BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
1
index
1 INTRODUCTION 2
1.1 BCD-RGD-804P-MT Industrial Ethernet Switch 2
1.2 Soware Features 2
1.3 Hardware Features 3
2 SPECIFICATION 4-5
3 SWITCH INSTALLATION 6
3.1 Install Switch on DIN rail 6
3.2 Wall-mounted 7-8
3.3 Equipment Ground Protection 8
4 HARDWARE DESCRIPTION 9
4.1 Front Panel 9
4.2 Indicator Description 10
5 CABLE 10
5.1 Ethernet Cable 10-11
5.2 SFP Port 12
5.3 Console Cable 12
BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
2www.bcdvideo.com
1 Introduction
1.2 bcd-rgd-804p-mt industrial ethernet switch
The BCD-RGD-804P-MT is a managed industrial Ethernet switch with 8*10/100/1000M auto sensing electrical
ports and 4*1000M SFP ports. It supports PoE/PoE+ with a variety of management: WEB, Telnet, Console (CLI),
SSH, etc., as well as proprietary network management software for centralized management, centralized monitoring,
centralized configuration. Most importantly it supports advanced ERPS (Ethernet Ring Protection Switching) as well
as STP, RSTP and MSTP.
1.2 software features
− PoE management
− ERPS ( recovery time ＜30ms over 128 units of connection)
− Ring coupling, STP / RSTP / MSTP
− SNMPv1/v2c/v3 & RMON & Port base/802.1Q VLAN network management
− Event notification through Syslog, Email, SNMP Trap, etc.
− WEB,＜Telnet,＜SSH,＜Console(CLI)＜network software multiple manage and configure
− Open and close port, binding MAC and port
− 802.1x network access control
− 802.1Q protocol, Isolate network flow
− Radius Centralized password management
− SNMPv3 Encrypted authentication and access security
− Qos guarantee based on real-time traffic
− Dual tag VLAN (802.1Q) and GVRP
− IGMP Snooping multicast function
− Port status, statistics, mirroring, and secure configuration
− RMON remote management
BCD-RGD-804P-MT
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
3
1.3 hardware feature
− 8*10/100/1000M auto sensing electrical ports
− 4*1000M SFP ports
− Support PoE/PoE+
− Console Port: USB＜(115200-8-N-1)
− Support dual DC power input
− Operating temperature:＜-40 to +75oC
− Storage temperature:＜-40 to +85oC
− Operating Humidity: 5%~95%, No condensation
− Support IP-40 housing design
− Size (W x D x H)＜68 mm(W) x 102.5 mm(D) x 146 mm(H)＜(DIN-rail mounting)＜
− Weight:＜0.8kg
BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
4www.bcdvideo.com
2. specification
10/100/1000 Base-T (X) Ports 8 RJ45Auto MDI/MDIX
1000Base-FX SFP 4 (SFP slot)
PoE Type End Span
MAC Table 8192 MAC Addresses
Priority Queues 4
Switch Performance
Store-and-Forward
Switching latency: 7 us
Switching bandwidth: 24Gbps
Max. Number of Available VLANs: 4096
IGMP multicast groups: 1024
Port rate limiting: User Define
Security Features
Enable/disable ports,
MAC based port security
Port based network access control (802.1x)
VLAN (802.1Q)
Q-in-Q VLAN for performance & security to expand the VLAN space
Radius centralized password management
SNMP v1/v2c/v3 encrypted authentication and access security
Soware Features
STP/RSTP/MSTP (IEEE 802.1D/w/s)
ERPS with recovery time < 30ms over 128 units
TOS/Diserv supported
Quality of Service (802.1p) for real-time traic
VLAN (802.1Q) with VLAN tagging and GVRP
IGMP Snooping for multicast filtering
Port configuration, status, statistics, monitoring, security
SNTP for synchronizing of clocks over network
DHCP Server / Client support
Port Trunk support
MVR (Multicast VLAN Registration) support
Warning/Monitoring System Relay output for fault event alarming
Syslog server/client to record and view events
Include SMTP for event warning notification via email
Event selection support
BCD-RGD-804P-MT
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
5
DDM Function Voltage/Current/Temperature
Console Port USB (115200-8-N-1)
Alarm Output
Relays Relays output error alarm: 1A@30VDC
Power
Redundant Input Power DC45~57V
Power Consumption (Typ.) 10 W (No PoE)
PoE/PoE+ Each port up to 30W
Overload Current Protection Present
Reverse polarity protect Present
Physical Characteristic
Enclosure IP40
Dimension (WxDxH) 68mm (W) x 102.5mm (D) x 146mm (H)
Weight (Kg) 0.8 (Kg)
Environment
Storage Temperature -40 to 85oC (-40 to 185oF)
Operature Temperature -40 to 85oC (-40 to 167oF)
Operating Humidity 5% to 95% Non-condensing
BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
6www.bcdvideo.com
3. switch installation
3.1 install switch on din rail
Each switch has a rail button on the rear panel. Rail buckle allows the switch mounted on the rail.
The switch can easily be installed in the rail:
Step 2 Insert the switch to rail until
you hear a “click” sound.
Step 1 Let tilt switch, rail edge card into rail.
BCD-RGD-804P-MT
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
7
3.2 wall-mounted
Step 2 Remove 4 screws (spec: M2 .5 x 8)
on the back panel and fix the installation
suspension loop on the back panel.
Turn o the screws 1, 2 on buckle
Remove 4 screws
Remove the buckle
Fix the installation loop
Step 1 Remove Din rail buckle.
BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
8www.bcdvideo.com
Step 3 Install the Switch on the wall vertically by using
self-tapping screws.
Equipment grounding terminals
3.3 equipment ground protection
In order to use this equiment safely and ensure the protection
of EMC, grounding terminals must be connected to the ground.
!
BCD-RGD-804P-MT
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
9
4. hardware description
4.1 front panel
1.＜ Power Supply (voltage input range: DC45~57V).
2.＜ Alarm Contact (one normal open and one normal close ).
3. Equipment control port (USB-115200-N-8-1)
4.＜ Equipment status indicator
− P1:＜ Power Supply 1
− P2:＜ Power Supply 2
− RUN:＜ system status
− Alarm:＜ Alarm indicator
− PoE (1-8):＜ PoE status ports 1 to 8
5. Ethernet port 1 to 8.
6. SFP port 9-12.
Port Description
10/100/1000 RJ-45
Ethernet ports
8 10/100/1000BAse-T(X) RJ-45 fast Ethernet ports support Auto-negotiation.
SFP port 4 100Base-X on SFP port
Console Port 1 USB (115200-8-N-1)
BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
10 www.bcdvideo.com
LED Color Status Description
RUN green On System running lights, the system normally solid green
Alarm green On Warning lamp
P1 orange On Power 1 indicator, a power input Steady
P2 orange On Power 2 indicator, a power input Steady
PoE 1-8 green On PoE connection normal
SFP Port
LNK green On Port connected
ACT orange Flicker Data transmit
10/100/1000Base-T(X) Ethernet Port
LNK green On Port connected
ACT orange Flicker Data transmit
4.2 indicator description
5. cable
5.1 ethernet cable
The product uses standard Ethernet cable. Depending on the connection type, you can choose CAT3, 4,
5e, 6 UTP cable to connect to other network devices (computers, servers, switches, routers, hubs, etc.).
Make sure that the cable properties in the following form.
CONNECT & LOGIN TO BCD-RGD-804P-MT switch
a. Connecting PC to BCD-RGD-804P-MT Ethernet port (RJ45 Ethernet port).
b. Factory default IP: 192.168.0.240
c. Login with default account and password. Username: admin Password: admin
