Bauhn ATV65UHDS-1221 Bedienungsanleitung
User Manual
MODEL: ATV65UHDS-1221
65”
AFTER SALES SUPPORT
1300 002 534
tempo.org/support
MODEL: ATV65UHDS-1221 PRODUCT CODE: 708211 12/2021
AUS
2
Welcome
3
Contents
Welcome 2
Unpack and Prepare 4
What's in the box 4
Important Tips 5
Attaching the stand 6
Wall-mounting the TV 7
Connect to power 8
Connect your antenna 8
Controls and Connections 9
Get to know your TV 9
Buttons on the TV 9
Ports on the TV 10
Remote Control 12
Setup 12
Using the Remote Control 13
Standard Remote 14
Easy Remote 16
On-Screen Set Up 17
TV Setting Menus 18
TV 20
Picture 21
Sound 23
Network 25
System 27
Lock 30
PVR
(Personal Video Recording) 31
About 32
QMenu 33
High Dynamic Range (HDR) 34
Smart TV 35
Smart TV Applications 35
Screencast 36
App Portals 36
Web Browser 37
TV Guide 38
Recording 39
Recording Live TV 40
Scheduled Recording 40
Playback 40
Pause Live TV (Time-shift) 41
USB Mode 42
Set up 42
Troubleshooting 44
Specications 47
Compliance and
Responsible Disposal 48
Warranty Information 49
Repair and Refurbished
Goods or Parts Notice 50
4 | UNPACK AND PREPARE
See the top of the box
for how to handle the TV
without damaging it!
Unpack and Prepare
What's in the box
Before installing your new TV, check you have everything needed.
In the box you will find:
A. 65"4K Ultra HD Smart TV
B. Remote Control
C. Easy Remote Control
D. AAA Activ Energy Batteries
E. TV Stands
F. Screws for TV Stands
G. Warning Sheet
H. TV Toppling Safety Message
I. Quick Start Guide
J. Warranty Certificate
K. General Safety Warnings
L. User Manual
You will need:
• Phillips-head screwdriver (for stand installation)
• Someone to help you lift and install your TV
• Broadband internet (to access Smart TV apps)
• Antenna cable (to watch live TV)
EF
G
HIJKL
CD
UNPACK AND PREPARE | 5
Important Tips
• Place the TV on a level surface.
• Place the TV away from any source that may generate heat or vibrations.
• Make sure there is enough space around vents for airflow.
• The remote control works up to 5 metres away from the TV.
• Unplug the TV before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Use only the power supply provided.
• It is highly recommended to use safety straps for securing the TV in place.
• Keep liquid, children and pets away from the TV at all times.
6 | UNPACK AND PREPARE
Unless you are wall-mounting the TV, you will need to
attach its stand/legs.
1. Lay the TV face-down on a soft, flat surface (like the
sofa, or a towel on a table) larger than the TV itself.
2. Match the stands to the installation points on the
underside of the TV.
3. Attach the stands to the TV at the installation points
using the screws provided. (Grab a screwdriver for
this bit).
Attaching the stand
• This TV is heavy! We recommend asking
someone to help you lift it.
• Unplug the TV from the power outlet before
installing or removing the stand.
• DO NOT place the TV standing upright without
its stand attached; it could damage the remote
sensor at the bottom of the TV.
• Only touch the frame, not the screen.
• It is highly recommended to use safety straps for
securing the TV.
CAUTION!
Do not apply
excessive force as
you might damage
the screw holes.
UNPACK AND PREPARE | 7
400mm
Back of the TV
200mm
Wall-mounting the TV
The TV comes with holes on the back panel for use with
wall-mounting brackets (bracket not included).
Use four standard M8*10mm screws (or longer,
depending on the mounting bracket) to wall-mount this
TV (screws are not included).
• Unplug the TV from the power outlet
before wall-mounting.
• Contact a professional for assistance with
wall-mounting the TV.
Required
• VESA Mounting
Bracket
• 4 x M8*10mm
screws (or longer
as required)
The screws in the package are for securing the TV stand
only. If you are wall-mounting the TV, consult a qualified
installer for advice on bracket support and wall support.
8 | UNPACK AND PREPARE
Free-to-airTVinHD(HighDenition)
High Definition (HD) channels
provide the best viewing quality and
are available with a digital antenna
connection.
TV channels in Ultra HD resolution are not
currently available in Australia. Therefore
when you watch HD broadcast signals on
an Ultra HD TV, the picture can appear
'soft' and lacks the detail you see when
watching the same content on a HD TV.
Connect to power
Make sure the TV is switched off at the power outlet
until you have finished connecting your cables.
Connect your antenna
Antenna cable not included.
Don't forget to plug in the TV
to the power outlet. Leave
the power switched off until
installation is finished.
ABC HD
SBS ONE HD
7HD
9HD
10 HD
PRIME7 HD
WIN HD
Example
HD Channels
CONTROLS AND CONNECTIONS | 9
See next page for more info on the connections.
1. (ON/Standby): Switch the TV to On or Standby.
2. VOL - / VOL + : Decrease/increase the volume level.
3. CH - / CH + : Select the previous or next channel.
4. MENU: Enter the settings menu.
Controls and Connections
Buttons on the TV
Get to know your TV
Front view
On/Standby indicator and
Remote sensor
1 4 5 6
23
5. SOURCE: Select the input source.
6. IR remote receiver.
10 | CONTROLS AND CONNECTIONS
Ports on the TV
1
HDMI IN
Use a high-speed
HDMI cable for
best picture and
sound quality.
SOUND
COMPUTER
All-digital connection between the TV and any HDMI device.
Supports Ultra HD resolution. Requires a high-speed HDMI cable
(not included).
2ANTENNA IN
FREE-TO-AIR
TV
Connect your antenna for live TV. (Antenna cable not included).
3USB
STORAGE
Plug in a USB stick/drive to PVR record and pause live TV.
Play media files stored on your USB storage device (supports
Ultra HD resolution; supported file codecs and extensions may
vary). Update the TV software via USB.
4
Headphone
Jack
SOUND
Connect to your headphones, amplifier or audio device, using an
AUX cable (not included).
1 2 3 4
HDMI IN 1
(ARC)
