Barco Galaxy NH-12 Bedienungsanleitung

www.barco.com

Barco’s ground-breaking 1080p HD, three-chip DLP NH-12 projector offers a wide

variety of options to its end users. With its bright light output and excellent color

quality, it is an outstanding choice for large-sized meeting rooms, boardrooms and

auditoriums in a diverse number of markets. Some of the NH-12’s most eye-catching

features include:

•12,000 lumens light output and a 2,000:1 contrast ratio

•Full 1080p HD resolution

•Liquid-cooled, sealed optical engine

The NH-12 also comes equipped with native multi-channel features, to allow for easy,

flexible integration into a high-resolution display system.

Barco’s NH-12 can be optionally readied for Windows desktop integration with spe-

cially engineered, user-friendly Barco software. This results in the following benefits:

•Windows desktop integration

•Simultaneous display of all local and networked sources

•Easy source and layout selection through the Start Menu

•Mouse and keyboard control

•Remote diagnostics and centralized maintenance

NH-12

1080p HD, 12,000 lumens three chip DLP projector

with optional multi-windowing software

www.barco.com

R5990083 March 2008

DLP™ technology by Texas Instruments offers crystal

clear images with superior quality.

DLP is a trademark of Texas Instruments.

The information and data given are typical for the equipment described.

However any individual item is subject to change without any notice.

The latest version of this product sheet can be found on www.barco.com.

NH-12 technical specifications

EMEA & ROW

Noordlaan 5

8520 Kuurne - Belgium

Tel. +32 56 36 82 11

Fax +32 56 36 85 26

Barco

Presentation & Simulation Division

contact.bps@barco.com

USA

600 Bellbrook Avenue

Xenia, OH 45385-4053

Tel. +1 (937) 372-7579

Fax +1 (937) 372-8645

APAC

7F, FenYang Road 138

200 031 Shanghai - China

Tel. +86 21 5465 5501

Fax +86 21 5465 5502

Inputs and outputs

Standard inputs

1x 5-BNC (RGBHV, RGBS or RGBsB)

1x Composite video (BNC)

1x S-Video (4-pin mini DIN)

1x DVI

1x VGA (D15)

Optional inputs (2 free layers)

See order information

Communication ports

RS232 (on D9)

IR or wired remote

10/100 Mb/s Ethernet (on RJ45)

Compatibility

Video

PAL, SECAM, NTSC signals

Composite, S-video, component or RGB formats

All current HDTV standards (720i, 720p, 1080i, 1080p)

Data

All computer graphics formats up to QXGA @ 75Hz

Analog sources with a pixel clock of up to 270 MHz

DVI sources with a pixel clock of up to 165 MHz

Safety

Safety standards

ETL60950 and EN60950

CE compliant

CCC compliant

Power

AC power

200 - 240 VAC/50-60 Hz

Max. power consumption / dissipation

2,800 Watt / 9,560 BTU

Order info

NH-12 R9010610

New 2kW lamp R9843080

Refurbished lamp R9843090

QXGA RGBHV input board R9843020

DVI/D15 input board R9843030

SDI/HD-SDI input board R9843040

Display capabilities

Light output

12,000 lumens (+/- 10%)

Contrast

2,000:1

Resolution

Full 1080p HD (1,920x1,080)

Chip technology

Sealed and liquid cooled three-chip DLP

Lamps

Lamp

2 kW Xenon

Lamp warranty

750 hrs warranted, max. 1000 hrs

Dimensions

Weight

70 kg (154.2 lbs) net - 85 kg (187.4 lbs) shipping weight

Height - width - length

345 / 590 / 913 mm

13.58

” /

23.22

” /

35.94

”

Lenses

Available zoom lenses

TLD HB (1.6-2.0:1) R9842060

TLD HB (2.0-2.8:1) R9842080

TLD HB (2.8-5.0:1) R9842100

TLD HB (5.0-8.0:1) R9842120

Available fixed focal lenses

TLD HB (0.8:1) R9842040

TLD+ (1.2:1) R9840775

Lens shift range

Horizontal shift up to +/- 65%

Vertical shift up to +/- 100%

Desktop integration

XDS Control Center R9898420

XDS Networked Desktop Sharing R9898430

XDS Extended Mouse & Keyboard Control R9898450

XDS Remote Control Center R9898440

XDS Videoconferencing Control R9898460

XDS Remote Administration R9898480
