B2 electronic BA60 Bedienungsanleitung

E N G L I S H

DHV0017 Rev12

b2 electronic GmbH

Riedstraße 1

6833 Klaus

AUSTRIA

Tel. +43 5523 57373

Fax + 43 5523 57373-5

www.b2hv.com

[email protected]

Subject to alterations –

errors excepted

Illustrations are not binding

BA60/75/80/100

User Manual

Breakdown Analyzer for

Insulating Oil

Introduction
DHV0017 b2 EN © b2 electronic GmbH
Table of Contents
1INTRODUCTION...................................................................... 3
1 Regarding this Document ..................................................................3
2 Documentation Conventions .............................................................4
3 Legal Considerations .........................................................................5
2SAFETY................................................................................... 7
1 Work Safety .........................................................................................7
2 Appropriate Applications ...................................................................8
3GENERAL DESCRIPTION ...................................................... 9
1 Technical Specifications ....................................................................9
2 Design Features ................................................................................11
3 Materials.............................................................................................12
4UNPACKING THE INSTRUMENT ......................................... 17
5DESIGN AND CONSTRUCTION ........................................... 18
1 Instrument Layout.............................................................................18
2 Instrument Set-up .............................................................................20
6SOFTWARE –REMOTE CONTROL ..................................... 25
7TEST PROCEDURE .............................................................. 26
1 Test Environment Criteria ................................................................26
2 Sample Selection and Handling ......................................................26
3 Instrument Connection.....................................................................27
4 Instrument Activation .......................................................................28
5Test Vessel Preparation ...................................................................28
6 Standard Test Execution ..................................................................29
7 Single Test Execution.......................................................................31
8 Withstand Test Execution ................................................................33
9 Error Messages .................................................................................35
10 Report.................................................................................................37
11 Instrument Disconnection and Termination ..................................40
8INSTRUMENT CARE............................................................. 41
1 Update ................................................................................................41
2 Installing Printer Paper Roll.............................................................41
3 Replacing Printer Ink Ribbon...........................................................43
4 Charging Internal Battery.................................................................45
5 Storage/Repairs.................................................................................45
9GLOSSARY AND ABBREVIATIONS .................................... 46
DECLARATION OF CONFORMITY....................................... 47

1 Introduction

©b2 electronic GmbH DHV0017 b2 EN 3

1 Introduction

Purpose

This Operating Manual serves to ensure the proper and safe use of

the Breakdown Analyzer (BA) for Oil.

This is only an Operating Manual, not a Software Manual.

1.1 Regarding this Document

Target User

This operating manual is designed to inform various user groups. The scope

and depth of the information provided may not be appropriate for all users.

However, it is important that all users familiarize themselves with this document

in full. The following is a guideline indicating the most significant information as

a function of the user’s responsibilities.

User

Responsibilities

Focus

BA Operator

•To adjust the BA instrument settings.

•To handle test liquid samples,

sample containers and test vessels

appropriately.

•To connect the BA test equipment.

•To carry out BA tests.

•To verify validity of BA application.

All Sections

Particular focus on all

safety messages

Procurement,

Management

•To assure that liquid test samples are

selected and handled appropriately.

•To assure that the workplace is safe

and has all required equipment.

•To assure that BA operators are

qualified technicians.

•To assure that operators fulfil their

responsibilities.

Particular focus on safety

messages and information

regarding general product

description.

Safety

NOTICE

This manual should always be on hand when using the BA test instrument.

1 Introduction

4 DHV0017 b2 EN © b2 electronic GmbH

1.2 Documentation Conventions

The following explain the symbols and safety messages found in this

document. The employment of safety symbols and signal words are

according to the DIN EN ISO 7010: 2012-10

Safety Messages

Symbols

DANGER

Indicates a hazardous situation which if not avoided will result in death or

serious injury.

WARNING

Indicates a hazardous situation which if not avoided could result in death or

serious injury.

CAUTION

Indicates a hazardous situation which if not avoided could result in minor or

moderate injury.

NOTICE

Indicates suggested practices to protect equipment and property.

Yellow triangle, framed in black: Used to indicate a potential hazard.

Only used in conjunction with description of the possible hazard!

Detailed symbol may correspond to this specific hazard.

Red outlined circle with red diagonal line: Used to indicate forbidden practices.

The described handling practice must not be carried out!

Blue circle with white exclamation mark: Used to indicate recommended

precautionary measures or a situation that can lead to property damage.

1 Introduction

©b2 electronic GmbH DHV0017 b2 EN 5

1.3 Legal Considerations

Warranty

b2 electronic GmbH provides an one-year warranty from the original purchase

date of instrument for all necessary parts and labor. This warranty is void in the

event of abuse, incorrect operation or use, unauthorized modification or repairs,

or failure to perform the specified maintenance as indicated in this operation

manual. This warranty does not include normal consumable items such as

lamps, paper rolls, printer ink ribbons, batteries or other auxiliary items.

This warranty and our liability are limited to replacing or repairing defective

equipment, at our discretion. Equipment that is returned to b2 electronic GmbH

must be packed in original packaging. All shipped items must be prepaid and

insured. No other warranties are expressed or implied.

Contact Information

b2 electronic GmbH

Riedstraße 1

6833 Klaus

Vorarlberg, Austria

T: +43 5523 57373

F: +43 5523 57373-5

www.b2hv.com

[email protected]

No part of this publication may be reproduced, transmitted, stored,

or translated in hardcopy or electronic form without the written consent

of b2 electronic GmbH.

Your opinion matters!

Your comments and suggestions are of value. We are dedicated to

supporting your needs. Offering you optimal documentation is part of

our promise of quality.

Improvement suggestions regarding this manual may be sent to:

[email protected]

Thank you for your feedback!

1 Introduction

6 DHV0017 b2 EN © b2 electronic GmbH

b2 Customer Portal –customers.b2hv.com

and product data base.

The b2 Customer Portal is reserved for b2 electronic customers.

Submit the registration and find:

•Information about meetings and training sessions

•Documents and manuals

•New soft- or firmware versions

•Support and service requests

•Send messages

•Request newsletters

2 Safety

©b2 electronic GmbH DHV0017 b2 EN 7

2 Safety

Safety is priority! Respect all safety information indicated in this manual. Only

use the BA test instrument for appropriate applications. Ensure that BA opera-

tors are qualified technicians that understand the scope of their responsibilities.

2.1 Work Safety

NOTICE

Before carrying out any test with this instrument, read this Operating Manual

in its entirety.

WARNING

Electric Potential

Never assume that equipment is safe to handle without using the necessary

safety precautions.

•All procedures must comply with local safety regulations.

•Always ground the equipment prior to operation with an external power

supply and ensure that earth connections are made first and removed last.

•All equipment must be inspected for damage before use. Damaged

equipment must not be used.

•Avoid testing alone. In the event of an emergency another person’s

presence may be essential.

WARNING

Unauthorized Equipment Modifications

Unauthorized equipment modifications may lead to hazardous situations.

•Do not install substitute parts or make unauthorized modifications to the

test instrument and accessories.

•Test instruments must only be repaired or modified by authorized

b2 personnel.

WARNING

Flammable Materials

Improper handling and selection of test liquids and other solvents may

result in fire.

•Do not test liquids with flash points < 110 °C (230 °F)!

•The test vessel and electrodes must be free from cleaning solvents

before performing any high-voltage test.

WARNING

Toxic Materials

Cleaning solvents and oil samples must be handled and disposed of

according to manufacture indications.

2 Safety

8 DHV0017 b2 EN © b2 electronic GmbH

Improper handling of the BA test equipment may lead to material damage.

•Always unpack and store the BA test equipment according to the

instructions of this manual.

Improper handling of test vessels, oil and electrodes may lead to test sample

contamination and result in inaccurate test results.

•Never touch the electrodes with bare fingers.

•It is recommended to wear powder-free latex, nitrile surgical gloves or

equivalent when handling test vessels, oil and electrodes.

2.2 Appropriate Applications

The BA test instrument is designed to automatically test the breakdown strength

of liquid dielectrics.

Test Liquids

Insulating oils used in electrical apparatus such as transformers, tap changers,

circuit breakers, cables etc. are appropriate test liquids. Test liquids with boiling

points below 110 °C (230 °F) are not appropriate!

Test Methods

Test methods for determining the breakdown strength of liquid dielectrics are

specified by various international standards organizations. The appropriate

procedures, hardware and reporting requirements are specified in different

standards e.g. (IEC, VDE and ASTM, etc.)

The number of tests to be performed, voltage rise-rate, timing sequences, test

vessel and electrode configuration, test limits and ranges specified by certain

standards are pre-programmed in the BA test equipment. Refer to the section

“Technical Description” for a list of the automatic test standards applicable for

this BA instrument.

It is the responsibility of the BA instrument user to follow appropriate liquid

filling procedures and to set gap spacing of the electrodes according to the

selected standard.

NOTICE

3 General Description

©b2 electronic GmbH DHV0017 b2 EN 9

3 General Description

3.1 Technical Specifications

Characteristic

BA60

BA75

Article Number

SB5002

SB5001

Output Voltage [max.]

60 kV rms

75 kV rms

Measurement accuracy

±1 kV

Voltage slew rate

0.5 kV/s –10 kV/s

Resolution (displayed)

0.1 kV

Power Supply

85 V –264 V (47 Hz –63 Hz)

12 V external supply

Power Consumption

75 VA

Internal Rechargeable

Battery

Not applicable

1 x 12 V / 7.2 Ah,

12 h continuous

Switch-off Time on Flashover

< 5 μs

Oil Temperature

0 °C to 100 °C

Temperature resolution

1 °C

Display

2.8" colour

Pre-programmed test standard *available on PC via BA ControlCenter.

AS 1767.2.1*

ASTM D 1816-04-1*

ASTM D 1816-04-2*

ASTM D 1816-12 : 1/2

ASTM D 877-02A*

ASTM D 877-02B*

ASTM D 877M-13 A/B

BS EN 60156

CEI EN 60156

CSN EN 60156/95

GOST 6581-75

IEC 60156:95

IP 295*

IP 295/83-2005

IRAM 2341/72*

JIS C 2101/78

MSZ 20880/74-1*

MSZ 20880/74-2*

MSZ 20880/74-3*

NBN C 27-002*

NBN C 10 156*

NF EN 60156*

ÖVE EN 60156

PA SEV EN 60156*

PN 77

PN 77/E-04408*

RVHP 1985*

SABS EN 60156*

SABS 555

UNE 21 309/70*

UNE EN 60156*

UTE C27-221/74*

VDE 370-5/96

User specific programs

Unlimited

software

BA ControlCenter

Integrated Printer

Not applicable

Graphical output 44 mm

(dot matrix)

Printer paper

Not applicable

Standard 44 mm wide roll

Interface

Bluetooth®, USB memory stick

Operating Temperature

-10 °C to +55 °C**

Storage Temperature

-20 °C to +60 °C

Relative Humidity

non condensing

Weight (batteries included)

19 kg

22 kg

Dimensions L x W x H (mm)

430 x 280 x 250

Note: b2 electronic GmbH reserves the right to modify values in accordance with future BA development.

**extended temperature range

3 General Description

10 DHV0017 b2 EN © b2 electronic GmbH

Characteristic

BA80

BA100

Article Number

SB5003

SB5004

Output Voltage [max.]

80 kV rms

100 kV rms

Measurement accuracy

±1 kV

Voltage slew rate

0.5 kV/s –10 kV/s

Resolution (displayed)

0.1 kV

Power Supply

85 V –264 V (47 Hz –63 Hz)

12 V external supply

85 V –264 V (47 Hz –63 Hz)

12 V external supply

Power Consumption

75 VA

Internal Rechargeable

Battery

1 x 12 V / 7.2 Ah,

12 h continuous

1 x 12 V / 7.2 Ah

12 h continuous

Switch-off Time On Flashover

< 5 μs

Oil Temperature

0 °C to 100 °C

Temperature resolution

1 °C

Display

2.8" colour

Pre-programmed test standard *available on PC via BA ControlCenter.

AS 1767.2.1*

ASTM D 1816-04-1*

ASTM D 1816-04-2*

ASTM D 1816-12 : 1/2

ASTM D 877-02A*

ASTM D 877-02B*

ASTM D 877M-13 A/B

BS EN 60156

CEI EN 60156

CSN EN 60156/95

GOST 6581-75

IEC 60156:95

IP 295*

IP 295/83-2005

IRAM 2341/72*

JIS C 2101/78

MSZ 20880/74-1*

MSZ 20880/74-2*

MSZ 20880/74-3*

NBN C 27-002*

NBN C 10 156*

NF EN 60156*

ÖVE EN 60156

PA SEV EN 60156*

PN 77

PN 77/E-04408*

RVHP 1985*

SABS EN 60156*

SABS 555

UNE 21 309/70*

UNE EN 60156*

UTE C27-221/74*

VDE 370-5/96

User specific programs

Unlimited

software

BA ControlCenter

Integrated Printer

Graphical output 44 mm

(dot matrix)

Graphical output 44 mm

(dot matrix)

Printer paper

Standard 44 mm wide roll

Interface

Bluetooth®, USB memory stick

Operating Temperature

-10 °C to +55 °C**

Storage Temperature

-20 °C to +60 °C

Relative Humidity

non condensing

Weight (batteries included)

22 kg

32 kg

Dimensions L x W x H (mm)

430 x 280 x 250

521 x 343 x 300

Note: b2 electronic GmbH reserves the right to modify values in accordance with future BA development.

**extended temperature range

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere b2 electronic Prüfgeräte Handbücher

b2 electronic

b2 electronic PD Series Bedienungsanleitung

Beliebte Prüfgeräte Handbücher anderer Marken

SMART

SMART KANAAD SBT XTREME 3G Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies BERT Serial Bedienungsanleitung

Agilent Technologies

Agilent Technologies N3280A Bedienungsanleitung

Vernier

Vernier Go Direct Voltage Bedienungsanleitung

Lifeloc

Lifeloc R.A.D.A.R. Bedienungsanleitung

Fluke

Fluke T5-600 Bedienungs- und Montageanleitung

Mercury

Mercury TSL01 Bedienungsanleitung

MAHA

MAHA MBT Series Bedienungsanleitung

Fuji Electric

Fuji Electric P-61 Bedienungsanleitung

ETC

ETC SealerAtor Bedienungsanleitung

Skyfine

Skyfine ETHYWAY V2 Bedienungsanleitung

Appion

Appion G5 Twin Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 8159-0112A Bedienungsanleitung

BW Technologies

BW Technologies MicroDock II Bedienungsanleitung

Sun Nuclear

Sun Nuclear 1027 Bedienungsanleitung

Biomark

Biomark HPR LITE READER Bedienungsanleitung

Hioki

Hioki 3169-20 Bedienungsanleitung

Ashcroft

Ashcroft ATE-100 Bedienungsanleitung

b2 electronic BA60 Bedienungsanleitung

Beliebte Prüfgeräte Handbücher anderer Marken
