BJA1500 USER MANUAL
(1500ML/L ULTRASONIC ATOMIZER)
Beijing Ultrasonic Co., Ltd
Address:10 Bogart Road, Lucheng Town,
Tongzhou District ,Beijing.China
E-Mail:[email protected]
www.bjultrasonic.com
2
一: Specification
Type
BJA1500
Size
99*27(diameter*height)
Power
150w
Atomization Amout
1500ml/h
Input Voltage
AC 200-240v /50Hz
100-120v/60Hz
Output Voltage
AC36V
Size of piezoceramics
20*1.7MHZ
Working temperature
+1℃~50℃
Level of water
40~80mm
Length of cable
5M
Input current
3A-3.5A
Overheating protection
50℃
Pictures Showing:
Product Advantage:
1.Copper shell.Plating nickel chrome.Good heat dissipation.
2.Atomized particles small.
3.Humidification efficiency:a large quantity of humidification,humidification significantly faster
results.
4.Overheating protection and Lack water protection.
Beijing Ultrasonic Co., Ltd
Address:10 Bogart Road, Lucheng Town,
Tongzhou District ,Beijing.China
E-Mail:[email protected]
www.bjultrasonic.com
3
5.Easy to replace the disc piezoceramics and clean the piezoceramics.
二:Brief Introduction
ultrasonic negative ionizing mist maker is technological product,which its integration of aroma
diffuser and air refresher,help to freshen air,and the mist will add air humidity and clear static
electricity,all the things are well for human body.If adding one or two drops of disinfectant or
aroma liquid,not only it can disinfect and sterilize the air,but also make the room full of fragrant
air.
Make sure put the mist maker in water,it can easily be misting. Its wide usage is in different craft
article,rokery garden fountain decoration and beautification range, also in the hotel place,even the
appliance installation of industry humidification.
三:Operating Instructions
1.When take out the mist maker from the package(please don’t crash the water level sensor).Please
put the mist maker placidly in the float,then put it in the water container.
If you will not use the float,the best working effect is keeping 30mm to 50mm of water above
ceramic disc,If water is too deep, it can not spray mist, but if water is too shallow, it will stop to
spray mist automatically,also when the water –lever sensor switch is out of water. It will also stop
to work.
Pls notice that there are no obstacles within the scope of more than 100mm space of the sprayer
ceramic water level(please check the drawing 1).
2.The Spray indicator light will be bright after connecting the mist maker with power supply,then
the ultrasonic atomizer will work.
Beijing Ultrasonic Co., Ltd
Address:10 Bogart Road, Lucheng Town,
Tongzhou District ,Beijing.China
E-Mail:[email protected]
www.bjultrasonic.com
4
If the spray lights flash and the atomizer don’t work, this mean that there was not enough water.
3. As the mist maker normally working, the water in the container will constantly evaporate,when
the water is below the water level sensor,it will automatically be protected and stop misting,at this
time the spray lights will flash. After adding the water above the water level sensor,it continues
misting.
4.At the beginning of the work, the atomization quantity may be small,it will be stable misting and
become large after working sometime.When the winter is coming,the weather will affect the
misting rate,you can put some hot water to speed its stable misting rate.
5.When you don’t use the mist maker for a long time,please make sure pull the transformer/adapter
input lead wires out,which can avoid the accident/ unfortunate happening.
四:Matters Needing Attention,Services and Maintenance
1.Pls operate them accotding to our instructions. Check the input voltage of transformer(generator)
if it’s suitable your local voltage standard before using.
2.When the mist maker normally work,inevitable meeting produces certain heat caused by
temperature rise,at this time,we need to pour enough water in the container to heat eliminate.
Generally the volume of water should be greater than 20 litres(in order to ensure the mist maker
normally working,it should be enough water in the container,so pls make sure more than 20 litres
water in the container).
The bottom of mist maker can’t be less than 180mm high away from the container, or can’t be less
than 10 litres water in the container.This can improve the heat dissipation capacity,If the water
under the floating status or well elimination condition,the water will be reduced.
3.Please don’t be covered by sundries above the mist maker,and hold more than 100mm space of
the sprayer,also can’t put the atomizer in the sealed container.
4.Please don’t let the mist maker work under the high temperature water,when the temperature
exceed 50℃, the hyperthermia/ superheating protection can play the important part, the misting
will be stopped,only the indication light shines, when the water temperature is below 40℃, it will
normally continue working.It is not allowed to work under the freezing environment.
5.Please don’t put it beside the TV or other electric equipment ,avoid from damaging them when
the mist maker produces misting
6.Suited Transformer/Adapter/Generator should keep away from the sprayer, and the sprayer water
can spill out and make it wet directly,due to the plug which is connected to the sprayer can’t be put
Beijing Ultrasonic Co., Ltd
Address:10 Bogart Road, Lucheng Town,
Tongzhou District ,Beijing.China
E-Mail:[email protected]
www.bjultrasonic.com
5
it into the water or wet.
7.In order to ensure the mist maker/sprayer/atomizer normally working under the nice
environment,please change the water every week,and use the clean soft cloth or rag to clean the
ceramic and water level sensor,but don’t use the chemical agent to clean,even also can’t use hard
or edge tool.
8.When the mist maker works,don’t put your hand above the sprayer,or else it will make you smart
feeling.
9.Although the adapter(transformer) for mist maker is used in outdoor ,but it can’t allow to be put
into the water.
五:Replace Method of Disc Piezoelectric Ceramic
after the mist maker is used for a long time,its misting rate will be reducing,you can replace the
ceramic disc to make it normally working at this time.
Methods as follows:
1.Use the ceramic disc key to wring out the copper ring with anticlockwise direction,and take it
out,please see clearly the ceramic disc face and bottom side.
2.Put the new ceramic disc on the original place(Please take attention to the installation direction
accorded with the same as original one.)
3.Put the copper ring,and use the ceramic disc key to screw down with the clockwise direction.
4.Please put the mist maker in the water container again,it can normally work as before.
