Behringer Flanger Machine FL600 Bedienungsanleitung

FLANGER MACHINE FL600

Ultimate Flanger Modeling Eects Pedal

Thank you for showing your condence in us by purchasing the BEHRINGER FLANGER MACHINE FL600.

This high-quality eects pedal delivers 11 extraordinary anger modes with extensive parameter control that

allow for maximum creativity so you always have the best sound regardless of the situation.

1. Controls

(1) The TYPE switch lets you choose between

a high-delity, DIGI(tal) anger with a

at frequency response, a vintage-type,

ANALOG bucket-brigade delay with ltered

frequency response and a classic studio

anger from the ‘70s (TAPE).

(2) With the TIME control, you can adjust the

anger delay time. Longer delay times produce

a sharper, more detuned sound, very close to a

chorus eect.

(3) The SPEED control determines the speed of the

anger eect. In CHORUS, VINTAGE, SINE,

SAW UP and SAW DOWN modes, turning this

control to the MIN(imum) brings the LFO to a halt.

(4) The F.BACK control determines the amount of

output signal fed back into the anger input in

order to confer more or less intensity to the eect.

(5) The blue ON/BATT LED illuminates when the eect is activated. It also serves as a battery level indicator.

(6) Turn up the DEPTH control to achieve a fuller and deeper eect sound.

(7) This control lets you choose between dierent anger eect modes:

TRG DWN: The modulation signal triggers a linearly falling wave envelope with a falling time

determined by the SPEED control.

TRG UP: The same as TRG DWN but with a linearly rising wave envelope.

CHORUS: The signal is modulated by a wide-range, triangular wave with a large oset producing a chorus-like eect.

VINTAGE: A simulation of the classic MXR anger.

RANDOM: A random value generator produces a modulation signal whose level varies with each cycle

of the LFO, which has a smoothing lter applied to the output.

STEP: The same as RANDOM but without the smoothing lter at the LFO’s output.

SINE: The signal is modulated by a sine wave.

ENV UP: The anger’s delay time is modulated according to the amplitude variations in the input signal as

detected by an envelope follower.

ENV DOWN: The inverted version of ENV UP.

SAW UP: A positive sawtooth wave modulates the signal.

SAW DOWN: A negative sawtooth wave modulates the signal.

(8) POL lets you choose between NEG(ative) and POS(itive) feedback anger modes.

(9) Use the two ¼" TS connectors IN A and IN B to plug in a stereo input signal. For mono use connect to IN A.

(10) The two ¼" TS connectors OUT A and OUTB send the signal to your amp. Use both outputs to achieve a

full stereo eect. For mono use, connect to OUT A.

In CHORUS, VINTAGE, SINE, SAW UP and SAW DOWN stereo modes, both channel signals are processed

with inverted phase LFOs. In SAW UP and SAW DOWN mono modes, both delay lines are mixed to create a

continuous rise/fall signal.

(3)

(2)

(7)

(8)

(11)

(10) (9)

(5)

(1)

(4) (6)

FLANGER MACHINE FL600

TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER, KLARK TEKNIK,

MIDAS, BUGERA, ANDTURBOSOUND ARE PART OF THE MUSIC GROUP (MUSIC-GROUP.COM).. ALLTRADEMARKS ARE THE PROPERTY OFTHEIR RESPECTIVE OWNERS.

MUSICGROUP ACCEPTS NO LIABILITY FOR ANY LOSSWHICH MAY BE SUFFERED BY ANY PERSONWHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION,

PHOTOGRAPH OR STATEMENT CONTAINED HEREIN. COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH

AUTHORIZED FULLFILLERS AND RESELLERS ONLY. FULLFILLERSAND RESELLERS ARE NOT AGENTS OF MUSICGROUP AND HAVE ABSOLUTELY NO AUTHORITYTO BIND

MUSICGROUP BY ANY EXPRESS OR IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OFTHIS MANUAL MAY BE REPRODUCED

OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE,

P.O. Box 146, RoadTown,Tortola, BritishVirgin Islands

(11) Press the footswitch to activate/deactivate the eect. Depress the pedal (>2 s) to set the anger’s speed by

tapping the pedal to the desired tempo. Depress the pedal once again (>2 s) to quit the set tempo function.

Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery

(not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful not to scratch the unit.

◊ The FL600 has no on/o switch. As soon as you insert the plug into the in connector, the FL600 is on.

When not using the FL600, remove the plug from the in connector. This extends the life of the battery.

The SERIAL NUMBER is located at the underside.

◊ In rare cases interferences of the normal function may appear by external inuence

(e.g. electrostatic discharge), as for example sound disturbances or malfunctions. If this occurs,

please turn down the volume on subsequent ampliers and disconnect the input connector briey

to restart the application.

2. Safety Instructions

Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service

product yourself. Contact our qualied servicing personnel for servicing or repairs, especially when power supply

cord or plug is damaged.

3. Warranty

Please register your new BEHRINGER equipment right after your purchase by visiting http://behringer.com

and read the terms and conditions of our warranty carefully.

4. Specications

In A

Connector ¼" TS

Impedance 500 kΩ

In B

Connector ¼" TS

Impedance 1 kΩ

Out A

Connector ¼" TS

Impedance 1 kΩ

Out B

Connector ¼" TS

Impedance 1 kΩ

Power Supply

9 V𝌂, 100 mA regulated

BEHRINGER PSU-SB

U.S.A./Canada 120 V~, 60 Hz

China 220 V~, 50 Hz

Korea 220 V~, 60 Hz

Europe/U.K./ 230 V~, 50 Hz

Australia

Japan 100 V~, 50 – 60 Hz

Power connector 2 mm DC jack,

negative center

Battery 9 V type 6LR61

Power consumption 60 mA

Physical/Weight

Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"

(H x W x D) approx. 54 x 70 x 123 mm

Weight approx. 0.73 lbs / 0.33 kg

BEHRINGER is constantly striving to maintain the

highest professional standards. As a result of these efforts,

modifications may be made from time to time to existing

products without prior notice. Specifications and appearance

may therefore differ from those listed or shown.
