Behringer DC9 Bedienungsanleitung

DYNAMICS COMPRESSOR DC9

Thank you for showing your confidence in us by purchasing the BEHRINGER DYNAMICS

COMPRESSORDC9.Thisultimateeffectspedalisspecificallydesignedtogiveastabledynamics

and an endless sustain to your guitar by evening out the signal without degrading the original

sound. You can also use the DC9 to boost the overall volume of your instrument for solo parts.

A compressor limits the dynamic range of a signal by attenuating signal peaks exceeding a

certain threshold level. The amount of gain reduction is determined by the compression ratio. The

result of compression is an attenuation of the difference between loudest and softest playing

which achieves a more powerful and punchy tone.

1. CONTROLS

Top view

The SENSITIVITY control determines the compression ratio. The higher you set the

SENSITIVITY value, the more the compression intensifies. In other words, as you increase

the SENSITIVITY, you reduce the level difference between softest and loudest playing.

The OUTPUT control adjusts the output level. Use it to compensate the gain reduction

resulting from the compression or to boost the output level of your instrument.

The LED illuminates when the effect is activated. It also serves as a battery level indicator.

Depress the footswitch to activate/deactivate the effect.

Use this 1/4" TS IN connector to plug in the instrument cable.

The 1/4" TS OUT connector sends the signal to your amp.

Use the DC IN connection to plug in a 9 V power supply (not included).

To install or replace the 9 V battery, remove the bottom side of the unit taking the four screws off.

The DC9 has no on/off switch. As soon as you connect the jack to the IN connector,

the DC9 is switched on. When the DC9 is not being used, remove the jack from

the IN to extend the battery life.

The SERIAL NUMBER is located on the bottom side of the device.

DYNAMICS COMPRESSOR DC9

2. WARRANTY

For our current warranty terms, please refer to our website at http://www.behringer.com.

3. SPECIFICATIONS

In Connector 1/4" TS

Impedance 1 MΩ

Out Connector 1/4" TS

Impedance 1 kΩ

Power supply 9 V , 100 mA regulated

BEHRINGERPSU-SB

USA/Canada 120 V~, 60 Hz

Europe/U.K./Australia 230 V~, 50 Hz

China/Korea 220 V~, 50/60 Hz

Japan 100 V~, 50/60 Hz

Power connector 2 mm DC jack, negative center

Battery 9 V type 6LR61

Power consumption 9 mA

Dimensions (H x W x D) approx. 56 mm (2 1/5") x 113 mm (4 2/5") x 69 mm (2 2/3")

Weight approx. 0.24 kg (0.53 lbs)

BEHRINGERisconstantlystriving tomaintain thehighest professionalstandards. Asa resultof theseefforts, modificationsmay bemade

fromtime totime toexisting productswithout priornotice. Specificationsand appearancemay thereforediffer fromthose listedor shown.

4. SAFETY INSTRUCTIONS

Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service product yourself. Contact our

qualified servicing personnel for servicing or repairs, especially when power supply cord or plug is damaged.

No utilizar cerca de agua o instalar cerca de fuentes de calor. Utilice sólo accesorios y aditamentos autorizados. No intenté reparar el producto

usted mismo. Contacte a nuestro personal técnico cualificado para servicio y reparaciones, especialmente cuando la fuente o el cable de

alimentación estén dañados.

Не эксплуатируйте прибор вблизи от источников воды и тепла. Применяйте только авторизованные дополнительные устройства.

Никогда не ремонтируйте прибор самостоятельно. Ремонт может производить только квалифицированный специализированный

персонал, особенно при повреждениях сетевого провода или сетевой вилки.

Die deutsche Anleitung ist erhältlich @ www.behringer.com

Manuel francophone en téléchargement sur www.behringer.com

Manualen españoldisponible en www.behringer.com

Manualiitaliani disponibili@www.behringer.com

Русскоязычное руководство @ www.behringer.com

Polska instrukcja dostępna jest pod adresem @ www.behringer.com

Nederlandsehandleiding beschikbaar@www.behringer.com

Suomenkielinen käyttöohje saatavilla osoitteesta www.behringer.com

Svensk manual finns tillgänglig på www.behringer.com

Dansk vejledning findes på @ www.behringer.com

Manualportuguês disponível @ www.behringer.com

Åëëçíéêü åã÷åéñßäéï õðÜñ÷åé äéáèÝóéìï óôç äéåýèõíóç www.behringer.com

Technicalspecifications andappearancesubject tochangewithoutnotice.Theinformationcontainedhereiniscorrect atthetimeofprinting.

BEHRINGERaccepts noliability foranylosswhichmaybesufferedbyanypersonwho relieseither whollyor inpart uponany description,

photographorstatementcontainedherein.Coloursand specificationmayvaryslightlyfromproduct.Productsaresoldthroughourauthorised

dealersonly.Distributorsand dealersarenotagentsofBEHRINGER andhaveabsolutelynoauthority tobindBEHRINGERbyany express

orimpliedundertaking orrepresentation.Nopartofthismanualmay bereproducedor transmittedinanyformorbyanymeans,electronicor

mechanical,including photocopyingandrecording ofany kind, forany purpose,withoutthe expresswritten permission ofBEHRINGER

InternationalGmbH.BEHRINGER,theBEHRINGER logoandJUST LISTENaretrademarksofBEHRINGER. ALLRIGHTSRESERVED.

Tel.+49 215492060, Fax+49215492064903
