USERS MANUAL
ALL WEATHER 8.4” - 15.0”
IP67 SEALED SERIES
MILITARy GRADE
PANEL MOUNT
ARM MOUNT
LCD Monitor User Guide
Part No. 150-7000-002
2150-7000-002
Table of Contents
Introduction.............................................................................. 3
Safety ..................................................................................... 4
Product Care and Maintenance.................................................... 6
System Set-up .......................................................................... 8
Installation ............................................................................... 9
Display Connections ................................................................ 11
Computer Hook-up .................................................................. 13
Operator Controls.................................................................... 16
On-Screen Display (OSD) ......................................................... 17
Optional Touch Screen............................................................. 21
Appendix A - Mechanical Drawings .......................................... 28
Appendix B - Troubleshooting ................................................... 28
Appendix C -Technical/Environmental Specications.................... 31
150-7000-002 3
The Aydin MIL-Spec Monitor is a ruggedized marine grade LCD Display for use
with a conventional RGB computer input. It is designed to operate under the
most extreme environments found in high performance vessels such as public
safety, government and military marine craft, as well as submarine vessels. The
ruggedized displays are capable of operating in environments that include extended
temperatures, extreme shock and vibration, direct exposure to salt water and other
environmental conditions.
Housed in a milled billet aluminum case, the slim-prole model is light weight and
watertight, with fully sealed, military grade connectors. Front-mounted controls and
various mounting options makes this a user-friendly display.
This model incorporates the latest optical engineering to achieve optimal viewability
in all lighting conditions.
It is engineered to operate on low power consumption, and may be equipped with
optional Analog Resistive Touch Screen. This manual contains instructions for
conguring the touch screen as well.
Welcome.
4150-7000-002
SAFETY
General Safety Instructions
• Before operating this Monitor, read this User Manual thoroughly
• Retain this User Manual for future use
• Verify the computer system capability (see System Set-up) to insure operation of
the Monitor
• For expeditious installation, follow these User Manual instructions in the
sequence presented
• Adhere to all Caution and Warnings on system parts and as stated in this User
Manual
• All User Manual instructions for installation and operation must be followed
precisely
• Adjust only those controls covered by the User Manual’s operating instructions;
improper adjustment of other controls voids the unit’s warranty and may result in
unit damage, and
• Adhere to local installation codes.
General Unit Safety
• Always disconnect the unit from the power source before cleaning
• Do not operate the unit with a damaged cord
• Do not operate if the unit has been dropped or damaged. The unit needs inspected
by qualied Aydin Service Personnel
• Position the power cord so it shall not be in contact with hot surfaces
• Do not allow anything to rest on the power cord, and
• Do not place the power cord where there shall be foot trafc.
General Safety Precautions
• Power cord must be connected to a properly wired and grounded power source
• Any equipment to which the unit shall be attached must also be connected to properly
wired and grounded power sources
• Do not connect or disconnect the unit during an electrical storm
• Do not remove the unit covers – there are no user serviceable parts in the unit
• Do not disassemble or modify the unit to avoid the possibility of electrical shock,
damage to electrical components or scratching the Display surface, and
• Disassembly of the unit voids the warranty.
warning!
caution!
Warning! Shock Hazards
This icon is intended to tell you of a potential risk of electrical shock.
Caution! Instructional
This icon is intended to tell you of important operating and/or
maintenance instructions.
Safety Icons
warning!
150-7000-002 5
Electrical Safety
Connecting Cables
• Disconnect the power to the computer when the Monitor is being installed, and
• Upon installation, verify the power connector is securely seated on the unit.
Ratings and Grounding
This unit may be operated from an 8-36 VDC power source.
• Use the supplied power cable, and
• Always connect to a properly grounded power source.
Protection on Servicing
Servicing - User
• User care is limited to cleaning the exterior of the unit.
• Do not disassemble or modify the unit or cables to avoid the possibility of an
electrical shock, damage to electrical components or scratching the
Display surface, and
• Disassembly voids the warranty.
Servicing
Aydin Displays Qualied Service Personnel may be required if the unit:
• Does not operate normally when installation instructions are followed
• Does not operate normally when operating instructions are followed
• Has been dropped or damaged, or
• Exhibits a distinct change in performance, indicating a need for service.
Shipping
If the unit should need to be shipped to the Aydin Displays Service Center, the original
packing material should be used to insure safety in shipping. Repack the unit as it
would have originally been received from Aydin Displays.
Fluids from LCD Display
• If the Monitor should ever become shattered, do not touch uids from an LCD Display
• If uid should get on hands or clothing, immediately wipe off with liquid soap or rubbing
alcohol; wash with water; consult with a doctor, and
• If uid gets in the eyes, ush eyes immediately with water for a minimum of 15 minutes;
consult with a doctor.
This equipment generates, uses and can radiate radio frequency energy. If not
installed with the unit’s accompanying cables, it may cause harmful interference
to radio communications.
Radio Frequency Interference
caution!
caution!
6150-7000-002
This monitor has been designed to provide optimum performance and service without
any required scheduled maintenance other than occasional cleaning.
Display Screen Cleaning
• A vinegar-based cleaner is preferred to prevent streaking and degradation of the
coatings, or
• A non-abrasive glass cleaner such as a professional foam glass cleaner
• Apply the cleaning solution to a soft clean cloth, dampening slightly
• Keep a fresh side of the cleaning cloth towards the screen surface to avoid
scratching it with accumulated grit, and
• To minimize the risk of abrasion to the screen, air drying is recommended.
Disconnect cabling from the Touch Screen Display before cleaning. A Touch Screen
Display will be activated by cleaning the Display. This may create a potentially
dangerous condition.
Optional Touch Screen Cleaning
• Follow cleaning directions above, or use a special screen cleaning tissue or a
solution specically formulated for antistatic coatings.
• Lightly dampen a soft clean cloth with water, vinegar based cleaner or a general
purpose mild detergent solution
• Keep a fresh side of the cleaning cloth towards the screen surface to avoid
scratching it with accumulated grit, and
• To minimize the risk of abrasion to the screen, air drying is recommended.
Monitor Enclosure
• Clean the unit enclosure with a soft clean cloth lightly dampened with a
general purpose mild detergent solution
• To rinse, wipe down with clean water, and
• Dry with a soft clean cloth.
Optional Touch Screen
PRODUCT CARE AND MAINTENANCE
Product Care
• Do not use abrasive cleaners or solvent-based (ammable) cleaners on the
Flat Panel or Touch Screen Display, its enclosure or any other electrical de-
vice (cables, power cord, etc)
• Do not use paper products as they may scratch the Display screen, and
• Do not directly apply cleaning solutions to the Display screen.
Turn off the Monitor power before cleaning the Monitor, optional Touch Screen
or unit’s enclosure.
warning!
caution!
warning!
In marine or similar environments,
an added benet of a vinegar-based
cleaner is its effectiveness in
dissolving salt deposits.
150-7000-002 7
To avoid risk of electrical shock, do not disassemble the unit’s enclosure. Users
cannot service the Monitor. User maintenance is restricted to cleaning, as ex-
plained. Disassembling the unit voids the warranty.
Long-term Storage
• For long-term storage, it is suggested the unit be stored in a normal indoor environ-
ment and the Display glass be protected from accidental damage.
• For pedestal mount units, disconnect the cable(s) and loosen the arm adjustment to
a point where the ball can be removed from the arm, or
• For Flush or Panel Mount units, cover the product with a protective covering that
shall not scratch or transfer any dyes to the Display screen.
Maintenance
Other Maintenance
Only Aydin Qualied Service Personnel shall perform all maintenance except for the
power cord replacement described above.
To avoid shock and re hazards, replaced the unit’s power cord if:
• Insulation becomes damaged, or
• A loose connection is suspected.
Power Cord
warning!
warning!
8150-7000-002
SYSTEM SET-UP
System Requirements
The computer must have this capability:
8.4=800 x 600 (SVGA)
10.4=1024 x 768 (XGA)
12.1=1024 x 768 (XGA)
15.0=1024 x 768 (XGA)
• If the optional Touch Screen Display is ordered, an available COM port for the
connector is required.
Shipping Box Contents
The display is shipped in a custom box with custom foam packaging. We
recommend you save the box and all packaging materials in case the unit would
need to be returned to the Aydin Displays Service Center.
In the shipping box you shall nd:
• CFP 8.4, 10.4, 12.1 or 15.0
• Custom Power Cable
• Custom VGA Cable
• Mounting System and Hardware
• Touch Screen Cable if the optional Touch Screen is ordered
• USB Cable if the optional USB Pass-through is ordered, and
• Optional Touch Screen Drivers (located on Aydin website)
Figure 1
150-7000-002 9
INSTALLATION
The display is designed to be mounted with a universal ball-and-socket mounting kit,
in a at panel or optional ush mount conguration.
Optional Pedestal Mount
The display can be supplied with a RAM® universal ball-and-socket system mounting
kit (Figure 2). By installing the monitor with this kit, the user can quickly adjust the
viewing angle to improve viewability in changing environments. This ball-and-socket
system has proven to be successful in supporting an extreme amount of weight in
high vibration and difcult-mount applications.
Locate the ball-and-socket system in the shipping box. The kit consists of two RAM
balls on mounting plates and a RAM arm, with an adjustable T-knob and a packet of
three (3) M4 x 10 counter-sunk stainless screws for mounting to the display.
Figure 2
Figure 3 Figure 4
Mounting Holes
10 150-7000-002
There are three mounting holes in the back of the Monitor for the ball mounting plate.
Take care not to strip the screw holes or over tighten. (Figure 4)
• Line up one of the ball mounting plates on these three holes (Figure 4)
• With three (3) M4 x 10 counter-sunk stainless screws attach this mounting plate to
the back of the unit.
• Mount the second ball mounting plate where the Monitor shall be installed
• Insert each ball into the RAM arm
• Lightly tighten the arm around the balls using the T-knob on the arm (Figure 2, 4)
• Adjust the Monitor to the viewing preference, and
• Tighten the T-knob to hold the Monitor in position.
It is recommended the remaining ball be mounted on a at surface. Because of the
various surface substrates the Monitor shall be mounted on, the installer shall provide
the screws to mount the other ball.
Panel Mount
The panel mount installation should be specied at the
time of order; the ball-and-socket mount system will
not be included in the shipping box.
The mounting hardware packet is included with the unit
accessories in the shipping box. This packet includes
four (4) threaded screws (approximately 7.6 cm [3”]
long), four (4) Nylock nuts and four (4) at washers.
For installation, there are four tapped mounting holes
on the four corners of the unit’s rear panel.
Take care not to strip the
screw holes or over tighten
as the enclosure is aluminum.
caution!
Figure 5
Andere Handbücher für IP67 SERIES
1
Inhaltsverzeichnis
Andere Aydin Displays Monitor Handbücher
Aydin Displays
Aydin Displays PROFORMANCE 4418 Bedienungsanleitung
Aydin Displays
Aydin Displays LCD Monitor Bedienungsanleitung
Aydin Displays
Aydin Displays VFP20 series Bedienungsanleitung
Aydin Displays
Aydin Displays Cambridge CFP42W1 Bedienungsanleitung
Aydin Displays
Aydin Displays VFP19R2-000-602 Bedienungsanleitung
Aydin Displays
Aydin Displays VFP20 series Bedienungsanleitung
Aydin Displays
Aydin Displays CFP24W2 Series Bedienungsanleitung
Aydin Displays
Aydin Displays CAMBRIDGE CFP19 Series Bedienungsanleitung
Aydin Displays
Aydin Displays Cambridge Bedienungsanleitung
Aydin Displays
Aydin Displays CFP32W1 Large Screen Series Bedienungsanleitung
Aydin Displays
Aydin Displays 356-7040-501 (model 4424S) Bedienungsanleitung
Aydin Displays
Aydin Displays IP67 SERIES Bedienungsanleitung
Aydin Displays
Aydin Displays CFP Series Bedienungsanleitung
Aydin Displays
Aydin Displays VFP15 series Bedienungsanleitung
Aydin Displays
Aydin Displays VFP19R2 Bedienungsanleitung
