Version: 1.0.2 ENG
Date: 26-08-2022
Configure the AXIS Network Video Door Station
for the CyberGate service
TechNote:
AXIS and
CyberGate
gf1
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
1
CyberGate
Microsoft Teams is the hub for team collaboration in Microsoft Office 365 that integrates people,
content, conversations and tools your team needs. Via the CyberGate application that runs in
Microsoft Azure you can now connect an AXIS Nework Video Door Station to your Microsoft Teams
environment. Microsoft Teams users can answer incoming calls from- or place outgoing calls to the
intercom – with 2-way audio and live video – on the Teams desktop client, Teams desk phone or
Teams Smartphone app and open the door for visitors.
! Note: For instructions on how to purchase and configure the CyberGate service, see our Tech
Note: ‘Connect a SIP Intercom to MS Teams using the CyberGate service’. !
gf2
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
2
AXIS Network Video Doorstation
For this document the AXIS A8105-E Network Video Doorstation (from now on named ‘AXIS’) is
used to connect to the CyberGate service (from now on named ‘CyberGate’).
This manual also applies to the following Axis Video Doorstations:
• Axis A8004-VE
• Axis A8207-VE
• Axis I8016-LVE
Follow the next steps to configure the AXIS to connect it to CyberGate.
Connect the AXIS
Connect the AXIS to the network, power it on and open a webbrowser to its IP-address.
Create a password for the ‘root’ user and click ‘OK’
Login as ‘root’ with the just created password
gf3
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
3
Set the Capture Mode:
Set the used power line frequency:
When logged-in, the live view opens
gf4
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
4
At the top, click ‘Setup’
Click on ‘Date& Time’ to set the correct Time zone.
Click the Save button to confirm.
gf5
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
5
Click on ‘VoIP Settings’ and at Account settings ‘Configure’
Remove the default ‘peer-to-peer entry with ‘Remove’, after that add a new entry by clicking on
‘Add’
gf6
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
6
Provide the following information:
Name Name of the SIP account, in this example ‘CyberGate’
Default account Enable by checking the checkbox
User ID Use the Username provided by the CyberGate service
Authentication ID Will be the same as the User ID
Password Use the Password provided by the CyberGate service
Caller ID Use the Username provided by the CyberGate service
Domain name Use the domain name of your organisation
Register address cybergate.cybertwice.com
Click the Save button to confirm.
gf7
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
7
Click ‘Network’ to set the SIP connection parameters
By default it uses UDP to connect to CyberGate. You can change it to TCP when needed.
To establish a secure connection to CyberGate, modify the following settings:
Transport Mode Change to TLS
Media Encryption Change this to SRTP Mandatory
Click the Save button to confirm.
These settings ensure that the SIP traffic and the audio / video are encrypted.
gf8
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
8
Click ‘Video’ to set the video parameters for SIP
Set the Resolution to 720p and set the View area to Landscape.
Click the Save button to confirm.
gf9
Configure the AXIS Network Video Doorstation for the CyberGate serviceCyberTwice
9
Click on ‘SIP Settings’ and enable SIP by checking ‘Enable SIP’’:
Click the Save button to confirm.
