BCM OFT-15W04 Bedienungsanleitung

Part No. E2017T154A1R

OFT-15W04

15.1" Open Frame Tablet

Quick Reference Guide

2nd Ed –30 June 2022

OFT-15W04

2 OFT-15W04 Quick Reference Guide

Federal Communication Commission Interference Statement

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE

FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT

MAY CAUSE UNDESIRED OPERATION.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instruction, may cause

harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Notice:

(1) A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent

interference to the nearby radio and television reception. It is essential that only the supplied

power cord by used.

(2) Use only shielded cables to connect I/O devices to this equipment.

(3) Changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

Quick Reference Guide

OFT-15W04 Quick Reference Guide

FCC RF Radiation Exposure Statement

This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant

to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF

Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far

below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a

manner that the potential for human contact during normal operation is minimized. When nearby

persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits

established in the ANSI C95.1 standards, the distance between the antennas and the user should not

be less than 20 cm.

OFT-15W04

4 OFT-15W04 Quick Reference Guide

WARNING

“CAUTION – Use suitable mounting apparatus to avoid risk of injury.”

“CAUTION – This is a Class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures”

“CAUTION –Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries

according to the instructions.”

“CAUTION - Use a power cord that matches the voltage of the power outlet, which has been approved

and complies with the safety standard of your particular country.”

“WARNING – To avoid risk of electric shock, this equipment must only be connected to a supply

mains with protective earth.”

Quick Reference Guide
OFT-15W04 Quick Reference Guide


Content
Getting Started............................................................................................................6
1 Safety Precautions ................................................................................................6
2 Packing List...........................................................................................................6
3 System Specifications ...........................................................................................7
4 System Overview.................................................................................................10
4.1 Bottom View............................................................................................................................... 10
5 System Dimensions.............................................................................................11
5.1 Front and Rear side ................................................................................................................... 11
5.2 Installing Extend Brackets.......................................................................................................... 12
5.3 Front and Rear side (With Extend Bracket)............................................................................... 13
Hardware Configuration...........................................................................................14
2 Motherboard Overviews ...........................................................................................15
3 Motherboard Connector list......................................................................................16
4 Motherboard Connectors settings ............................................................................17
4.1 DC Power-in connector (JDCIN2)............................................................................................... 17
4.2 Touch Key Button (JTB1)............................................................................................................ 17
4.3 Speaker connector (JSPK1)........................................................................................................ 18
4.4 A-MIC connector (JAMIC1)......................................................................................................... 18
4.5 General purpose I/O connector (JDIO1) ..................................................................................... 19
4.6 Sensor Board connector (JSENSE)............................................................................................ 19
4.7 RS-232 connector (JRS232)....................................................................................................... 20
4.8 RS-232 & RS-485 connector (JRS485) ...................................................................................... 20
4.9 USB Camera & DMIC connector (JCAM1) ................................................................................. 21
4.10 RTC battery connector (JRTC) ................................................................................................. 21

OFT-15W04

6 OFT-15W04 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x OFT-15W04

1 x power cord, AC/DC adapter 12V/5A 90 Screw Type

(Optional)

Quick Reference Guide

OFT-15W04 Quick Reference Guide

1.3 System Specifications

Board Specification

Mother Board

ACP-APL

CPU

Intel Celeron J3455 1.5GHz

CPU Cooler (Type)

Heatsink

Memory

4GB DDR3L SODIMM 1866

Power Supply

DC in

Adapter

60W / 12V

Microphone

1x3P_ pitch 2mm AMIC interface

Speaker

1x4P_ pitch 2mm Speaker interface

Camera

2x5P_ pitch 2mm Camera / DMIC

Wireless LAN

1 x 802.11 a/b/g/n/ac Wireless LAN

Bluetooth

BT 5.0

Operating System

2019 Win 10

Expansion Card

SD slot

Storage

Other Storage

Device

32GB eMMC

SSD (60G) M.2 B-Key (3042) Apacer-A32.255GGB.00104

Micro SD slot

Panel

LCD Panel

15.6” BOE NV156FHM-N42

Touch Screen

15.6” HH

Touch Controller

EETI 80H84

Resolution

1920 x 1080

Luminance

220 cd/m²(typ.)

External I/O

DC in Power jack

JDCIN1: Power Jack_90D

Pwr-in 12V~24V

HDMI Port

JHDMI1: HDMI Port_90D

USB Port

JUSB1: USB Type A Host (3.0)_90D

JUSB2: USB Type A Host (3.0)_90D

Lan Port

JLAN1: 10/100/1000 Lan port_90D

Audio Port

JHP1: Headphone Jack_90D

Power button

Power button_90D

Internal I/O

Micro USB (Client)

JUUSB1: Micro USB_90D

OFT-15W04

8 OFT-15W04 Quick Reference Guide

For programming OTG

USB Camera &

DMIC

JCAM1: 5x2P_2mm_90D

USB for Camera & DMIC

Touch

J15TP1: USB for touch screen

M.2 Socket

JNGFF2: M.2 E-Key x 1(2230)_90D for 802.11 a/b/g/n/ac Wireless LAN and

Bluetooth 5.0

JNGFF3: M.2 B-Key x 1(3042)_90D for SSD or WWAN (Option)

Touch Key Button

JTB1: 6x2P_2mm_90D

Touch button control (power/vol/brightness…)

DC-IN(wafer)

JPWR2: 2x2P_2mm_90D

Pwr-in 12V~24V

eDP

J15LCD: 1x30P 90D

Analog MIC

JAMIC1: 1x3P_2mm_90D

Speaker

JSPK1: 1x4P_2mm_90D

L+/L-, R+/R-

Sensor

JSENSE: 5x2P_2mm_90D

RS232

JRS232: 1x5P_2mm_90D

Uart Rs232(Tx/Rx/Rts/Cts/GND)

RS232 & RS485

JRS485: 5x2P_2mm_90D

Uart Rs232(Tx/Rx/Rts/Cts/GND)

Uart Rs485

GPIO

JGPIO1: 10x2P_1mm_90D

RTC Battery

JRTC: 2P_1.25mm_90D

SIM Card socket

JSIM1: Micro SIM Card socket

for LTE module

Expansion Slots

JSD1: Micro SD slot_90D

Mechanical

Power Type

12V~24V wide voltage DC input

Power Connector

Type

DC Jack

Dimension

384x254x53.4 mm

Weight

1.7 kg

Color

Metallic

Fanless

Yes

OS Support

2019 Win 10

Reliability

EMI Test

FCC Class A

Safety

2014/35/EU EN 62368-1: 2014+A11: 2017 (Second Edition)

Quick Reference Guide

OFT-15W04 Quick Reference Guide

Low Voltage Directive

Random Vibration

Operation

1. PSD: 0.00454G²/Hz, 1.5 Grms

2. Operation mode

3. Test Frequency : 5-500Hz

4. Test Axis : X,Y and Z axis

5. 30 minutes per each axis

6. IEC 60068-2-64 Test:Fh

7. Storage : CF or SSD

Sine Vibration test

(Non-operation)

1 Test Acceleration : 2G

2 Test frequency : 5~500 Hz

3 Sweep：1 Oct/ per one minute. (logarithmic)

4 Test Axis : X,Y and Z axis

5 Test time :30 min. each axis

6 System condition : Non-Operating mode

7. Reference IEC 60068-2-6 Testing procedures

Package vibration

test

1. PSD: 0.026G²/Hz, 2.16 Grms

2. Non-operation mode

3. Test Frequency: 5-500Hz

4. Test Axis: X,Y and Z axis

5. 30 min. per each axis

6. IEC 60068-2-64 Test:Fh

Shock Test

1. Wave form：Half Sine wave

2. Acceleration Rate：10g for operation mode

3. Duration Time：11ms

4. No. of Shock：Z axis 300 times

5. Test Axis: Z axis

6. Operation mode

7. Reference IEC 60068-2-29 Testing procedures Test Eb : Bump Test

Package drop test

1 One corner , three edges, six faces

2 ISTA 2A, IEC-60068-2-32 Test:Ed

Operating

Temperature

0°C ~ 40°C

Operating

Humidity

40°C @ 95% Relative Humidity, Non-condensing

Storage

Temperature

-20°C ~ 60°C

Note: Specifications are subject to change without notice.

OFT-15W04

10 OFT-15W04 Quick Reference Guide

1.4 System Overview

1.4.1 Bottom View

Connectors

Label

Function

Note

Audio line-out connector

HDMI

HDMI connector

USB

2 x USB 3.0 connector

LAN

RJ-45 Ethernet

Reset

Reset button

DCIN

DC power-in connector
