Avenview DVI-GS3 Series Bedienungsanleitung

DVI-GS3 Series

Part #: DVI-GS3-2

www.avenview.com

Description

DVI-GS3-2 GameSwitch allows you play over a DVI monitor in High-Definition resolutions of 720p

/ 1080p for ultimate HD multimedia experience. Now you can experience High Definition Gaming

at maximum resolution. GameSwitch enables you to play console games on a regular DVI

monitor. With only one monitor, DVI GameSwitch is perfect solution for watching high definition

contents. Switching between two machines as easy as a click of a button. GameSwtich gives you

ultimate visual experience on your DVI monitor.

Features

Play latest console games on DVI monitor at High Definition

One monitor for two devices

Simultaneous connection from two of following devices:

Game Console

PC with graphics output

DVD Players with HDMI output

Blue-Ray / HD-DVD Player

DV Camcorder

Plug & Play

Easy screen switching via select button

Supports HD resolutions of up to 1080p

Compliant with HDMI 1.2, HDCP and DVI 1.0

High quality audio to stereo speaker or monitor with built-in speaker

LED status to indicate the source displayed

Supports VGA, SVGA, XGA, TFT_LCD, LCD TV, PDP, Projector with DDC2B function

LEDs on Transmitter and Receiver to indicate system status

Equipped with magnetic pad and metal plate for easy installation

Compact size

www.avenview.com

System Devices and Functions

DVI-GS3-2

Built-in two set of DVI inputs

Built-in one set of DVI output

Built-in one set of Speaker output

Installation Diagram of DVI-GS3-2

www.avenview.com

Cable and Accessories

Game Cable

Console Cable

USB Power Cable

Power Adapter

(Sold Seperately)

Package Content

DVI-GS3-2

GameSwitch

1 GameSwitch

Selector Cable

HDMI & AV to DVI Cable 1.8m

USB Power Cable

User Manual

www.avenview.com

Specifications

GameSwitch DVI-GS3-2

Input

Connector

Game: DVI Female x 1, Audio Female x 1

PC: DVI Female x 1, Audio Female x 1

Cable

Game: HD & AV to DVI Cable

PC: Use monitor’s DVI and Audio cable

Output

Connector

DVI Female x 1, Audio Female x 1

Cable

DVI to DVI + Select Button + Audio cable

Supported Resolution

480i, 480p, 720p, 1080i, 1080p

Audio Channel

Stereo

Switching Method

Auto or Manual Select Button

Supported Signal

HDMI 1.2, HDCP, DVI 1.0

Power Consumption

DC 5V, 700mA

Housing

Metal

Dimension (LxWxH)

Compact Size: 62 x 113 x 29 mm

Operating

Temperature

0 ~ 50°

Storage Temperature

-20 ~ 60°

Humidity

10 ~ 90%

Features, availability and specifications are subject to change without notice.

Avenview Inc.

[email protected]

www.avenview.com
