Beamz SB400 Bedienungsanleitung

SB400

150.450 V1

d001-d512

DMX Start address

Au01 –Au07

Static program

Au08 –Au10

LED Running effect

S01 –So02

Sound-controlled strobe effect

St01- St16

Automatic change between twelve show effects

SP00 - SP16

Speed auto mode

u000 –u255

Manual dimmer

Dimmer

000-255

Master dimmer 0-100%

Strobe

000-001

No function

002-255

Strobe

Macro

000-001

No function

002-255

Macro function

Macro speed

000-255

Macro function speed adjustable

LED

000-255

LED 1 Dimmer 0-100%

000-255

LED 2 Dimmer 0-100%

000-255

LED 3 Dimmer 0-100%

000-255

LED 4 Dimmer 0-100%

The checklist below may help you troubleshoot in the unlikely event that a problem occurs while using the product:

No response from unit.

No power to unit.

Check that power is turned on.

Check cables and connections.

Fuse blown or internal fault.

Replace mean fuse or contact Beamz support

or Beamz authorized service partner. Do not

remove base or yoke covers. Do not attempt to

replace a fuse or carry out any repairs or

service that are not described in this User

Manual unless you have both authorization

from Beamz support or Beamz authorized

service partner.

Unit resets correctly but does not respond (or

does not respond correctly) to the controller.

The controller is not connected.

Connect controller.

Bad DMX-line.

Inspect connections and cables. Correct poor

connections. Repair or replace damaged

cables.

DMX-line has no end resistance.

Insert DMX terminator plug in DMX output

socket of last unit on DMX-line.

Incorrect unit addressing.

Check unit address and DMX mode settings.

A unit is defective and is disturbing data

transmission on the DMX-line.

Unplug DMX IN and OUT connectors and

connect them directly together to bypass one

unit at a time until normal operation is

regained. Have defective unit serviced by an

authorized technician.

Pin 2 and 3 are reversed in XLR connection.

Inspect connections and cables. Install a

phase-reversing cable between the units or

swap pin 2 and 3 in the unit, that behaves

erratically.

Error after unit reset.

Effect requires mechanical adjustment.

Check unit’s software version and error

messages for more information. Contact

Beamz support or Beamz authorized service

partner.

Light output cuts out intermittently.

Unit too hot.

Allow unit to cool. Reduce ambient

temperature. Ensure free airflow around unit.

Clean unit if necessary.

LEDs damaged

Disconnect unit and contact Beamz support or

Beamz authorized service partner.

The power supply settings do not

match local AC voltage and

frequency.

Disconnect unit. Check settings and

correct if necessary.
