The AX50 access control kit is a
compact, standalone single door
controller supplied with a proximity
reader with keypad, controller and
cards.
Presenting the wireless smart card
within 10cm (4”) of the slimline reader
or entering the individual PINcode,
automatically verifies the unique code
and opens the door if access is allowed
for the individual.
The mullion-style reader is
weatherproof, easy to install and fixed
with the security screws supplied,
allowing installation
even in the toughest
environments.
The program card
included, prevents
unauthorised
system changes—
cards can easily be
individually added
and deleted using the built-in keypad.
Standalone Access
Control for 1 Door
AX50 Kit Contents
1 AX50 Controller
1 Proximity & PIN Reader
10 Wireless Smart Cards
1 Program Card
1 Fixing Kit
1 Manual
September 2003
AX50 Features
500 cardholders/users
Request to exit input
Card only and/or PIN only
Fast block load of cards
Controller unit on secure side of the
door
Quick to install and easy to program
using the keypad
27-28 Shrivenham Hundred Business Park, Watchfield, Swindon,
Wiltshire SN6 8TZ United Kingdom
Tel: +44 (0)1793 784002
Fax: +44 (0)1793 784005
Website: www.axxessid.com
Additional Products Available
Distributor:
AX Proximity Key Fob
part no. 205-221
Proximity key fob for use
with AX Proximity and
Keypad readers.
Sold in packs of 10.
Dimensions: 35 x 7.5mm
AX ISO Proximity Cards
part no. 205-220
ISO proximity cards for use with
AX Proximity and Keypad
readers.
Suitable for photo ID printing.
Sold in packs of 10.
Dimensions: 85.4 x 54 x 0.8mm
Dimensions & Power Requirement
Controller
Steel powder-coated white face plate
87 x 87 x 28 mm (3.43 x 3.43 x 1.18”)
12VDC 45mA
White ABS housing
87 x 115 x 30 mm (3.43 x 4.53 x 1.18”)
Proximity & PIN Reader
White ABS housing
119 x 40 x 17 mm (4.69 x 1.57 x 0.67”)
12VDC 45mA
Warranty Period
The equipment is guaranteed against defects in
materials and workmanship for 5 years from date of
shipment (see warranty policy for details).
Part Numbers
AX50 Kit 105-050
Power Supply 12vDC 1AH 105-316
AX ISO Proximity Cards 205-220
AX Proximity Key Fob 205-221
proximity & PI N
reader
proximity cards
request to exit
pushbutton
part no. 999-252
power supply
part no. 105-316
electric strike or
magnetic lock
part no. 310-208
or 308-121
AX50 controller
6 core 24AWG0.22m²
2 core 24AWG0.22m²
Maximum length: 50 metres (165 ft)
