HDXW14

14,000 lumens, WUXGA, 3chip DLP projector

With the HDX series, Barco brings its

expertise in 3D projection to events. The

HDXW14 combines active 3D and both

wired and wireless control options in one

unit. The success of the FLM event

projectorshave added considerably to the

design of the HDX projector, while it also

shares image processing and AthenaTM

scaling technology with Barco's benchmark

image processing hardware.Its sturdy,

compact design allows the HDXW14 to be

ready for the road in no time, while its

14,000 lumens light output and 3chip DLP

color quality ensure crisp, vivid imagery on

anyscreen.

Quickpreviewandwirelesscontrol

TheHDX'sbuiltincolorLCDscreenprovidesyouwithalltheinformationyou

need on your projector's status, and allows you to preview your connected

sources. The projector has a native 3G HDSDI/SDI input, which makes it

compatible with progressive sources over a single BNC cable. In addition, it

offersquickandwirelesscontrolviasmartphonesandtabletcomputers.

Simplesetupandmaintenance

Barco designed the HDXW14 with efficiency and quick setup in mind. Its

featuresjustfivebuildingblocksthatcanberemovedandreplacedquickly,so

thattimespentservicingtheprojectoriskepttoabareminimum.Inaddition,

itcaneasilybeboxed,shippedandfitsintostandardflightcases.

HDXW14

14,000 lumens, WUXGA, 3chip DLP projector

Fastsignaldistribution

Our proprietary BarcoLink technology guarantees swift signal distribution

betweenBarco’sprojectorsandimageprocessors.WithBarcoLink,signalsare

distributed over a BNC coax cable, which is not only more durable but also

enablesyoutoloweryourcosts.

Barco's HDX series won an InAVationAward for Most InAVative

CommercialProjector.

Technicalspecifications HDXW14

Projectortype WUXGA3chipDLPdigitalprojector

Technology 0.96"DMDx3

Resolution 1,920x1,200(WUXGA)

Lightoutput 13,000ANSIlumens/14,000centerlumens

Contrast 1,850:1(standard)/2,400:1(highcontrastmode)

Brightnessuniformity 90%(standard)

AspectRatio 16:10

ScenergiX Horizontalandverticaledgeblending

Lenstype TLD+

Lensrange 0.73:1;1.2:1;1.251.6:1;1.52.0:1;2.02.8:1;2.84.5:1;4.57.5:1;7.511.5:1

Opticallensshift Vertical:10%to+110%/Horizontal:30%to+30%onzoomlenses

(memorized)

Colorcorrection P7

Lamp 2.5kWxenon

Lamplifetime(typical) 1,750hours

Transportwithlamp Yes

Lamphouse,quickreplace Yes

Customerbulbreplace Yes

Lampwarranty(fieldreplace/factoryreplace) 90days,500hours/prorata750hours

SealedDLP™core Standard

Opticaldowser Standard

Pictureinpicture Uptotwosourcesonscreensimultaneously

Orientation tableceilingside(portrait)vertical

DMX512 Standard

WARP DirectadjustOSD+toolset

Integratedwebserver Yes

CLO(constantlightoutput) Standard

3D activeeyewear(optional),passiveInfitec(optional),passivecircular(optional),

tripleflashupto200Hz

Inputs DVII(HDCPincludinganalogRGBYUV),SDI/HDSDI/dualHDSDI/3G/BarcoLink

OptionalInputs 5BNCRGBHV(RGBS/RGsB,YUVCS/SOY,Compositevideo,SVideo);DVII

(HDCPincludinganalogRGBYUV)+BarcoLink/SDI/HDSDI/dualHDSDI/3G;3D

activeinputinput(HDMI/DisplayPort)feat.SENSIO3D

InputResolutions fromNTSCuptoQXGA(2,048x1,536)

Pixelclock 200MHz

Softwaretools ProjectionToolset+Androidapp

Control XLRwired,IR,RS232,DMX512in/out,integratedwebbrowser,Projection

Toolset

optionalcontroloverWiFiandGSM/mobile

Networkconnection 10/100Mb/sEthernet(onRJ45),WiFi

ACpower 200240VAC/5060Hz

Technicalspecifications HDXW14

Powerconsumption 2,600W/STBY

Noiselevel(typicalat25°C/77°F) 50dB(A)

Operatingtemperature 0~40°C/32~104°F

operationhumiditynocondens 080%

DissipationBTU max.8,871BTU/h

Dimensions(WxLxH) 475x725x382mm(18.7"”x28.54"x14.96")

Weight 50kg(110lbs)

ShippingDimensions (LxWxH)900x650x560mm(35.43"x25.59"x22.04")

Standardaccessories Powercord;wireless/XLRwiredruggedremotecontrol

Certifications CompliantwithUL609501andEN609501,complieswithFCCrules&regulations,

part15ClassAandCEEN55022ClassA,RoHS

Warranty 2yearsstandard,extendableupto5years

Generatedon:16Dec2013

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
