Baxtran XTA Bedienungsanleitung
| marca propiedad de | est une marque de | trade mark propiety of | ist als Marke des Markeneigentums zu kennzeichnen
|marchio proprietà di
Pol. Empordà Internacional Calle F. Parcela 15-16
17469 VILAMALLA - (Girona) SPAIN
T. (34) 972 527 212 - F. (34) 972 527 211
El fabricante se reserva el derecho de modificar sin previo aviso las características de sus productos para introducir mejoras técnicas o cumplir con nuevas regulaciones oficiales./Le
constructeur se réserve le droit de modifier les caractéristiques de ses produits en vue d’y apporter des améliorations techniques ou de respecter de nouvelles réglamentations./The
manufacturer reserves the right to modify the specifications of its products in order to make technical improvements or comply with new regulations/ Der Hersteller behält sich das Recht vor,
ohne Vorankündigung die Eigenschaften seiner Produkte zu ändern, um weitere Verbesserungen zu erzielen oder neuen offiziellen Richtlinien nachzukommen/ Il fabbricante si riserva il diritto
di modificare senza alcun preavviso le caratteristiche dei suoi prodotti in vista di apportare migliorie tecniche o di rispettare nuove regolamentazioni.
14/03/2019
EN|FR|ES
USER MANUAL | MANUEL D’UTILISATION | MANUAL DE USUARIO
XTA / XTA-P
XTA
EN
CONTENTS
1. PRECAUTIONS 5
2. INTRODUCTION 6
3. SPECIFICATIONS 6
3.1. GENERAL SPECIFICATIONS 6
4. INSTALLATION 7
5. KEYBOARD & DISPLAY 8
6. OPERATION 9
6.1. POWER ON/OFF 9
6.2. ZERO 9
6.3. TARE 9
6.4 WEIGHING GOODS 10
6.5. UNIT PRICE SETTING 10
6.6. UNIT PRICE MEMORY 10
6.7. BACK LIGHT 11
6.8. AUTOMATIC UNIT PRICE CLEAR 12
6.9. GIVE CHANGE 12
7. PARAMETER 13
7.1. PARAMETER SETTINGS 13
7.2. PARAMETER MENU 14
8. CALIBRATION 15
9. RS 232 OUTPUT 15
10. ERROR CODES 16
FR
SOMMAIRE
XTA
1. PRÉCAUTIONS 17
2. INTRODUCTION 18
3. DISPOSITIONS 18
3.1. DISPOSITIONS GÉNÉRALES 18
4. INSTALLATION 19
5. CLAVIER & ÉCRAN 20
6. FONCTIONNEMENT 21
6.1. POSITION ON/OFF 21
6.2. ZÉRO 21
6.3. TARE 21
6.4 PESAGE DE MARCHANDISES 22
6.5. FIXATION DU PRIX UNITAIRE 22
6.6. MÉMOIRE DU PRIX UNITAIRE 22
6.7. RÉTRO-ÉCLAIRAGE 23
6.8. EFFACEMENT DU PRIX UNITAIRE AUTOMATIQUE 24
6.9. RENDRE LA MONNAIE 24
7. PARAMÈTRE 25
7.1. PARAMÉTRAGES 25
7.2. MENU DES PARAMÈTRES 26
8. ÉTALONNAGE 27
9. RS 232 SORTIE 27
10. CODES D’ERREURS 28
ES
ÍNDICE
XTA
1. PRECAUCIONES 29
2. INTRODUCCIÓN 30
3. ESPECIFICACIONES 30
3.1. ESPECIFICACIONES GENERALES 30
4. INSTALACIÓN 31
5. TECLADO Y PANTALLA 32
6. OPERACIÓN 33
6.1. ENCENDIDO ON/OFF 33
6.2. CERO 33
6.3. TARA 33
6.4 PESAR PRODUCTOS 33
6.5. CONFIGURACIÓN UNIDAD DE PRECIO 34
6.6. MEMORIA UNIDAD DE PRECIO 34
6.7. LUZ TRASERA 35
6.8. BORRADO AUTOM 35
6.9. DAR CAMBIO 35
7. PARÁMETROS 36
7.1. CONFIRGURACIÓN PARÁMETROS 36
7.2. MENÚ PARÁMETROS 37
8. CALIBRACIÓN 38
9. SALIDA RS 232 38
10. CÓDIGOS ERROR 39
5
ENUSER MANUAL XTA
1. PRECAUTIONS
WARNING
DISCONNECT ALL POWER TO THIS UNIT BEFORE
INSTALLING, CLEANING, OR SERVICING. FAILURE TO
DO SO COULD RESULT IN BODILY HARM OR DAMAGE
THE UNIT.
CAUTION
• PERMIT ONLY QUALIFIED PERSONS TO SERVICE THE INSTRUMENT
• BEFORE CONNECTING OR DISCONNECTING ANY COMPONENTS, REMOVE THE POWER.
• FAILURE TO OBSERVE THESE PRECAUTIONS BODILY HARM OR DAMAGE TO OR DESTRUCTION
OF THE EQUIPMENT.
• The price computing scale is a precision electronic instrument, handle it carefully.
• Do not install the scale in direct sunlight.
• Verify the local voltage and receptacle type are correct for the scale.
• Only use original adaptor, other could cause damage to the scale.
• Pluggable equipment must be installed near an easily accessible socket outlet.
• Avoid unstable power sources. Do not use near large users of electricity such as welding equipment or large motors.
• Avoid sudden temperature changes, vibration, wind and water.
• Avoid heavy RF noise.
• Keep the scale clean
ENUSER MANUAL XTA
6
2. INTRODUCTION
XTA & XTA-P scales are very compact, reliable, high accuracy and much stable.
It uses 15mm LCD display with LED backlight, with the different back light operation,
Weighing unit conversion /kg and /100g and change function.
20 membrane keyboard
10 indirect PLU, it can store 10 unit price values
Auto unit price clear operation (SAVE function)
3. SPECIFICATIONS
3.1. GENERAL SPECIFICATIONS
MODEL XTA / XTA-P
Display 15mm LCD Display with white LED back Light
Gross weight 4.1kg (XTA) / 4,5kg (XTA-P)
Capacity 3/6kg 6/15kg 15/30kg
Readability 1/2g 2/5g 5/10g
Max. Divisions 2 x 3000e
Weighing Units kg
Pan size 204 x 263 mm
Housing ABS plastic and stainless steel pan
Operation Temperature -10°C ~ +40°C
Stability Time 1 seconds typical
Power AC switching adaptor 12V/2500mA.
Rechargeable battery 6V/3.2Ah
Keypad 20 keys
Zero range 0mV~5mV
Signal input range 0~15mV
ADC Sigma delta
Internal counts 600,000
ADC update Max. 60 times/second
Load cell drive voltage Max. 5V/150mA
7
ENUSER MANUAL XTA
4. INSTALLATION
UNPACKING
Carefully take the scale out of its package, make it sure its not damaged and all accessories are included.
Accessories:
1. Scale
2. Power Adaptor
3. Stainless steel pan
4. Product manual
Keep the packaging material for your future use.
LEVEL ADJUSTING
Place the scale on a table.
Check the water mark. If bubble is not centered, adjust the leveling feet until reach centre. Check the level when you change the
location.
CONECT ADAPTOR
• To charge the battery insert the adaptor pin to jack. Adaptor simply plug into the mains power.
The scale no needs to be turned on.
• The battery should be charged for 4 hours for full capacity.
• On the right side of the display there is an LED to indicate the status of battery charging. When the scale is plugged into the
mains power he internal battery will be recharged. If the LED is green, the battery has a full charge. If it is red, the battery is nearly
discharged and if yellow, the battery is being charged.
• Do not use any other type of power adaptor than the one supplied with the scale.
• Verify that the AC power socket outlet is properly protected
Note: Please charge the battery before using the scale for the first time.
ADAPTOR JACK POWER KEY
ENUSER MANUAL XTA
8
5. KEYBOARD & DISPLAY
KEYS PRESS THIS KEY TO
to Numeric Keys, enter unit price / PLU: In setting mode, press numeric keys to enter parameters setting.
Clear incorrect entries and error conditions.
Being set unit price in fix mode, press the key to input double zero; being set unit price in float mode, press the key
to input decimal point.
Returns the display to zero if the weight on the pan is inside the metrological limitation. In parameter settings, to
escape from the menu.
Subtracts the tare values, change to gross to net mode and enter parameter settings.
Activate / desactivate the SAVE function.
Used to store or recall unit price. In parameter setting mode, used to scroll down the menu.
Used to give change operation.
Without function.
Used to change unit (kg/100g).
Whitout Function.
9
ENUSER MANUAL XTA
DISPLAY OVERLAY
DISPLAY SYMBOLS
BATT
Battery indicator. When it’s illuminated, battery should be
recharged.
Net Net weight.
Stable Stable indicator. When it’s illuminated, the scale is stable.
Zero Zero indicator. When it’s illuminated, the scale is in zero point.
/Kg or /100g Kilogram or 100g mode.
SAVE Save indicator.
CHARGE Battery charging indicator
CH Check out indicator
6. OPERATION
INITIAL START-UP
Warm-up time of 15 minutes stabilizes the measured values after switching on.
6.1 POWER ON/OFF
Power switch is located below the right side of the scale. Switch on the scale by pressing on/off. The display is switched on and the
self test is started. If you want to switch off press again the key.
6.2 ZERO
Environmental conditions can lead to the balance exactly zero in spite of the pan not taking any strain. However, you can set the display
of your balance to zero any time by pressing key and therefore ensure that the weighing starts at zero if the desviation is
inside metrological margins.
6.3 TARE
The weight of any container can be tared by pressing key, so that with subsequent weighing the net weight of the object being
weighed is always displayed.
ENUSER MANUAL XTA
10
PROCECTURE:
• Load weight on the pan.
• Press key. Zero is displayed, and tare is subtracted.
• Remove weight from the platform. Tared weight is displayed. It can set only one tare value. It can display with a minus value.
• Press key. Zero is displayed, tare weight is cleared.
6.4 WEIGHING GOODS
• Place goods to be weighed on the platform.
• Wait few seconds for stability display.
• Read the result.
• Avoid overloading. When display appears “ol” reduce the load or unload.
6.5 UNIT PRICE SETTING
• Make sure platform is empty and display is zero
Weight 0 000
Unit price 0 000
Total price 0 000
• Place goods to be weighed on the platform.
Weight 0 175
Unit price 0 000
Total price 0 000
• Enter the unit price by pressing numeric keys. Total price will be calculate automatically.
Weight 0 175
Unit price 5 000
Total price 0 88
6.6 UNIT PRICE MEMORY
XTA & XTA-P can store 10 unit price values. It can select from 0 to 9 numeric keys.
SAVE TO MEMORY
• By pressing numeric keys enter the unit price, for example, 10.
Weight 0000
Unit price 10
Total price 0
• Press and hold PLU, display will be shown.
