Baumatic B25SE Bedienerhandbuch

说明书递交文档

设计

DESIGN

许婷婷

2012.7.9

校对

CO.BY 袁晓娟

图号/物料编码 PART NO.

标准化

TANDARD 马凯

李宇

1. 即日起更改说明书页码3、5、39、40、41内容

删除原先说明书40页 2014.4.11 周凤霞

图纸名称 PART NAME

材

料 MATERIAL

业务

seller

图样

标记

REL

版本号

REV.NO

重量

(g)

WEIGHT

比例

scale

批准

UTHORIZ

于清 0 1:1

美的冰箱事业部

MIDEA REFRIGERATION

DIVISION

共页

TOTAL

SHEETS

第页

NO. OF SHEETS

技术要求

1、尺寸：32K

2、说明书印刷颜色：封面彩印,内页黑白印刷。

3、样板需送设计部门封样。

标记

MARKER 变更内容修改日期签名

BAUMATIC

B25SE(CE-BCD515WE-S)

说明书

50200101B858

80g双胶纸

B25SE

Side by side frost free

fridge freezer

USER MANUAL FOR YOUR BAUMATIC

B25SE

545 Litre side by side

frost free fridge freezer

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference, for

you or any person not familiar with the operation of the appliance.

JW 06/07/12

Contents

Environmental note 4

Important safety information 5-6

Specifications of your fridge freezer 7-10

Description of the appliance 8

Fridge section (including door) 8

Freezer section (including door) 8

Using your Baumatic fridge freezer 12-17

Before switching on 11

During first use 11

Control panel 12

Switching on the appliance 12

Setting the temperature manually (freezer section) 12

Setting the temperature manually (fridge section) 13

Switching on fast freeze mode 13

Switching on rapid cooling mode 14

Switching on holiday mode 14

Switching on energy saving mode 15

Returning the appliance to normal operation 15

Switching on the control panel lock 15

Using the ice/water dispenser 16-19

Arranging and storing food in the fridge section 20

The **** freezer section 21

Freezing fresh food 22

Tips on freezing 23

Storing commercially frozen food 24

Defrosting frozen food 24

Normal operating noises 24

Important user information 24

Saving energy when using your fridge-freezer 24-25

Cleaning and maintenance 26-29

General cleaning 26-28

The defrost drain hole 28

Defrosting the freezer section 29

Replacing the light bulb 29

Installation 30-36

Electrical connection 30

Positioning 31

Installation preparation 32

Removing the fridge and freezer doors 33-34

Installing the decorative plinth 35

Connecting the water inlet hose 36

Troubleshooting 37-39

Contact details

Technical data

Environmental note

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Advice Line.

IMPORTANT: Any installation work must be carried

out by a qualified electrician or competent person.

Use of the appliance

oYour appliance is only designed to be used in the

home. It is suitable for storing food that needs to

be chilled and refrigerated. If it is used for any

other purpose or it is not used correctly, then

. will accept no liability for any

damage that is caused.

oAltering the specification of the appliance must not be attempted

for reasons of safety.

Before using your appliance

oCheck the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance

to your mains supply and should contact your retailer.

Refrigerant

oYour appliance contains R600a refrigerant, which is a natural gas

that does not contain CFCs that can damage the environment.

However it is a flammable substance, therefore care should be

taken:

During the transportation and installation of the

appliance, make sure that the refrigeration pipe-

work does not get damaged.

If it does become damaged then sources of ignition

and open flames should be avoided. Also the room

that the appliance is situated in should be thoroughly

ventilated.

oDo not place any objects on top of the appliance,

as this may damage the table top.

Baumatic

Child safety

oPackaging material should be kept away from

children.

oChildren should not be allowed to touch the

controls or play with the appliance.

General safety

oDo not pull on the power supply cable to remove the plug from

your mains supply socket.

oDo not pull out or insert the plug with wet hands.

oDo not attempt to use your appliance outdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing maintenance work,

ensure that the appliance has been disconnected from your

mains supply.

oNever allow the back coils of the appliance to come into contact

with the wall surface.

oAlways ensure that the location where you are installing your

appliance is free of stored items such as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep your appliance well ventilated, so

that there is proper air flow between the bottom of

the unit and the plinth/kick plate which it is sitting

on.

oDo not place electrical devices inside of the appliance, such as

mixers or ice cream makers.

oDo not store aerosol cans with a flammable propellant in this

appliance.

Service

You should not attempt to repair the appliance yourself,

as this could cause injury or a more serious malfunction.

If you require a service call then please contact the

Baumatic Customer Care Department.

Specifications of your fridge freezer

Dimensions of your appliance

oHeight: 1760 mm

oWidth: 902 mm

oDepth: 750 mm (Including doors and handles)

Energy efficiency class

oEnergy class: A+

Cubic capacities

oTotal gross/net capacity: 545/515 litres

oGross capacity (fridge/freezer): 347/198 litres

oNet capacity (fridge/freezer): 340/175 litres

Specifications of the appliance

oFrost free fridge and freezer

oStar rating **** (freezer door racks **)

oMulti airflow cooling system

oElectronic temperature control

oDigital control panel

oAdjustable thermostat

oFast cooling switch

oFast Freeze switch

oFast freeze indicator light

oDoor open warning indicator

oTemperature rise warning indicator

oAutomatic motor-driven ice maker

oWater dispenser

oAdjustable feet

o3 Adjustable fridge safety glass shelves

o1 Salad crisper shelf (Safety glass)

o4 Bottle racks

o2 Salad crispers

oButter and cheese compartment

oEgg rack

o3 Freezer safety glass shelves

o2 Transparent freezer drawers

o4 Freezer door racks

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

In order to find out the climatic rating of your appliance, you should

check the rating plate. The rating plate is located inside of the fridge

section, on the left side. You will need to open the door of the fridge

section and you may need to remove one of the middle safety glass

shelves. The rating plate will indicate the ambient temperature range

that your appliance will function correctly within.

Description of the appliance

1) Bottom beam/decorative plinth

2) Freezer drawer (x2)

3) Freezer shelf (x3)

4) Ice dispenser

5) Freezer door rack (x4)

6) Ice maker

7) Fridge light

8) Butter/cheese compartment

9) Adjustable safety glass shelves (x3)

10) Bottle racks (x 4)

11) Salad crisper drawer (x2)

12) Digital control panel

13) Ice/water dispenser

Description of product features (fridge)

Safety glass shelves

oThe shelves may be placed in any of the guide slots within the

interior of the appliance. They are protected from sliding out.

oTo remove a shelf: Take off all of the

items that are stored on the shelf that

you want to remove. Pull the shelf

forwards (a), then lift the front of the

shelf (b) towards 90° and carefully

pull it out of the grooves (c).

oThe upper shelves should be used to store pasta, canned food,

milk etc.

oThe lower shelf should be used to store cooked meats and

sausage etc.

Salad crispers

oThese drawers are suitable for storing fruits, salad and

vegetables. They are designed to keep the contents fresh for as

long as possible.

oCare should be taken when storing tropical fruit (bananas and

pineapples etc) and tomatoes. As these types of items can easily

deteriorate at a lower temperature.

Butter and cheese compartment

oThis rack should be used to store eggs, butter, cheese, yogurts

etc.

Bottle racks

oThese racks should be used for storing reasonably sized bottles.

These racks can also be used to store smaller cans, packages

and tubes, etc.

oIMPORTANT: IT IS IMPORTANT THAT NONE OF THE

SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS

THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE.
