These loudspeakers take everything

musicians love about the original

B212 and B215 loudspeakers and upgrade

them with the same bass and tre sducers

found in our wildly popular B212A/

B215A active versions for even better

sound and power handling. And with

integrated overload protection circuitry,

these loudspeakers arrive ready to push it

to the limit without putting their high-or

low-frequency drivers in danger.

Triumphant transducers

Every stitch of these loudspeakers is

built to deliver, but the fact is that their

transducers (woofers and tweeters)

are the only part you actually hear.

While some manufacturers are okay

with putting o-the-shelf transducers

in their boxes, we custom-design and

build ours from scratch. Not only do

we wind our own voice coils, we grow

the trees that are processed into

the paper pulp that becomes

the cones. We even machine the frames

and backplates. BEHRINGER’s quality is

truly under control.

Big sound, lightweight, low price

Big here, small there, lots of this,

light on that—everyone’s got their

preferences, but the EUROLIVE B212XL

and B215XL have proportions we can

all agree upon. These loudspeakers

pack a clean, punchy wallop (and can

handle up to 800 and 1000 Watts,

respectively), they are easy to lift by

their recessed handles (24 lbs / 38.7 lbs)

and are available at insanely low prices.

Who wouldn’t want to hook up with one

of these beauties?

EUROLIVE - 1000-Watt/800-Watt

2-Way PA Speaker System with

15"/12" Woofer and 1.75" Titanium

Compression Driver

Continued on page 3

High-power 2-way PA sound

reinforcement speaker system

for live and playback applications

(200 Watts Continuous / 800 Watts

Peak Power and 250 Watts

Continuous / 1000 Watts Peak Power)

Available in black or white nish

Ultra-compact and light weight

system delivers excellent sound even

at extreme sound pressure levels

Extremely powerful 12"/15" long-

excursion driver provides incredibly

deep bass and acoustic power

State-of-the-art 1.75" titanium-

diaphragm compression driver for

exceptional high-frequency

reproduction

Ultra-wide dispersion, large-format

exponential horn

Overload-protection circuitry ensures

optimal HF driver protection

Versatile trapezoidal enclosure design

allows dierent positioning:

• Stand mounting with 35-mm

pole socket

• Tilts on its side for use as a

oor monitor

Optional swiveling mounting

brackets available (sold separately)

EUROLIVE

B215XL/B212XL

B215XL-WH/B212XL-WH

Professional Passive Speakers

Page 2 of 4

Stereo separation with a subwoofer

EUROLIVE B212XL/B215XL

XENYX 2442USB

EUROPOWER EP2000

Mono Subwoofer

Output

SUPER-X PRO CX2310

L R

B1800X

Wiring several B212XL/B215XL loudspeakers

XENYX 2442USB

EUROPOWER

EP2000

EUROLIVE B212XL/B215XL

Ergonomically shaped handles for

easy carrying and setup

2 professional speaker connectors

plus ¼" jack connectors

High-quality components and

exceptionally rugged construction

ensure long life

Conceived and designed by

BEHRINGER Germany

EUROLIVE

B215XL/B212XL

B215XL-WH

B212XL-WH

Page 3 of 4

Get on the stick…or get on down

The B212XL and B215XL are perfect either

as part of a PA system or as onstage monitors.

If the situation calls for a PA, mount the

speakers on stands via the 35mm pole socket.

From there, send a line from the MAIN OUT of

a mixer (such as a XENYX 1202FX) to a power

amplier (like the EUROPOWER EP2000).

Finally, attach a B212XL or B215XL to each of

the amp’s outputs. These loudspeakers have

inputs for both professional speaker cable and

¼" cable. Because these loudspeakers have two

parallel inputs, you can connect up to two of

them to any channel on a power amp.

But these loudspeakers don’t have to be

conned to an upright position. Just lay them on

their sides for use as a oor monitor. You’ll nd

that they tilt to the ideal angle for onstage

monitor wedge applications.

Choose white, black, on or o the wall…

You asked for it, and now we’re proud to

oer these amazing loudspeakers in black or

white. We now also make swiveling wall-mount

brackets for the B212XL and B215XL. That means

they’re ready to t even more comfortably into

a venue’s color scheme and layout (WB212 and

WB215 for black brackets or WB212-WH and

WB215-WH for white). No matter what your

sound or aesthetic needs may be, we make one

that’s just right for you!

Ultra-wide

dispersion and

large format

exponential horn

1.75" titanium

diaphragm

compression driver

for high-frequency

reproduction

Ergonomically

shaped carry

handles on

each side of

enclosure

Impact resistant,

molded enclosure

12"/15" long-

excursion LF

transducer

provides deep

bass and

acoustic power

1 /" (35-mm)

pole socket

for use with

standard

speaker stands

Large openings for

powerful low-end

reproduction

Rubber feet for

stacking enclosure

on structures or

subwoofers

Parallel ¼"

loudspeaker

inputs

Professional

speaker inputs

wired in parallel

336.00 mm [13.2283 in]

436.00 mm [17.1653 in]

695.25 mm [27.3719 in]

272.00 mm [10.7086 in]

348.80 mm [13.7322]

549.64 mm [21.6394]

B212XL B215XL

EUROLIVE

B215XL/B212XL

B215XL-WH

B212XL-WH

Page 4 of 4

For service, support or more information contact the BEHRINGER location nearest you:

Europe

MUSIC Group Services UK

Tel: +44 156 273 2290

Email: [email protected]om

USA/Canada

MUSIC Group Services NV Inc.

Tel: +1 702 800 8290

Email: [email protected]om

Japan

MUSIC Group Services JP K.K.

Tel.: +81 3 6231 0454

Email: [email protected]om

Technical speciﬁcations and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss

which may be suﬀered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and speciﬁcations may vary from actual product. MUSIC Group products are sold through authorized fullﬁllers and resellers only.

Fullﬁllers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any

means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,

Tortola, BritishVirgin Islands. 985-10000-00350

SYSTEM DATA

B215XL

High-performance woofer 15" / 381 mm

B212XL

High-performance woofer 12" / 305 mm

B215XL / B212XL

Tweeter compression driver 1.75" / 44 mm

B215XL

Frequency range 55 Hz to 20 kHz

B212XL

Frequency range 65 Hz to 18 kHz

B215XL

Power rating 1000 W Peak Power 250 W

Continuous Power (IEC 60268-5)

B212XL

Power rating 800 W Peak Power 200 W

Continuous Power (IEC 60268-5)

B215XL / B212XL

Impedance 8 

B215XL

Sensitivity (1 W @ 1 m) 96 dB (Full Space)

B212XL

Sensitivity (1 W @ 1 m) 95 dB (Full Space)

B215XL

Dispersion 70° x 40°

B212XL

Dispersion 90° x 60°

B215XL

Crossover frequency 2.0 kHz

B212XL

Crossover frequency 1.9 kHz

DIMENSIONS/WEIGHT

B215XL

Dimensions (HxWxD) approx. 27 ⁄ x 17 ⁄ x 13 ⁄"

approx. 695 x 440 x 335 mm

Weight 38.7 lbs / 17.6 kg

B212XL

Dimensions (HxWxD) approx. 21 ⁄ x 13 ⁄ x 10 ⁄"

approx. 550 x 345 x 270 mm

Weight 24.0 lbs / 10.9 kg

Please note these specications are preliminary and conceptual in nature,

and as such are subject to change as product development progresses.

This information is supplied for market research purposes only and is not

to be made public in any manner. This document is solely the property of

The MUSIC Group, or one of its subsidiaries, and must be surrendered upon

request of the owner.

EUROLIVE

B215XL/B212XL

B215XL-WH

B212XL-WH
