPTH
58
58
HEIGHT
10" W/C
4" W/C
10" W/C
4" W/C
MANIFOLD
PRESSURE
Natural
Gas
Liquid
Propane
GAS TYPE
GAS SUPPLY INFORMATION
(A)
(A)
(B)
(C)
(B) (C)
24" 41 " 58"/
24" 41 " 58"
"
"
/
41 "
/
41 "
/
User Manual
www.AvantcoEquipment.com 5
INSTALLATION
Do not use the door or its handle to lift the fryer.
Before installing the fryer, verify that the type of gas (natural or propane) is in conformity to the
specifications on the fryer data plate, which is located on the inside of the door panel. Make sure
the fryer is configured for the proper elevation.
Clearances
• Minimum clearance from combustible construction:
The fryer may be installed on combustible floors
Location
• Install fryer in an area with sufficient air supply for gas combustion at fryer burners.
• Do not obstruct the flow of combustion and ventilation air.
• Provide adequate clearance for air openings into the combustion chamber.
• Do not permit fans to blow directly onto fryer.
• Avoid wall-type fans, which create cross-currents within a room. Avoid open windows
next to sides or back.
Minimum clearance from
noncombustible construction
Sides of Fryer
Front of Fryer
Between the fryer and
any open-top flame units 16" (41 cm)
0"
0"
Minimum clearance from
noncombustible construction
Sides of Fryer
Back of Fryer 6"
6
"
Allow space for
servicing and operation.
NOTE
All avantco donut fryers shall be installed with at least a 16
inch space between the fryer and Surface ames from
adjacent equipment
User Manual
6 www.AvantcoEquipment.com
Take out the outside chimney.
Please connect the outside chimney using screws
2
Fix the two supporting brackets. The lid
extending direction can be at either right or left side.
Take out the inner chimney. Please fasten the inner
four screws.
1
chimney to the inner chimney support using
User Manual
www.AvantcoEquipment.com 7
CODES AND STANDARDS
The fryer must be installed in accordance with:
In the United States:
• State and local codes, or in the absence of local codes, with:
Assemble the handle using the screws provided.
Attach handle.
User Manual
8 www.AvantcoEquipment.com
• National Fuel Gas Code, ANSI-Z223.1/NFPA #54 (latest edition). Copies may be obtained from The
American Gas Association Accredited Standards Committee Z223, @ 400 N. Capital St. NW, Wash-
ington, DC 20001 or the Secretary Standards Council, NFPA, 1 Batterymarch Park Quincy, MA 02169-
7471.
• NFPA Standard #96 Vapor Removal from Cooking Equipment, latest edition, available from the Na-
tional Fire Protection Association, Batterymarch Park, Quincy, MA.
• National Electrical Code, ANSI/NFPA-70 (latest edition). Copies may be obtained from The National
Fire Protection Association, Batterymarch Park, Quincy, MA. 02169-7471.
• In the commonwealth of Massachusetts all gas appliances vented through a ventilation hood or ex-
haust system with a damper or with a power means of exhaust shall comply with 248 CMR.
In Canada:
• Local codes
• CAN/CSA-B149.1 Natural Gas and Propane Installation Code (latest edition),available from the
Canadian Standards Association, 155 Queen Street, Suite 1300, Ottawa, Ontario Canada K1P 6L1.
• CSA C22.1 Canadian Electric Code (latest edition), available from the Canadian Standards Associa-
tion, 155 Queen Street, Suite 1300, Ottawa, Ontario Canada K1P 6L1.
ASSEMBLY
The fryer must be restrained to prevent tipping and the splashing of hot liquid. The means of restraint
may be the manner of installation, such as connection to a battery of appliances, installing the fryer in an
alcove, or by separate means such as adequate ties.
FLUE CONNECTION
Make the flue connection as follows:
• Comply with Vapor Removal from Cooking Equipment, ANSI-NFPA Standard #96 (latest edition),
available from the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
• Locate the fryer under a hood with adequate connection to an exhaust duct. The hood must extend 6”
(15 cm) beyond fryer on both sides.
• Clearance above the fryer should be adequate for combustion byproducts to be removed efficiently.
• An 18” (46 cm) minimum clearance should be maintained between the flue vent and the filters of the
hood venting system.
• Never make flue connections directly to the fryer.
User Manual
www.AvantcoEquipment.com 9
GAS CONNECTION
Prior to lighting, check all joints in the gas supply line for leaks. Use soap
and water solution.
Do not use an open flame
After piping has been checked for leaks, fully purge gas pipes to remove air.
1/2 Gas connection, 12/ to 3/4 adapter included in the unit.
GAS PRESSURES (ALL MODELS):
The gas pressure should be set at 4” W.C. (Water Column) (0.8 kPa) for natural gas and 10” W.C.
(2.75 kPa) for propane gas. If incoming pressure exceeds ½ PSI (3.45 kPa), an additional pressure
regulator must be installed.
TESTING THE GAS SUPPLY PIPING SYSTEM:
When test pressures exceed ½ PSI (3.45 kPa), the fryer and its individual shutoff valve must be dis-
connected from the gas supply piping system.
When test pressures are ½ PSI (3.45 kPa) or less, the fryer must be isolated from the gas supply pip-
ing system by closing its individual shutoff valve.
Fryers with Casters:
Separate instructions for installing casters are included with the casters:
• The installation shall be made with a connector that complies with the Standard for
Connectors for Movable Gas Appliances, ANSI Z21.69, CAN/CGA-6.16, and a quick disconnect
device that complies with the Standard for Quick-Disconnect Devices for Use with Gas
Fuel, ANSI z21.41 CSA 6.9 or Quick-Disconnect Devices for Use with Gas Fuel.
• When installing a quick disconnect you must also install a means for limiting the movement
of the fryer. This device will prevent the gas line or quick disconnect from being strained.
The restraining device should be attached to the cutout on the back panel. See illustration
for location.
WARNING
• Do not obstruct the flow of the gases from the appliance. Proper air balance should be maintained in
the room.
• Ensure that your ventilation system does not cause a down draft at the fryer’s flue opening. Down
draft will not allow the fryer to exhaust properly and will cause overheating which may cause perma-
nent damage. Damage caused by down draft will not be covered under equipment warranty. Never
allow anything to obstruct the flue or ventilation exiting from the fryer flue. Do not put anything on top
of flue area.
User Manual
10 www.AvantcoEquipment.com
A Rear of Fryer
B Strain Relief Chain Connection (Chain supplied by others)
• The fryer must be installed with a connector (not supplied by Factory) complying with the
above codes.
• The fryer must be installed with restraining means to guard against transmission of strain to the
connector. See illustration.
• The fryer must be installed with the casters provided.
• If the restraint is ever to be disconnected, first turn the gas supply off. If disconnection of the
restraint is necessary, to reconnect this restraint after the fryer has been returned to its originally
installed position.
LEVELING THE FRYER
• Check the level of the fryer by placing a level on top of the fryer after gas connections have
been made.
• Ensure that the fryer is level front-to-back and side-to-side in the final installed position.
• Lock the wheels after unit is level.
