Behringer ULTRABAS BX4210A Bedienungsanleitung

Version 1.2 June 2006

Specifications

ULTRABASS BX4210A

BX4210A

ULTRABASS

450-Watt Bass Workstation with 2 Original BUGERA 10 Aluminum-Cone Speakers and 1 Horn Driver

* German Patent No.: 100 15 833

** Neutrik® and Speakon® are registered trademarks of the respective o ner and are not affiliated ith BEHRINGER®

sPowerful 450-Watt Bass Workstation with front-ported bass abinet

s2 original BUGERA 10" Hard Atta k aluminum- one speakers

sCustom-made 1" horn tweeter for ultimate pun h

sRe essed arrying handles and integrated rollers for easy transportation

sPatented* Dynamizer te hnology for ultimate pun h and to apture every nuan e of your playing

sSwit hable Ultrabass sub-harmoni s pro essor for unbelievable low-end power

sDedi ated 5-band EQ with Deep, Bright and Shape fun tions for awesome sound shaping

sMusi al opto-limiter for ultimate volume without distortion

sVintage-style VU meter for pre ise signal level ontrol

sDual footswit h for Ultrabass and Shape fun tions in luded

sBalan ed DI output for dire t onne tion to your mixing onsole

sDedi ated Tuner Output/Effe t Send and separate Line Output for additional flexibility

sFX Insert for external effe ts devi es (stomp boxes, ra k effe ts, et .)

s3 speaker outputs on 1/4" ja ks and professional speaker onne tor ( ompatible to Neutrik® Speakon®)**

sIntegrated limiter and a tive, temperature- ontrolled ooling system for ultimate prote tion

sHigh-quality omponents and ex eptionally rugged onstru tion ensure long life

sCon eived and designed by BEHRINGER Germany

ULTRABASS BX4210A

SPECIFICATIONS

AUDIO INPUTS

Active instrument input 1/4" TS connector, unbalanced

Input impedance approx. 220 kW unbalanced

Passive instrument input 1/4" TS connector, unbalanced

Input impedance approx. 750 kW unbalanced

Return 1/4" TS connector, unbalanced

Input impedance approx. 10 kW unbalanced

AUDIO OUTPUTS

Send/Tuner 1/4" TS connector, unbalanced

Output impedance min. 2.2 kW unbalanced

Line Out 1/4" TS connector, unbalanced

Output impedance approx. 100 W unbalanced

Output level max. +4 dBu

D.I. output XLR connector, servo-balanced

Output impedance approx. 100 W balanced

Output level max. -10 dBu

Loudspeaker connectors 1/4" TS connector, unbalanced

professional connector

(compatible to Neutrik® Speakon®)

Load impedance min. 4 W

SYSTEM SPECIFICATIONS

Po er amp output 450 Watts into 4 W

SPEAKERS

High-po er bass speakers 2 x 10" BUGERATM

Aluminum cone speakers

Sensitivity 93 dB @ 1 W / 1 m

SPL max. 120 dB

Impedance 2 x 4 W

Frequency response 42 Hz - 16 kHz

Po er (program) 500 W

T eeter 1" t eeter driver

POWER SUPPLY

Mains voltages U.S./Canada

120 V~, 60 Hz, 6 A

China/Korea

220 V~, 50 Hz, 3 A

Europe/U.K./Australia

230 V~, 50 Hz, 3 A

Japan

100 V~, 50/60 Hz, 6 A

General export model

120/230 V~, 50 - 60 Hz

Fuse 100 - 120 V~: T 10 A H 250 V

220 - 240 V~: T 6.3 A H 250 V

Mains connection Standard IEC receptacle

PHYSICAL/WEIGHT

Dimensions (H x W x D) approx. 24 7/10" (627 mm)

x 26 1/2" (674 mm)

x 14 3/5" (370 mm)

Weight approx. 39 kg (86 lbs)

BEHRINGER constantly strives to maintain the highest quality standards. Modifi-

cations may be made if necessary without prior notice. The specifications and appearance

of the equipment may therefore differ from those listed or illustrated.

Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time of printing. The names

of companies, institutions or publications pictured or mentioned and their respective logos are registered trademarks of their respective owners. Their use

neither constitutes a claim of the trademarks by BEHR NGER nor affiliation of the trademark owners with BEHR NGER. BEHR NGER accepts no

liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained

herein. Colours and specification may vary slightly from product. Products are sold through our authorised dealers only. Distributors and dealers are not

agents of BEHR NGER and have absolutely no authority to bind BEHR NGER by any express or implied undertaking or representation. No part of this

manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for

any purpose, without the express written permission of BEHR NGER nternational GmbH. BEHR NGER® is a registered trademark.

Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide , Germany.

Tel. +49 2154 9206 0, Fax +49 2154 9206 4903
