BaudTec G123USB Bedienungsanleitung
ADSL USB Modem
1
ADSL USB Modem
ADSL USB Modem
System Requirement
1. Pentium 200 MHz processor or above
2. Windows 98SE, Windows Me, Windows 2000, Windows XP and
Windows Vista.
3. 64 MB of RAM or above
4. 25 MB free disk space
Package Contents
For Annex-A ADSL USB Modem
1. ADSL USB Modem
2. CD-ROM (Software & Manual)
3. Quick Installation Guide
4. Telephone Cable (RJ-11)
5. USB Cable
6. Annex A ATF085A1R Splitter (Optional, with an extra RJ-11
Telephone cable)
For Annex-B ADSL USB Modem
1. ADSL USB Modem
2. CD-ROM (Software & Manual)
3. Quick Installation Guide
4. Telephone Cable (RJ-11)
5. USB Cable
6. Annex B ATF057R Splitter (Optional, with an extra RJ-11 Telephone
cable)
ComTW263R4
2
ADSL USB Modem
Connection of ADSL USB Modem
If you have an ISDN telephone line connected the router as shown below:
(Annex-B ADSL USB Modem)
**Use the “ATF057” Annex-B Splitter (Optional)
1. Connect the supplied USB cable from your PC's USB port to the ADSL
USB Modem.
2. Connect the supplied RJ11 telephone cable from your home's
telephone jack to the “LINE” port of the supplied ATF057 splitter.
Connect the other supplied RJ11 telephone cable to the “MODEM”
port of the splitter and connect the other end of this cable to the “LINE”
port of your ADSL USB Modem.
3. Connect a RJ11 telephone cable to the “PHONE” port of the splitter
and connect the other end to the telephone input.
3
ADSL USB Modem
If you have a PSTN telephone line (normal analog line) connected the
router as shown below: (Annex-A ADSL USB Modem)
**Use the “ATF085A1R” Annex-A Splitter (Optional)
1. Connect the supplied USB cable from your PC's USB port to ADSL
USB Modem.
2. Connect the supplied RJ11 telephone cable from your home's
telephone jack to the “LINE” port of the supplied ATF085A1R splitter.
Connect the other supplied RJ11 telephone cable to the “MODEM”
port of the splitter and connect the other end of this cable to the “LINE”
port of your ADSL USB Modem.
3. Connect a RJ11 telephone cable to the “PHONE” port of the splitter
and connect the other end to your telephone.
ComTW263R4
4
ADSL USB Modem
LED Meaning
Your ADSL USB Modem has indicator lights on the front side. Please see
below for an explanation of the function of each indicator light.
●PWR : Power indicator
●Link : ADSL Link indicator
●Data : Data Transfer indicator
Table 1.1--- LED function
Label Color On Flash Off
PWR Green Power On NA Power Off
Link Green Connect to
DSLAM
Disconnect to
DSLAM
NA
Data Green NA Transmit /
Receive Data
NA
5
ADSL USB Modem
Install the ADSL USB Modem
For Windows XP/Vista
1. Please turn on your computer.
2. Do not connect your ADSL USB MODEM device to the PC prior to
driver installation and connect ONLY WHEN PROMPTED TO DO SO
DURING THE SOFTWARE INSTALLATION PROCEDURE.
3. Please insert the supplied CD into your CD-ROM drive.
4. The CD should auto-start, displaying the window shown in 5. below. If
your CD does not start automatically go to Windows Explorer, Select
your CD drive and click “autorun.exe”
5. Please click “USB Driver Installation” to continue.
ComTW263R4
6
ADSL USB Modem
6. Click ” Next ” in the following window
7. Please click “ Accept ” button to continue.
7
ADSL USB Modem
8. Select your setting in this window and click “ Next ”. If you want to
configure the setting manually, please click “ Customize ”.
