Avaya 3725 Bedienungsanleitung
Avaya 3725 DECT Telephone - Quick Reference Guide
Display Icons
Signal strength
Battery status
Voice mail
Microphone off
Ring volume set to silent
Loudspeaker on
Loudspeaker off
Sound off
Headset connected
Bluetooth headset connected
Bluetooth
New message
Read message
Missed call
Incoming call
Outgoing call
System connection
Key lock
Phone lock
Display
Volume buttons
Soft keys
Off-hook key
Five-way Navigation
key Alphanumeric keys
Key lock and
Upper/lower case
Shows time and icons
Shows date and icons
Sound off button
Shows the soft key
function
Microphone
Multifunction button
On/Off, On-hook key
Space
Headset connector
Voice mail
Confirmation button
Sound off key
LED
Avaya 3725 DECT Telephone - Quick Reference Guide
The cordless telephone is a feature-rich handset with colour
display, telephony, messaging, and bluetooth. It is designed
to be used in office environment and medium demanding
environment such as hospital environment.
It is suitable for users dependent of being reachable and/or
having a need for mobile voice and messaging features,
which makes it ideal for applications where the user needs
either one way messaging or to be able to interact with
other users. The colour display enhances and simplifies the
use of the cordless telephone.
Read the safety instructions before use.
For software download and parameter set up, read the
Installation and Administration Manual, IP DECT
* System dependent
Note: Your unit may have more functions than described
here; see User Guide, Avaya 3725 DECT Telephone.
Product presentation
Functions 3725
Local phonebook (250 contacts) X
Central phonebook X*
Company phonebook X
Vibrator X
Headset connector X
Microphone on/off during call X
Loudspeaking function X
SMS (Short Message Service) X*
Voice mail access X*
Centralized management X*
Easy replaceable battery X
Bluetooth X
Avaya 3725 DECT Telephone - Quick Reference Guide
Switch the telephone on/off
Press and hold the On-Hook key until pop-up
question is displayed.
Make a call
Dialling can be made in the following ways:
• In idle screen, dial the number and press the Off-hook
key .
• Press the Off-hook key and enter the number.
• Press a pre-programmed Hot key*or Soft key.
• Dial a number from the local phonebook. Enter the
Contacts menu, select Call contact and select the name
from the list, press Call or the Off-hook key .
• Dial a number from the Central phonebook. Enter the
Contacts menu, select Central phonebook > search by
name/number/last result, and press Search. Press Off-
hook key .
* The alpha-numeric keys can be programmed with a
telephone number.
Answer/End a call
When the ring signal sounds; press the Off-hook key
to answer.
To end the call, press the On-hook key .
Turn loudspeaking function on/off
During a call, press theleft Soft key to turn the loudspeaking
function on/off.
Basic functions
Avaya 3725 DECT Telephone - Quick Reference Guide
Turn audio signals on/off
In idle mode a long press on the Sound off key changes
between audio signals on/off. The Sound off icon
indicates a completely silenced telephone.
• A short press on the Sound off key before answering a
call, silences the ring signal.
Lock/Unlock the keypad manually
Press the -key to lock/unlock and then Soft key Lock/
Yes. The Locked keypad icon indicates a locked
keypad.
Change the volume during a call
Press the Volume button upwards to increase the volume,
downwards to decrease the volume. Or, use the Navigation
key to adjust the volume.
Charge the battery
Charging is done in a desktop charger or in a charging rack.
Charging is indicated by orange LED. When the battery is
fully charged the LED is green and a fully charged Battery
icon is displayed.
While in a desktop charger the telephone is fully
operational. The telephone does not vibrate in charger.
The battery can also be charged in a separate battery pack
charger.
Note: Charging below 5°C will harm the battery and shorten
the lifetime.
Remove the battery
It is recommended to switch off the telephone before
removing the battery.
Receive a text message
When a text message is received, the LED starts flashing
and a message tone sounds. A pop-up New message(s):1
View now? is displayed and the Soft keys Yes/No to read
Messaging
Avaya 3725 DECT Telephone - Quick Reference Guide
the message now or later. The message is then stored in
the message list. The New message icon is shown in
the display.
If the message is received during a call, the user is notified
by a beep.
Read a stored message
Open the Message list, either from the messaging menu or
by pressing the Navigation key in Idle screen. Use the
Navigation key to navigate in the Message list. Select
message and press the soft key View to read the message.
Send message
Open the Messaging menu , and select Write new
message. Enter text, press the soft key Send, and then
enter a number, or press the midle soft key for phonebook
look-up. Press Send.
Delete a stored message
To delete a message, select message and press the soft
key More, select Delete, and press the soft key Yes.
Check voice mail
A new voice mail is indicated by a pop-up and the icon.
Only one voice mail at the time will be displayed in the
message list.
Open the Messaging menu, select Inbox, select , press
the soft key View, and press Call.
or
A long press on digit key 1will call your voice mail. If the
extension number is not available a pop-up Voice mail
number not defined is displayed. See User Guide, Avaya
3725 DECT Telephone.
Avaya 3725 DECT Telephone - Quick Reference Guide
.
For descriptions of all functions; see User Manual, Cordless
Telephone 3725.
Navigate the menu
Use the Navigation key to move around in the menu
structure.
The menus are; Connections, Calls, Short cuts, My
favourites, Messaging, Settings, Profiles, and Contacts.
The three Soft keys below the display are used for choices
in the menu. The function of each Soft key is explained by
text in the soft key field in the display.
Use the local phonebook
To find and call a name: Enter Contacts , step to Call
contact and press Select. Enter the first letter in the name
or the whole name (will be displayed in Search field while
entering text), or step in the contact list. Select the name
and press Call.
To edit the contact: Select Edit contact, select the name
and press Edit. Make your changes, press OK and then
press Save.
Menu
BackSelect
10:45
Messaging
Avaya 3725 DECT Telephone - Quick Reference Guide
To add a contact, select Add contact, select New or From
call list. Press Add, enter the name and press OK. Select
Number, enter the number, press OK and press Save.
To delete a contact: select Delete contact, select the name,
press Delete, and then press Yes.
Use the central phonebook
Enter Contacts , and select Central phonebook.
Select Search by name, Search by number, or Last
result. Enter the first letter(s) in the first name, and/or the
first letter(s) in the family name. Press Search. The Central
phonebook will be searched and a list of matching names
will be displayed. You can step to the next entry in
alphabetic order by pressing the Navigation key. Press
More to add contact, or press Call or the Call key to
make the call.
Use the company phonebook
The company phonebook has to be imported via the PDM
before it will be visable in the handset. See User Manual,
Cordless Telephone 3725.
Enter Call list. A contact from the company phonebook is
marked with the symbol. Select name/numberand press
Call, only work number is available for the contact and it is
not editable.
Soft keys, Hot keys and Multifunction button
The three Soft keys below the display can be defined for
specific functions such as dialling a specific number.
A long press on a Hot key can have the same function as a
Soft key and any key 0, 2- 9can be programmed as a Hot
key. The Multifunction button can also be programmed for
different functions with the use of long press and double
press.
For more information about Soft keys, Hot keys and
Multifunction button, see User Guide, Avaya 3725 DECT
Telephone.
Avaya 3725 DECT Telephone - Quick Reference Guide
Turn the automatic keypad lock on/off
Enter Settings , and step to Locks. Select Automatic
key lock Off/On, select On/Off, and press Back. A locked
keypad is indicated by the Key lock icon .
To unlock,press the key , and then the Soft key Yes.
Avaya 3725 DECT Telephone - Quick Reference Guide
The following accessories for the Avaya 3725 DECT
Telephone are available:
Also available:
• Telephone lanyard
• Rackmount Charger
• Multiple Battery Charger
Accessories
Leather casing incl. belt clip Belt clip, swivel type
Standard clip Desktop chargers
Headset with microphone
on boom
