Beamz 2-SOME Bedienungsanleitung

2-SOME

153.747_153.748 V3

Immediately upon receiving the product, carefully unpack the carton, check the contents to ensure that all parts are present, and

have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damage from

shipping or the package itself shows signs of mishandling. Save the package and all packing materials. In the event that the product must be returned to

the factory, it is important that the product be returned in the original factory box and packing.

If the unit has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The arising condensation water

might damage your unit. Leave the unit switched off until it has reached room temperature.

On the label on the backside of the unit is indicated on this type of power supply must be connected. Check that the mains voltage corresponds to this, all

other voltages than specified, the light effect can be irreparably damaged. The product must also be directly connected to the mains and may be used. No

dimmer or adjustable power supply.

Always connect the unit to a protected circuit (circuit breaker or fuse). Make sure the unit has an appropriate electrical ground to

avoid the risk of electrocution or fire.

The unit may be set up on a stable and even surface. By means of the fixing facilities of the baseplate, the unit can also be mounted upside down to a truss,

see below picture. For fixing, certified clamps with correct save working load are required. According to the figure, the quick lock bolts of the omega

brackets are placed into the openings provided in the base plate and turned clockwise until they lock (to the stop). The mounting place must be of

sufficient stability and be able to support a weight of 10 times of the unit’s weight. Secure the unit with a safety cable so that it cannot fall down.

When carrying out any installation, always comply European and national guidelines concerning rigging, truss and all other safety issues. Always let the

installation checked out by an authorized dealer !

You can control this fixture without a controller because this feature provides automatic and sound

activated mode.

Fixture shows the preset program.

Fixture responds to the beat of the music. Turn the music on and adjust the microphone

sensitivity knob until the product responds to the beat of the music.

Controls the speed of program in auto mode

Press off existing modes. Press return the last modes.

Automatic mode will enable you to run the automatic programs on the product.

To turn on Automatic mode:

1. Press on the remote controller.

2. Press or to choose between the different auto programs.

Sound-Active mode will enable the product to respond to the music.

To turn on Sound-Active mode:

1. Press on the remote controller.

2. Press or to choose between the different sound programs.

To adjust the strobe speed of the automatic program and the sound active program.

1. Press on the remote controller.

2. Press or to either increase or decrease the speed of the program.

3. Press again to turn off the strobe.

To adjust the speed of the automatic program and the sound active program.

1. Press on the remote controller.

2. Press or to either increase or decrease the speed of the program.

To adjust sound sensitivity for in Sound-Active mode

1. Press on the remote controller.

2. Press or to either increase or decrease sound sensitivity.

1. Press on the remote controller.

2. Press , , , , (red, green, blue or white) to choose your colour.

3. Press again , , , , (red, green, blue or white) to close your colour.

4. Press or to either increase or decrease the percentage of each colour.

Press ON/OFF Light 1

Press ON/OFF Light 2

The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery contacts prevents the

battery from being discharged during storage. Prior to the first operation remove the foil from the battery support on the rear side of the

remote control. Otherwise operation of the remote control is not possible.

If the range of the remote control decreases, replace the battery. For this purpose, on the rear side of the remote

control press the small bar with the groove to the right (1) and at the same time remove the battery support (2). For

operation, one 3 V button cell type CR 2025 is required. When inserting, pay attention that the positive pole of the

button cell shows upwards in the support.
