AWOL VISION LTV-3500 Bedienungsanleitung

MENU ITEMS

IMAGE MODE

U S E R S E T T I N G S

A D V A N C E D I M A G E S E T T I N G S

ZOOM MODE

IMAGE RESET

L I G H T S E T T I N G S

P R O J E C T I O N M O D E

A C T U A T O R C O N T R O L

C O R R E C T I O N C O N T R O L

M A N U A L C O R R E C T I O N

FOCUS

SOUND MODE

E Q U A L I Z E R D E T A I L

A D V A N C E D S O U N D S E T T I N G S

OUTPUT DEVICE

A U D I O O U T P U T F O R M A T

D T S V I R T U A L X

DOLBY ATMOS

SOUND RESET

N E T W O R K

B L U E T O O T H

P O W E R S E T T I N G S

L A N G U A G E

T I M E

I N P U T M E T H O D

E Y E C A R E

C E C E N A B L E

S C R E E N S A V E R / T I M E R

K E Y T O N E

D E V I C E I N F O R M A T I O N

U P D A T E S

U S E R A G R E E M E N T

R E S T O R E

TABLE OF CONTENTS

Standard Vivid* Sport Movie Game

OFF Low Medium

1. IMAGE

1.1 IMAGE MODE

User

1.2 USER SETTINGS

Brightness

Contrast

Chroma

Tone

Sharpness

*Default Setting

Image Mode must be set to User to make image customizations.

1.3 ADVANCED SETTINGS

1.3.1 MEMC (Motion Estimation, Motion Compensation)

This feature inserts frames in the middle of two frames of footage to increase the total

number of frames in the same scene. This makes the footage smoother.

High

Select Image Mode based on viewing content.

The default settings in the advanced settings menu will vary according to Image Mode.

Low Medium High

Dark Middle

1.3.4 Dynamic Contrast

1.3.3 Noise Reduction

This feature removes or reduces noise from the image.

Auto

This feature makes dark areas darker and bright areas brighter.

1.3.5 Gamma

Bright

1.3.2 Low Delay Mode

This feature minimizes the HDMI Input Lag. When you select Game Mode in the Image

Mode menu, the Low Delay Mode feature will automatically turn on.

Users are given the extra option to get the HDMI Input Lag performance on all Image

Modes and not just Game Mode. This allows users to not only enjoy a lower HDMI Input

lag but also more accurate colors.

This feature controls the overall brightness of an image.

Users are given the extra options for Gamma Value to meet different viewing environments

(Dark = 2.0 Gamma, Middle = 2.2 Gamma, and Bright = 2.4 Gamma).

1.3.7 White Balance

R-Gain

R-Offset

This feature removes unrealistic color casts, so that objects which appear white in person

are rendered white in the image.

The Gain adjusts the bright part of the image. The Offset adjusts the dimmer parts of the

image. Each setting is based on a scale from -100 to 100.

G-Gain

G-Offset

B-Gain

B-Offset

1.3.8 Color Correction

This feature is the process of adjusting raw image data so the resulting picture looks realistic.

Hue is the full range of visible colors in the spectrum. Saturation is the "colorfulness" or

intensity of a color relative to white. Brightness is the value (dark to bright) of a color.

Red Green Blue

Cyan Magenta Yellow Skin Tone 5

1.3.6 Color Temperature

This feature allows you to select the relative warmth or coolness of the light.

Cool Standard Hot User

1.3.9 MPEG

OFF Low Medium High

1.3.10 HDR

Auto Low Middle High

1.4 ZOOM MODE

This feature allows you to shrink or enlarge the image.

Auto* 4:3 Movie Expand 16:9

*Default Setting

1.5 RESET

Click Reset to reset the Image settings to factory settings.

This noise reduction feature reduces block noise around outlines and mosquito noise on the

background.

This feature can only be turned on when the projector plays HDR content. Users can

change the HDR's EOTF (Electro-Optical Transfer Function) Setting for optimization.

Bright Standard* Soft

2. LIGHT

2.1 LIGHT SETTINGS

High Dynamic Low Dynamic User

*Default Setting

2.1.1 Light Mode

Select the laser source output power; the higher output power means higher lumens.

2.1.2 Custom

Light Mode must be set to User to make light customizations. This setting is based on a

scale from 0 to 10.

2.1.3 Intelligent Light Sensing

2.2 PROJECTION MODE

Front-Projection Rear-Desktop Front-Ceiling Rear-Ceiling

Select the Projection Mode based on how the projector is positioned.

This feature allows the projector to automatically adjust the laser source output power

according to the ambient light.

If the ambient light is dark, the laser source output will decrease automatically. If the ambient

light is bright, the projector will increase the laser source output

2.3 ACTUATOR CONTROL

This feature enables 4K Resolution.

2.4 CORRECTION CHART

This feature aids in the positioning of the projector relative to the screen.

The message on the screen reads, "Please move the host position so that the reference

line coincides with the screen border."

2.5 MANUAL CORRECTION (KEYSTONE CORRECTION)

This feature allows projectors that are not placed perpendicular to the horizontal centerline

of the screen (too high or too low) to skew the output Image, thereby making It rectangular.

The message on the screen reads, "Press OK to select the point you need to adjust".

Click Reset to revert the image back to the original projection. Click Save to apply the

changes made.

2.6 FOCUS

This feature allows you to focus the image.

The message on the screen reads, "Please press up and down key to adjust motor lens for

focus performance".

Standard* Music Sports

3. SOUND

3.1 SOUND MODE

*Default Setting

Select the Sound Mode based on the viewing content.

User

3.2 EQUALIZER DETAIL

120Hz

500Hz

1.5KHz

5KHz

10KHz

Sound Mode must be set to User to tune the equalizer. Each setting is based on a scale

from -50 to 50.

3.3 ADVANCED SETTING

Sound Balance

Bass

Trebel

Make adjustments to the Sound Balance (-50 to 50), Bass (-100 to 100), Trebel (-100 to

100), or AVC (Audio Voice Control). Each Sound Mode has advanced settings.

AVC

Speakers* Bluetooth HDMI eARC

3.4 OUTPUT DEVICE

*Default Setting

Select the Output Device based on the preferred audio output device.

S/PDIF

Auto* PCM Bypass

3.5 AUDIO OUTPUT FORMAT

*Default Setting

Output Device must be set to HDMI eARC or S/PDIF to change Audio Output Format. It is

recommended to configure the audio output format to Bypass when using HDMI eARC in

order to not compress the audio.

3.6 DTS VIRTUAL X

This feature simplifies the expansion of surround sound listening, by providing primarily the

perception of height channels, without requiring additional speakers.

3.7 DOLBY ATMOS

3.8 RESET

This feature allows you to hear sound in a 360-degree bubble with its object-oriented audio

engineering and its up-or-down-firing speakers.

Click Reset to reset the Sound settings to factory settings.
