Overview
Back View
VIDEO L-IN
HDMI
POWER
R-IN
PC AUDIO IN
POWER
Headphone
VIDEO L-IN R-IN
PC AUDIO IN
HDMI1 HDMI2
HDMI3
Headphone
POWER: Connect to the power.
HEADPHONE: Connect it to your headphone or other audio equipment.
Video:Connect it to video output terminal of DVD.
L/R in: Connect them to audio output terminals of DVD, shared with YPbPr.
PC AUDIO IN:Connect it to the audio output terminal of PC.
VGA: For PC display. Connect it to the D-Sub 15 pins analog output connector of the PC.
HDMI1/2/3:&RQQHFWWRRWKHUHTXLSPHQW
COAX:Digital output to AV receiver.
RF: Connect antenna or cable 75 Ohm coaxial to receive TV signal.
USB:USB jack for Recording and Media.
YPbPr: Connect them to the YPbPr video output terminal of DVD.
USB
COAX
COAX YPbPr
USB YPbPr
Model: AX15$;$;
POWER: Connect to the power.
HEADPHONE: Connect it to your headphone or other audio equipment.
Video:Connect it to video output terminal of DVD.
L/R in: Connect them to audio output terminals of DVD, shared with YPbPr.
PC AUDIO IN:Connect it to the audio output terminal of PC.
VGA: For PC display. Connect it to the D-Sub 15 pins analog output connector of the PC.
HDMI:Connect WRother equipment.
COAX:Digital output to AV receiver.
RF: Connect antenna or cable 75 Ohm coaxial to receive TV signal.
USB:USB jack for Recording and Media.
YPbPr: Connect them to the YPbPr video output terminal of DVD.
Model: AX132
