User Manual
User ManualUser Manual
User Manual
Sorry to the changes of our products parameters but without notice
.
M8
User Manual
1
1. About MXⅢ
ⅢⅢ
Ⅲ(a.k.a. M82)
1.1 Overview
（
（（
（Top View）
））
）
（
（（
（Front View）
））
）
Infrared Sensor
Power Button
Power LED
M8
User Manual
2
（
（（
（Back View）
））
）
（
（（
（Right View）
））
）
1.2 Accessories
MX
Ⅲ
includes the following accessories
Power Adapter USB CableHDMI Cable
AV Cable
Remote Control
Headphone
&
Upgrade
B
utton
Power
Port
RJ45
Port
HDMI
Port
SPDIF
Port
TF
Card
OTG
Port
USB
Port
USB
Port
M8
User Manual
3
* Accessories and appearance are subject to change without prior notice
2. Getting Started
2.1 Basic Operations
2.1.1 Power On/ Off and Sleep
1. Connect the MXⅢto the TV with HDMI cable, connect MXⅢto the power adaptor,
Connect
mouse, air mouse or other input devices with USB port
2. Press power button to start MXⅢ, power LED turns into blue
3. Under the power on mode, long press power button over 10 seconds to power off the device,
Power LED turns off
4. Under power on mode, press remote control’s power button, device is entering into sleep
mode. Power LED turns into red
5. Under sleep mode, device will be wake when you press remote control’s power button,
M8
User Manual
4
power LED turns from red to blue
2.1.2 Remote Control Introduction
1. Standby/Wake up
2. Mute
3. Media
4. APPS
5. Music
6. Web
7. Volume -
8. Volume +
9. Previous
10. Next
11. Home
12. Return
13. Arrow keys
14. OK
15. Menu
16. Mouse
17. Numbers
（
0~9
）
18. Characters S
witching Key
19. Delete
2.1.3 Open applications
Use remote control’s arrow keys to choose the wanted program, click OK button to open the
selected program
1
2
3
4
7
8
11
13
15
17
18
12
16
19
14
65
10
9
M8
User Manual
5
2.1.4 Switch in the applications
Click icon to view recently used programs, click program icon to switch application
arbitrarily
2.1.5 Close Applications
Click icon * to view recently used programs, choose one of them by click and hold,
drag it to blank area to close the application
* This function only operated in the condition of Mouse mode
2.1.6 Back To Home Screen
Click icon to return to home screen
Click icon on remote control to return to home screen
2.1.7 Read External Storage Data
Read U Disk
Insert U flash disk or removable hard disk into USB port in the status of power on, icon
appears in top left corner of the desktop, open “FileBrowser”, the identified USB(A:) will
M8
User Manual
6
appear under “Local Disk”, U disk’s operation is available now
Read TF card
Insert TF card into the device in the status of power on, when icon appears in top left
corner of the desktop, open “FileBrowser”, the identified External Storage Card will appear
under “Local Disk”, TF card’s operation is available now
2.1.8 WIFI Function
Home Screen SETTINGSNetworkSelect“Wi-Fi”to open WIFI function
Choose hotspot Input PasswordConnect to the network
M8
User Manual
7
2.1.9 Ethernet Function
Home Screen SETTINGSNetworkSelect “Ethernet” to open Ethernet function
Insert network cable, network will be connected automatically
2.2
Advanced Operations
2.2.1 WLAN Hotspot
Operations on MXⅢ:
M8
User Manual
8
Home Screen SETTINGS OtherMore SettingMore…Portable hotspotSelect
“Portable Wi-Fi hotspot”
Select “Set up Wi-Fi hotspot” to set up“Network SSID”、“Security”、“Password”parameters
* Ensure connected to the wired network, MXⅢcan be used as wireless AP to support more
wireless devices access in the family
2.2.2 Miracast
Operations on MXⅢ
Home Screen My recommendMiracastOpen Miracast service
Operations on other devices (for example MIUI 2)
Home ScreenSettings WLANPress menu WLAN DisplayFind the devices
M8
User Manual
9
searched (MXⅢ), click invite
Corresponding device will be listed when MXⅢbegin to search, a pop-up invite window
appears, click “accept”
Complete connection, MXⅢwill display other device’s images
2.2.3 DLNA
Ensure other devices like Iphone, Android smart phone, etc have opened iMediaShare *,
Ensure them in the same local wireless LAN with MXⅢ
Operations on MXⅢ
Home ScreenMy recommendMedia CenterDLNA DMRStart DMRON
