AXIOMTEK SBC82621 Bedienungsanleitung

SBC82621 Series

Socket370 Half-size

All-in-One CPU Card

User’s Manual

Disclaimers

The information in this manual has been carefully checked and is believed

to be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

AXIOMTEK assumes no responsibility for any inaccuracies that may be

contained in this document. AXIOMTEK makes no commitment to update

or to keep current the information contained in this manual.

AXIOMTEK reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, stored in a retrieval system,

or transmitted, in any form or by any means, electronic, mechanical,

photocopying, recording, or otherwise, without the prior written

permission of AXIOMTEK Co., Ltd.

February 2004, Version A1

Printed in Taiwan

ESD Precautions

Integrated circuits on computer boards are sensitive to static

electricity. To avoid damaging chips from electrostatic

discharge, observe the following precautions:

 Do not remove boards or integrated circuits from their anti-static

packaging until you are ready to install them.

 Before handling a board or integrated circuit, touch an unpainted

portion of the system unit chassis for a few seconds. This helps to

discharge any static electricity on your body.

 Wear a wrist-grounding strap, available from most electronic

component stores, when handling boards and components.

Trademarks Acknowledgments

AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.

IBM is a registered trademark of International Business

Machines Corporation.

MS-DOS, and Windows ’95/98/NT/2000/XP/ME are trademarks

of Microsoft Corporation.

Award is a trademark of Award Software, Inc.

IBM, PC/AT, PS/2, VGA are trademarks of International

Business Machines Corporation.

Intel, Pentium, Pentium II, Pentium III and Celeron are

trademarks of Intel Corporation.

VIA is a trademark of VIA Technologies , Inc.

S3 is a trademark of S3 Graphics , Inc

Realtek RTL-8100C/RTL-8110S is registered trademark of

Realtek Semiconductor Corporation.

Other brand names and trademarks are the properties and

registered brands of their respective owners.

iii

This page does not contain any information.

SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual

T a b l e o f C o n t e n t s

Chapter 1 Introduction............................................................1

1.1 General Description.......................................................1

1.2 Specifications ................................................................2

1.3 Utilities Supported.........................................................3

Chapter 2 Jumpers and Connectors......................................5

2.1 Jumpers and Connectors Layout.................................5

2.2 Jumpers and Connectors Dimensions ........................6

2.3 Jumper Settings.............................................................7

2.3.1 Watchdog Trigger Mode Setting: JP3 .............................. 7

2.3.2 CMOS Clear Jumper: JP8 ............................................... 8

2.3.3 Power Selection of Flat Panel Connector (VDDM of CN1):

JP1 ................................................................................. 8

2.3.4 COM RS232/422/485 Setttings: JP2, JP4, JP5................... 8

2.3.5 DiskOnChipMemory Segment: JP6............................... 9

2.3.6 USB Wake-Up Settings: JP7 .............................................. 9

2.4 Connectors...................................................................10

2.4.1 VGA Interface............................................................... 11

2.4.2 Floppy Disk Controller.................................................... 18

2.4.3 Parallel Port Interface .................................................... 18

2.4.4 Serial Port Interface....................................................... 19

2.4.5 Real Time Clock and CMOS RAM.................................. 19

2.4.6 Keyboard and Mouse Connectors................................ 19

2.4.7 USB Connector ............................................................. 20

2.4.8 IrDA Connector............................................................. 20

2.4.9 Power Input Connectors ............................................... 21

2.4.10 ACPI Connector.......................................................... 21

2.4.11 PC/104 Connectors .................................................... 22

2.4.12 CPU Fan Connector: FAN1 & FAN2 ............................. 23

2.4.13 Flat Panel Bezel Connector......................................... 23

2.4.14 Enhanced IDE Interface Connector ............................ 24

Table of Contents v

SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual

Chapter 3 Hardware Description........................................25

3.1 Microprocessors..........................................................25

3.2 CPU Bus Clock.............................................................25

3.3 BIOS ...........................................................................25

3.4 System Momory...........................................................25

3.5 Real Time Clock and CMOS RAM...............................26

3.6 VGA Interface...............................................................26

3.7 I/O Port Address Map ..................................................27

3.8 Interrupt Controller......................................................28

Chapter 4 Award BIOS Utility ............................................29

4.1 BIOS Introduction........................................................29

4.2 BIOS Setup...................................................................29

4.2.1 Standard CMOS Setup.................................................. 31

4.2.2 Advanced BIOS Features .............................................. 35

4.2.3 Advanced Chipset Features ......................................... 39

4.2.4 Integrated Peripherals................................................... 43

4.2.5 Power Management Setup........................................... 47

4.2.6 PNP/PCI Configuration................................................... 50

4.2.7 PC Health Status ........................................................... 53

4.2.8 Frequency/Voltage Control........................................... 54

4.2.9 Load Fail Safe Defaults ................................................. 55

4.2.10 Load Optimized Defaults ............................................ 56

4.2.11 Save & Exit Setup ........................................................ 57

4.2.12 Exit Without Saving ...................................................... 58

Appendix A Watchdog Timer .............................................59

Table of Contents

SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual

C h a p t e r 1

Introduction

1.1 General Description

The SBC82621 is an industrial grade CPU card. It provides

reliable high performance and function-rich capability.

The CPU incorporates the VIA VT8606 chipset and the

VT82C686B with built-in AGP-4x VGA controller. This

combination ensures its compatibility with ISA bus passive

backplanes.

Designed for the professional embedded developers, the

Socket370 all-in-one SBC82621 CPU card is virtually the

ultimate one-step solution to various applications.

Introduction 1

SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual

1.2 Specifications

 CPU: Intel Celeron, Pentium III, Tualatin and VIA Cyrix

III

 System Chipset: VIA TwisterT (PN133T) VT8606,

VT82C686B with integrated real-time clock

 BIOS: Award PnP BIOS

 Standard I/O:

 Two serial ports; 1x RS-232, 1x RS-232/422/485

 1 x parallel port, SPP/EPP/ECP

 1 x IDE Interface

 1 x FDD Interface

 1 x PS/2 Keyboard Interface

 1 x PS/2 Mouse Interface

 1 x IrDA interface for wireless communication

 System Memory:

 1 x 168-pin DIMM socket

 Maximum of 512MB SDRAM

 ECC/parity checking

 L2 Cache: integrated in CPU

 Watchdog Timer:

 Generates a system reset or NMI by jumper selectable

 Software programmable time interval

 64 levels, 0.5~8/5~80/50~800/100~1600 seconds

 Ethernet:

 Dual Realtek 8100C PCI Bus 10/100M Base-T or One

Realtek 8100C PCI Bus 10/100M Base-T 、Realtek 8110s

PCI Bus 10/100/1000M Base-T

 Wake On LAN (via ATX power supply)

 Onboard RJ-45 connector

Introduction

SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual

 VGA/Flat Panel Controller:

 AGP interface controller with integrated system main-

memory supporting CRT/LCD displays

 Supports up to 1280 x 1024 256-color resolution on non-

interlaced CRT monitors, and 1024 x 768 16 bit-color on

LCD panel monitors

 USB Interface: use a VIA VT6212 4-Port Host Controller

support two ports; USB Spec. Rev. 2.0 compliant

 DiskOnChip: ports DisksupOnChip

 Expansion Slots: one 16-bit PC/104 connector

 Dimensions: 121.92 x 185 mm

NOTE: Specifications are subject to change without notice.

1.3 Utilities Supported

 VIA Chipset Drivers

 Ethernet Utility

 Flat panel/CRT Drivers

 System Doctor

Introduction 3

SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual

This page does not contain any information.

Introduction
