Baumatic BMC461SS Bedienungsanleitung

BMC461SS

46 cm High compact

combination microwave

oven

User Manual for your Baumatic

BMC461SS

46 cm High compact combination

microwave oven

NOTE

This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance

GS 15/03/12

Contents

Environmental note 4

mportant safety information 5 – 9

Specifications 10–12

Product and aperture dimensions 10

Product specifications 10-11

Standard accessories 11

Electrical details 11

Control panel 12

Using your microwave oven 13–1

Functions 13

Turning the appliance on 14

Initial set up 14-15

Setting the clock 15

The oven light 16

The safety lock 16-17

Changing the operating language 17

Before first use 17-1

Timer functions 1 -22

Setting the minute minder 1

Setting the cooking time 19-20

Setting the end of cooking time 20-21

Setting the delayed cooking time 21-22

Selecting a cooking function 22-33

Quick start 22

Setting the temperature 22-23

Residual heat 23

Cooking table 23

Using the microwave function 24

Using the microwave and grill function 24-25

Using the microwave and fan oven function 25-26

Defrost by time 26

Defrost by weight 26-27

Maximum defrost weights 27

Defrost table 27

Auto recipes 2 -29

Saving a personalised recipe 29

Deleting a personalised recipe 29-30

Microwave cooking guidelines 30–31

Materials you can use in a microwave oven 31-32

Materials you cannot use for microwave cooking 32

Utensils table 32-33

Cleaning and maintenance 33-34

The appliance exterior 33

The appliance interior 33

Turntable and turntable support 33-34

General cleaning advice 34

nstallation 35-40

Electrical connection 35-36

Aperture and ventilation requirements 37-40

Fixing the appliance into the housing unit 40

Troubleshooting 40-42

Baumatic consumables 43

Contact details 44

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

MPORTANT SAFETY NFORMAT ON

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Customer Care

Department.

General nformation

oThis appliance is designed for domestic household use. It can

NOT be used as a freestanding microwave and must be built in

to a standard kitchen cabinet or housing unit (see the section

entitled “Installation”).

oYou should only operate the appliance when the turntable and

turntable support are in position.

oYou should only use ovenware that is suitable for being used in a

microwave.

oTo prevent corrosion occurring due to moisture/condensation,

the cavity and the door of the microwave should be wiped dry

after each use of the appliance.

oThe appliance must not be left unattended if you are heating or

cooking food in containers that are made of paper, plastic or

other flammable materials. If left unattended, they could pose a

fire hazard.

oIf you notice smoke coming from the appliance, you should keep

the door of the microwave closed and then disconnect it from

your mains supply. DO NOT use your microwave oven, if you

think it is not operating correctly.

nstallation

oIMPORTANT: Only the built in/built under installation

sanctioned by Baumatic and outlined in this manual should be

followed.

oDo not attempt to use your appliance outdoors or any place

where it is likely to come into contact with the elements.

oIMPORTANT: The adjacent furniture or housing and all

materials used in the installation must be able to withstand a

minimum temperature of 85°C abo e the ambient temperature

of the room it is located in, whilst in use.

oDo not attempt to use your appliance outdoors or any place

where it is likely to come into contact with the elements.

oCertain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouration at

temperatures below the guidelines given above.

oAny damage caused by the appliance being installed in

contravention of this temperature limit, or by placing adjacent

cabinet materials closer than 4mm to the appliance, will be the

liability of the owner

oFor use in leisure accommodation vehicles, please refer to

the appropriate information given in the installation instructions

for this appliance.

oThe use of this appliance for any other purpose or in any other

environment without the express agreement of Baumatic Ltd.

will invalidate any warranty or liability claim.

oYour new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of Guarantee. The foregoing does not

affect your statutory rights.

Service

oYour microwave complies with all relevant safety standards. In

order for it to continue to operate safely, only an engineer that

is approved by the Baumatic Customer Care Department

should work on the appliance

oIMPORTANT: It is dangerous for a non qualified person to work

on the appliance, in particular if they remo e the co er that

pro ides protection against exposure to microwa e energy.

oIf you notice that the door seal, door surfaces, power cord and

plug are damaged. You should stop using the appliance,

disconnect it from the mains supply and contact the Baumatic

Customer Care Department.

oOnly genuine Baumatic spare parts should be fitted to your

appliance. These can be obtained from the Baumatic Spares

Department.

Warning and safety instructions

oThis appliance complies with all current European safety

legislation. Baumatic do wish to emphasise that this compliance

does not remove the fact that the appliance surfaces will

become hot during use and retain heat after operation

oDO NOT place anything between the door and the door frame.

oDO NOT store anything that is flammable inside of the

microwave. When it is switched on, the items could catch fire.

oDO NOT switch the appliance on if there is no food or liquid

inside of the microwave. If you run the microwave whilst it is

empty, there is a chance that it will overload.

oThe door seals and the door surfaces should ALWAYS be kept

clean and free from debris.

Child Safety

oBaumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowed

to touch the appliance at any time.

oIf it is necessary for younger family members to be in the

kitchen, please ensure that they are kept under close supervision

at all times.

oIMPORTANT: This appliance should only be operated by adults.

You SHOULD NOT allow young children to use the microwa e

without super ision. Older children should only operate the

appliance if they ha e been thoroughly instructed on how to use

the microwa e and the consequences of improper usage.

General Safety

oDo not allow electrical fittings or cables to come into contact

with areas on the appliance that get hot.

oDo not use the appliance to heat the room it is located in.

oDo not use the appliance to dry paper, textiles or animals.

oDo not install the appliance next to curtains or soft furnishings.

oDo not use the appliance to heat unopened bottles or cans etc.

oDo not use corrosive chemicals or vapours in this appliance. This

oven is especially designed to heat. It is not designed for

industrial or laboratory use.

oDo not heat cooking oil or liquid containing alcohol, as there is

the chance of spontaneous combustion.

oDo not boil eggs or similar foods in their shells, otherwise they

may burst. It is possible to poach eggs in your microwave,

providing you prick the yolks first.

oDo not attempt to lift or move cooking appliances by using the

oven door, as this may cause damage to the appliance or result

in injury to the person lifting the appliance.

Cleaning

oCleaning of the oven should be carried out on a regular basis.

oGreat care should be taken whilst using this appliance and when

following the cleaning procedure.

oIMPORTANT: The appliance must be disconnected from the

mains before following the cleaning procedure.

nstallation

This appliance must be correctly installed by a

suitably qualified person, strictly in accordance

with the manufacturer’s instructions

oBaumatic Ltd declines any responsibility for injury or

damage, to person or property, as a result of improper

use or installation of this appliance

oHeat, steam and moisture will be created during use of the

appliance, take care to avoid injury and ensure that the room is

adequately ventilated. If the appliance is going to be used for

prolonged periods of time, then additional ventilation may be

required.

oPlease consult with your qualified installer if you are in any doubt

about the amount of ventilation that you will require.

Declaration of conformity

oCE: Appliance conforming to the European directives

9/336/EEC, 93/6 /EEC, 73/23/EEC and subsequent revisions

and “RoHS” directive 2002/95/CE.*

oThe manufacturer declares that the oven is built using certified

materials and requires the appliance to be installed in

accordance with the standards currently in force. This appliance

must be used by a trained person for domestic purposes only.

*The RoHS directive stands for “the restriction of the use of

certain hazardous substances in electrical and electronic

equipment”. This directive bans the placing on the EU market of

new electrical and electronic equipment containing more than

the agreed levels of lead, cadmium, mercury, hexavalent

chromium, polybrominated biphenyl (PBB) and polybrominated

diphenyl ether (PBDE) flame retardants.

Specifications

Product dimensions

Height: 454 mm

Width: 59 mm

Depth: 55 mm

Aperture dimensions*

Height: 45 mm MIN

Width: 560 mm

Depth: 560 mm

* Please refer to the installation instructions for more detailed

information about the size of aperture required.

Product specifications

o7 cooking functions:

Microwave

Microwave + grill

Microwave + fan oven

Fan oven

Grill

Grill + fan

Fan oven + grill

o6 power levels

o60 preset recipes + 100 personal recipes

Inhaltsverzeichnis

Andere Baumatic Ofen Handbücher

Baumatic

Baumatic BO988BL Bedienungsanleitung

Baumatic

Baumatic MEGACHEF B610MC Bedienungsanleitung

Baumatic

Baumatic BSD67MS Bedienungsanleitung

Baumatic

Baumatic P619BS Bedienungsanleitung

Baumatic

Baumatic PD659SS-ANZ Bedienungsanleitung

Baumatic

Baumatic P900SS Bedienungsanleitung

Baumatic

Baumatic BS65MS Bedienungsanleitung

Baumatic

Baumatic BAU91GG Bedienungsanleitung

Baumatic

Baumatic B151BL-B Bedienungsanleitung

Baumatic

Baumatic P640SS Bedienungsanleitung

Baumatic

Baumatic B906.6SS Bedienungsanleitung

Baumatic

Baumatic B501.1BS Bedienungsanleitung

Baumatic

Baumatic BSO616SS Bedienungsanleitung

Baumatic

Baumatic BO670SS Bedienungsanleitung

Baumatic

Baumatic BCS461SS Bedienungsanleitung

Baumatic

Baumatic BCS461SS Bedienungsanleitung

Baumatic

Baumatic BO600BL SS Bedienungsanleitung

Baumatic

Baumatic BO675TS Bedienungsanleitung

Baumatic

Baumatic BSCS45-ANZ Bedienungsanleitung

Baumatic

Baumatic BODM984 Montageanleitung

Baumatic

Baumatic B240SS-A Bedienungsanleitung

Baumatic

Baumatic B910SS-A Bedienungsanleitung

Baumatic

Baumatic B262ss Bedienungsanleitung

Baumatic

Baumatic ELECTRIC SINGLE OVENS Bedienungsanleitung

Beliebte Ofen Handbücher anderer Marken

Bosch

Bosch HVA531NS0 Bedienungsanleitung

Electrolux

Electrolux EOF6P46X Bedienungsanleitung

NEFF

NEFF B44S32 5GB Series Bedienungsanleitung

Combi

Combi BLODGETT BC142GDS Bedienungsanleitung

AEG

AEG COMPETENCE 311704300 Bedienungsanleitung

Falcon

Falcon DOMINATOR PLUS G3106 Series Benutzerhandbuch

Rational

Rational SCC WE 61G Bedienungsanleitung

Smeg

Smeg DOSPA38X Installations- und Betriebshandbuch

Electrolux

Electrolux air-o-convect 20 GN 2/1 Bedienungsanleitung

Miele

Miele HR 1954-2 Bedienungsanleitung

KHIND

KHIND OT50 Bedienungsanleitung

Henny Penny

Henny Penny Smoker Box Bedienungsanleitung

Lang

Lang ECOD-AP Bedienungsanleitung

AEG

AEG BEK455310M Bedienungsanleitung

Frigidaire

Frigidaire FNGE90JGR Bedienungsanleitung

Hotpoint

Hotpoint FE9 S831 JSH IX Bedienungsanleitung

GE Advantium SCB2000 Bedienungsanleitung

AEG

AEG DE401301DM Bedienungsanleitung
