Behringer Filter Machine FM600 Bedienungsanleitung

FILTER MACHINE FM600

Ultimate Filter Modeling Eects Pedal

Thank you for showing your condence in us by purchasing the BEHRINGER FILTER MACHINE FM600.

This Filter Modeler delivers the whole range from funky auto-wah, twin, band-pass to swirling low-pass

lter eects—at the touch of a footswitch. Discover the world of moving lters and take o with sounds

you have never heard before.

1. Controls

(1) The FILTER switch is used to select one of three lter types (BP=Band Pass, TF=Twin Filter

band pass, LP=Low Pass), which deliver completely dierent sounds. Cut-o and center

frequencies respond to the dynamics of your playing.

(2) The SENS knob determines the sensitivity of the lter and hence the level at which the lter

frequency modulation starts to work.

(3) The PEAK knob is used to dene the shape of the lter from narrow to wide.

(4) The POL switch determines whether the lter frequency moves up to higher frequencies (UP)

or down to lower frequencies (DOWN) according to the dynamics of your playing.

(5) With the RANGE knob, you can alter the travel range of the lter frequency.

(6) The ON/BATT LED lights up, as soon as the eect is activated. Furthermore, you can check the

status of the battery.

(7) The footswitch is used for switching the eect on/o.

(8) The ¼" TS connector (IN) connects to your instrument.

(9) The ¼" TS connector (OUT) sends the signal to your amp/combo.

Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the

9 V battery (not included), press the hinges with a ballpen and remove the pedal cover. Be careful not

to scratch the unit.

(6)

(2)

(1)

(9) (8)

(3)

(7)

(4)

(5)

FILTER MACHINE FM600

TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE

MUSIC GROUP (MUSIC-GROUP.COM). ALLTRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSICGROUP ACCEPTS NO LIABILITY FOR ANY LOSS

WHICH MAY BE SUFFERED BY ANY PERSONWHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN.

COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS

ONLY. FULLFILLERSAND RESELLERS ARE NOT AGENTS OF MUSICGROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSICGROUP BY ANY EXPRESS OR

IMPLIED UNDERTAKING OR REPRESENTATION.THIS MANUAL IS COPYRIGHTED. NO PART OFTHIS MANUAL MAY BE REPRODUCED ORTRANSMITTED IN ANY FORM

OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE,WITHOUT THE EXPRESS

Tortola, British Virgin Islands

◊ The FM600 has no On/O switch. It is operable as soon as you insert a plug into the

IN connector. Disconnect the plug, if you don’t use the FM600. In doing so, you can

extend the life time of the battery.

The SERIAL NUMBER is located at the underside.

◊ In rare cases interferences of the normal function may appear by external inuence

(e.g. electrostatic discharge), as for example sound disturbances or malfunctions.

If this occurs, please turn down the volume on subsequent ampliers and disconnect

the input connector briey to restart the application.

2. Safety Instructions

Do not use near water, or install near heat sources. Use only authorized attachments/accessories.

Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,

especially when power supply cord or plug is damaged.

3. Warranty

Please register your new BEHRINGER equipment right after your purchase by visiting http://behringer.com

and read the terms and conditions of our warranty carefully.

4. Specications

Connector ¼" TS

Impedance 500 kΩ

Out

Connector ¼" TS

Impedance 1 kΩ

Power Supply

9 V𝌂, 100 mA regulated

BEHRINGER PSU-SB

USA/Canada 120 V~, 60 Hz

Chinat/Korea 220 V~, 50/60 Hz

Europe/U.K./ 230 V~, 50 Hz

Australia

Japan 100 V~, 50 - 60 Hz

Export model 120/230 V~, 50 - 60 Hz

Power connector 2 mm DC jack,

negative center

Battery 9 V type 6LR61

Power consumption 60 mA

Physical/Weight

Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"

(H x W x D) approx. 54 x 70 x 123 mm

Weight approx. 0.73 lbs / 0.33 kg

BEHRINGER is constantly striving to maintain the

highest professional standards. As a result of these efforts,

modifications may be made from time to time to existing

products without prior notice. Specifications and appearance

may therefore differ from those listed or shown.

FEDERAL COMMUNICATIONS

COMMISSION COMPLIANCE INFORMATION

Responsible Party Name: MUSIC Group Services US Inc.

Address: 18912 North Creek Parkway,

Suite 200 Bothell, WA 98011,

USA

Phone Number: Phone: +1 425 672 0816

FILTER MACHINE FM600

complies with the FCC rules as mentioned in the followingparagraph:

This equipment has been tested and found to comply with the limits for a ClassB digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct the interference by one or

more of the followingmeasures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician forhelp.

This device complies with Part 15 of the FCC rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

Important information:

Changes or modications to the equipment not expressly approved by MUSIC Group can void

the user’s authority to use the equipment.

FILTER MACHINE FM600
