Advanced Socket 370

Motherboard

IN810EP

USER’S MANUAL

DECLARATION

Rights:

No part of this manual, including but not limited to the products and

software described in it, may be reproduced, transmitted, transcribes,

stored in a retrieval system, or translated in any form or by any means

without the expressed written permission of the manufacture.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies and are used

only for identification or explanation purposes without intent to infringe.

♦Intel, MMX and Pentium are registered trademarks of Intel Corporation.

♦IBM and OS/2 are registered trademarks of International Business Machines.

♦AMI is a registered trademark of AMI Software Inc.

Responsibility:

This manual is provided “As is” with no warranties of any kind, either expressed

or implied, including, but not limited to the implied warranties or conditions of

this product’s fitness for any particular purpose. In no event shall we be liable for

any loss of profits, loss of business, loss of data, interruption of business, or

indirect, special, incidental, or consequential damages of any kind, even the

possibility of such damages arising from any defect or error in this manual or

product. We reserve the right to modify and update the user manual without prior

notice.

COMPLIANCE & CERTIFICATE

ISO 9001 Certificate:

This device was produced in our plant with advanced quality

system certified by DNV QA Ltd. in according to ISO 9001.

This Certificate is valid for:

DESIGN & MANUFACTURE OF MOTHER BOARDS AND

PERSONAL COMPUTERS.

CE Declaration:

CE marking is a visible declaration by the manufacturer or

his authorized representatives that the electrical equipment to

which it relates satisfies all the provisions of the 1994

Regulations.

FCC Compliance:

FCC stands for Federal Communications Commission.

This product complies with FCC Rules Part 15 and has been

tested, and complied with the EMI rules by a certified body.

In normal operation, there shall be no harmful interference

caused by this device nor shall this devise accept any

interference received, including interference that may cause

undesired operation of this product.

Year 2000 Compliance:

This product is tested to be qualified to bear the NSTL Year

2000 Compliant logo. Year2000 problem is mainly a

problem of computer software (OS), and the hardware issue.

With the support of BIOS on motherboard, the Y2K problem

can be thoroughly conquered.

EASY INSTALLATION

Easy Installation Steps

The following “Easy Installation” steps are for

users accustomed to the assembly of a computer

system. For those individuals requiring more

specific information please refer to the more

detailed descriptions located within the latter

chapters of this manual. Note: You must keep

your power cable unplugged until the following

installation steps are completed.

Getting Start:

Touch a grounded metal surface to release static electricity

stored in your body before unpacking your motherboard. For

details please refer to Precaution section in Chapter 3.

Install the CPU by correctly aligning the CPU with the

socket370 as noted in the motherboard diagram. Once aligned,

press down on the CPU gently but firmly and lock it. Next,

install the 3.3 volt unbuffered SDRAM into the 168 pin

DIMMs. See Sec. 3.2 & Sec. 3.3.

Set CPU speed in according to Sec.3.2.

After completing the above steps, install any expansion

Cards( PCI, AMR) into riser card and have the riser card

installed firmly into the slot for riser card on board. See Sec. 3.4.

Plug in all cables included in the package except for the

power cord. Please see Sec. 3.5.

Please recheck all steps to ensure no mistakes

have been made and then plug in the power cord

and turn on the power to enter the BIOS setup, Chapter 4.

Release

Static Electricity

Couple

Connectors Of

HDD, FDD…

Install All

Expansion Slots

Set Jumpers of

CPU

Insert CPU &

RAM

CONTENTS

1INTRODUCTION............................................................................... 7

2FEATURES......................................................................................... 8

3INSTALLATION.............................................................................. 11

3.1 SLOTS AND CONNECTORS....................................................... 15

3.2 CPU (CENTRAL PROCESSING UNIT)........................................ 16

3.2.1 Install CPU ............................................................. 16

3.3 SYSTEM MEMORY (DRAM).................................................... 18

3.3.1 DIMM (Dual Inline Memory Module)...................... 18

3.3.2 Installation Procedure............................................. 18

3.3.3 DIMM Module Combinations.................................. 19

3.4 EXPANSION SLOTS.................................................................. 20

3.5 CONNECTORS......................................................................... 21

3.5.1 Primary IDE Connector (J31, 39-pin block) ............ 21

3.5.2 Secondary IDE Connector (J26, 39-pin block)......... 21

3.5.3 Floppy Drive Connector (J23, 33-pin block)............ 22

3.5.4 Power Input Connector (J22, 20-pin block) ............. 22

3.5.5 TV-Out/DFP connector (J13, 36-pin slot)................ 22

3.5.6 Front Panel connectors (J28 20-pin header)............ 23

3.5.7 Back Panel Connectors ........................................... 25

Additional Connectors........................................................................ 28

4BIOS SETUP..................................................................................... 35

4.1 HOW TO ENTER BIOS SETUP.................................................. 35

CONTENTS

4.1.1 Setup Keys............................................................... 36

4.1.2 Getting Help............................................................ 36

4.1.3 In Case of Problems ................................................ 36

4.2 MAIN SETUP MENU ................................................................ 37

4.3 STANDARD CMOS SETUP MENU ............................................ 39

4.4 ADVANCED CMOS SETUP MENU............................................ 43

4.5 ADVANCED CHIPSET SETUP MENU .......................................... 46

POWER MANAGEMENT SETUP MENU ......................................................... 48

PCI/PLUG AND PLAY SETUP MENU............................................................ 50

4.8 PERIPHERALS SETUP MENU..................................................... 52

4.9 AUTO-DETECTION IDE HDD ................................................. 56

4.10 CHANGE USER PASSWORD ...................................................... 56

4.11 CHANGE SUPERVISOR PASSWORD............................................ 56

4.12 AUTO CONFIGURATION WITH OPTIMAL SETTINGS.................... 57

4.13 AUTO CONFIGURATION WITH FAIL SAFE SETTINGS .................. 57

4.14 SAVE SETTING AND EXIT ........................................................ 57

4.15 EXIT WITHOUT SAVING.......................................................... 57

1. INTRODUCTION

How To Use This Manual

This manual provides information necessary

for Original Equipment Manufactures (OEMs)

and home users to build a PC-AT compatible

system using the Pentium II PCI/ISA/AGP

motherboard. Just follow the installation

procedure presented on the EASY

INSTALLATION Page and refer to the section number following each

step if you require more detailed instructions.

Check Your Device Items

The standard package should contain

following items marked with a “4”, If you

find any these items missing or damaged.

Please contact your retailer.

4The IN810 motherboard

41 IDE ribbon cable

41 floppy ribbon cable

41 CD with drivers of Intel810 VGA and AC’97 Audio codec.

2. FEATURES

Photo Of The Motherboard

2. FEATURES

Features Of The Motherboard

This product is based on the “Micro ATX” form factor. It features

the advanced Multimedia function and provides support for

business PC maker. This motherboard incorporates Intel 810-

DC100 chipset. Providing features such as integrated 2D/3D AGP

VGA controller, Ultra DMA 33/66 IDE Interface, ACPI power

management, and PCI 3D sound support.

Processor (+Cache)

lSingle Intel Socket-370 mechanism for Intel Celeron Processor.

lSupport 66/100 MHz FSB

Chipset

lIntel 810 Chipset includes GMCH0 (Memory Controller Hub), ICH(I/O Controller Hub)

and FWH(Firm Ware Hub).

lWinbond W83627F-AW super I/O Controller.

lSoftware Audio and Hardware AC’97 V2.1 CODEC.

System Memory

lTwo 168-pin DIMM sockets.

lMinimum 8MB up to maximum 512 MB Memory Capacity.

l100MHz SDRAM DIMM module.

Graphics Support

lIntegrated H/W 3D AGP Graphic controller (2x mode)

lSupports AGP(Accelerated Graphics Port) for increased performance of Graphic Displays,

special 3D operations in multimedia, and higher speed to satisfy the users optical vision.

lSupports 3D hyper pipelined architecture, parallel data processing and compression,

precise pixel interpolation, full 2D hardware acceleration land motion video compression.

PCI Bus Master IDE Controller (I/O controller Hub)

lTwo PCI Bus Master IDE Ports(Up to 4 IDE Devices) for Tape Backup machines and

CD-ROMs. Either the 5.25-inch or 3.5 inch(1.44MB or 2.88MB) floppy drives can be

used without requiring an external card. Additionally, Floppy 3 mode (Japanese standard

3.5 inch disk drive, 1.2MB) and LS-120 floppy disk drives(3.5 inch disk drive: 120MB,

1.44MB, 720K) are also supported.

lSupport Ultra DMA 33/66 MB/sec (ATA33/ATA66)

lSupport PIO Mode3,4, run in 17MB/sec. (Max)

Integrated I/O

lLPC revision 1.0 super I/O controller.

l1 Floppy Port (up to 2.88 MB), 1 Parallel Port (ECP/EPP).

l2 Serial Ports (16C550 Fast UART Compatible).

l1 IrDA TX/RX Port. (option, shared with COM2)

l1 PS/2 Mouse Connector, 1 PS/2 Keyboard connector.

2. FEATURES

l1MIDI/Game port

l2 Standard USB Connector (48MHz).

System BIOS

l4M-bit Flash device in Firmware Hub(FWH).

lA unique Roandom Number Generatior in FWH to enable enhanced platform security.

lPC97 and PnP compatible. ACPI, APM and DMI support.

lBootable from CD-ROM supported.

Green Features

lPower Management: APM 1.2.

lAdditionally, with support for ACPI (Advanced Configuration and Power Interface)

feature and On-Now, your system will become more wise in management of power.

Sound System

lSoftware Audio and Hardware AC’97 V2.1 codec compliant.

l3 Audio Phone Jacks (Line out, Line in, Mic. In)

l1 MIDI/Game port, 1 CD in, 1 Modem in. 1 Aux in.

Additional features

lWake-On-LAN and Wake-on-Ring header

lKeyboard/Mouse wake up with ICH.

lModem Ring up function

lFront USB header.

lHardware Monitor Capability (optional)

Expansion Slots

l1 AMR, 3 PCI expansion slots.

Mechanical

lThis motherboard complies with the Micro ATX Form Factor specifications and is a four

layers with dimensions of 9.6” x 8.5”.

Inhaltsverzeichnis

Andere BCM Hauptplatine Handbücher

BCM

BCM RX87Q Bedienungsanleitung

BCM

BCM FX810E Bedienungsanleitung

BCM

BCM SQ576 Bedienungsanleitung

BCM

BCM RX370Q Bedienungsanleitung

BCM

BCM RX45Q Bedienungsanleitung

BCM

BCM QS440VA Bedienungsanleitung

BCM

BCM RX815ELT Bedienungsanleitung

BCM

BCM BC45Q Bedienungsanleitung

BCM

BCM iX965GM Installations- und Betriebshandbuch

BCM

BCM IXBDN-D510 Bedienungsanleitung

BCM

BCM MX3150N Bedienungsanleitung

BCM

BCM RX35Q Bedienungsanleitung

BCM

BCM MX680RD Bedienungsanleitung

BCM

BCM GT440ZX Bedienungsanleitung

BCM

BCM MX266 Bedienungsanleitung

BCM

BCM BC133KT-100 Bedienungsanleitung

BCM

BCM IN915GVE Bedienungsanleitung

BCM

BCM RX945G Installations- und Betriebshandbuch

BCM

BCM MX945GME Bedienungsanleitung

BCM

BCM MX67QM Bedienungsanleitung

BCM

BCM MX3350N Bedienungsanleitung

BCM

BCM BC87Q Bedienungsanleitung

BCM

BCM BC875PLG Bedienungsanleitung

BCM

BCM RX815ELT Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
