DPY 7406 GXB3

Dryer

User Manual

Asciugatrice

Manuale utente

2960310997_EN/270315.1713

2 / 60 EN

Dryer / User Manual

Please read this user manual first!

Dear Customer,

Thank you for prefering a Beko product. We hope that your product which has been manufactured with high quality

and technology will give you the best results. We advise you to read through this manual and the other accompanying

documentation carefully before using your product and keep it for future reference. If you transfer the product to

someone else, give its manual as well. Pay attention to all details and warnings specified in the user manual and

follow the instructions given therein.

Use this user manual for the model indicated on the cover page.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful hints about

usage.

AWarning for hazardous situations with

regard to life and property.

BWarning against electric shock.

Warning against hot surfaces.

Warning against fire hazard.

Packaging materials of the product are

manufactured from recyclable materials in

accordance with our National Environment

Regulations.

Do not dispose of the packaging wastes with the domestic waste or other wastes, discard them to the dedicated

collection points designated by the local authorities.

3 / 60 EN

Dryer / User Manual

1 Important instructions for safety and

environment

This section contains safety instructions that will help protect from risk of

personal injury or property damage. Failure to follow these instructions shall

void any warranty.

1.1 General safety

•The dryer can be used by children at and above 8 years old and by

persons whose physical, sensory or mental capabilities were not fully

developed or who lack experience and knowledge provided that they

are supervised or trained on the safe usage of the product and the risks

it brings out. Children should not play with the product. Cleaning and

maintenance works should not be performed by children unless they are

supervised by someone.

•Children of less than 3 years should be kept away unless continously

supervised.

•Adjustable feet should not be removed. The gap between the dryer and

the floor should not be reduced with materials such as carpet, wood and

tape. This will cause problems with the dryer.

•Always have the installation and repairing procedures carried out by the

Authorized Service. Manufacturer shall not be held liable for damages

that may arise from procedures carried out by unauthorized persons.

•Never wash the dryer by spraying or pouring water onto it! There is the

risk of electric shock!

4 / 60 EN

Dryer / User Manual

Important instructions for safety and environment

1.1.1 Electrical safety

AElectrical safety instructions should be followed while electrical

connection is made during the installation.

•Connect the dryer to a grounded outlet protected by a fuse at the value

specified on the type label. Have the grounding installation performed by

a qualified electrician. Our company shall not be liable for any damages

that will arise when the dryer is used without grounding in accordance

with the local regulations.

•The voltage and allowed fuse protection is stated on the type label plate.

•The voltage specified on the type label must be equal to your mains

voltage.

•Unplug the dryer when it is not in use.

•Unplug the dryer from the mains during installation, maintenance,

cleaning and repair works.

•Do not touch the plug with wet hands! Never unplug by pulling on the

cable, always pull out by grabbing the plug.

•Do not use extension cords, multi-plugs or adaptors to connect the dryer

to power supply in order to decrease the risk of fire and electric shock.

•Power cable plug must be easily accessible after installation.

BDamaged mains cable should be changed notifying the Authorized

Service.

BIf the dryer is faulty, it must not be operated unless it is repaired

by an authorized service agent! There is the risk of electric shock!

5 / 60 EN

Dryer / User Manual

Important instructions for safety and environment

1.1.2 Product safety

Points to be taken into consideration for fire hazard:

Below specified laundry or items must not be dried

in the dryer considering fire hazard.

•Unwashed laundry items

•Items soiled with oil, acetone, alcohol, fuel oil, kerosene, stain

removers, turpentine, paraffin or paraffin removers must be

washed in hot water with plenty of detergent before being dried

in the dryer.

For this reason especially the items containing the above

specified

stains must be washed very well, to do this

use adequate detergent and choose a high washing

temperature.

Below specified laundry or items must not be dried in the

dryer due to the fire hazard:

•Garments or pillows bolstered with rubber foam (latex foam),

shower bonnets, water resistant textiles, materials with rubber

reinforcement and rubber foam pads.

•Clothing cleaned with industrial chemicals.

Items such as lighter, match, coins, metal parts, needle etc.

may damage the drum set or may lead to functional problems.

Therefore check all the laundry that you will load into your dryer.

Never stop your dryer before

the programme completes. If you must do this, remove all

laundry

quickly and lay them out to dissipate the heat.

Clothes that are washed inadequately may ignite on their own

and even may ignite after drying ends.

6 / 60 EN

Dryer / User Manual

Important instructions for safety and environment

•You must provide enough ventilation in order to prevent gases exiting from

devices operating with other types of fuels including the naked flame from

accumulating in the room due to the back fire effect.

AUnderwear that contains metal reinforcements should not be

dried

in the dryer. Dryer may be damaged if metal reinforcements come

loose and break off during drying.

CUse softeners and similar products in accordance with the

instructions of their manufacturers.

CAlways clean the lint filter before or after each loading. Never

operate the dryer without the lint filter installed.

•Never attempt to repair the dryer by yourself. Do not perform any repair

or replacement procedures on the product even if you know or have the

ability to perform the required procedure unless it is clearly suggested in

the operating instructions or the published service manual. Otherwise, you

will be putting your life and others’ lives in danger.

•There must not be a lockable, sliding or hinged door that may block

the opening of the loading door in the place where your dryer is to be

installed.

•Install your dryer at places suitable for home use. (Bathroom, closed

balcony, garage etc.)

•Make sure that pets do not enter the dryer. Check the inside of the dryer

before operating it.

•Do not lean on the loading door of your dryer when it is open, otherwise it

may fall over.

•The lint must not be allowed to accumulate around the tumble dryer

7 / 60 EN

Dryer / User Manual

Important instructions for safety and environment

1.2 Mounting over a washing machine

•A fixing device should be used between the two machines when installing

the dryer above a washing machine. The fitting device must be installed

by the authorized service agent.

•Total weight of the washing machine and the dryer -with full load- when

they are placed on top of each other reaches to approx. 180 kilograms.

Place the products on a solid floor that has sufficient load carrying

capacity!

AWashing machine cannot be placed on the dryer. Pay attention

to the above warnings during the installation on your washing

machine.

Installation Table for Washing Machine and Dryer

Dryer Depth Washing Machine Depth

62cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm

54 cm Can be

installed Can be

installed Cannot be

installed

60 cm Can be

installed Can be

installed Cannot be

installed

8 / 60 EN

Dryer / User Manual

Important instructions for safety and environment

1.3 Intended use

•Dryer has been designed for domestic use. It is not suitable for

commercial use and it must not be used out of its intended use.

•Use the dryer only for drying laundry that are marked accordingly.

•The manufacturer waives any responsibility arisen from incorrect usage or

transportation.

•The service life of the dryer that you purchased is 10 years. During this

period, original spare parts will be available to operate the dryer properly.

1.4 Child safety

•Packaging materials are dangerous for the children. Keep packaging

materials away from children.

•Electrical products are dangerous for the children. Keep children away

from the product when it is operating. Do not let them tamper with the

dryer. Use the child-proof lock in order to prevent the children to tamper

with the dryer.

CChild-proof lock is on the control panel. (See Child lock)

•Keep loading door closed even when the dryer is not in use.

9 / 60 EN

Dryer / User Manual

Important instructions for safety and environment

1.5 Compliance with the WEEE regulation

and disposing of the waste product

This product complies with EU WEEE Directive (2012/19/EU). This

product bears a classification symbol for waste electrical and

electronic equipment (WEEE).

This product has been manufactured with high quality parts and

materials which can be reused and are suitable for recycling. Do

not dispose of the waste product with normal domestic and other

wastes at the end of its service life. Take it to the collection center for the

recycling of electrical and electronic equipment. Please consult your local

authorities to learn about these collection centers.

Compliance with RoHS Directive:

The product you have purchased complies with EU RoHS Directive

(2011/65/EU). It does not contain harmful and prohibited materials

specified in the Directive.

1.6 Package information

Packaging materials of the product are manufactured from recyclable

materials in accordance with our National Environment Regulations. Do

not dispose of the packaging materials together with the domestic or other

wastes. Take them to the packaging material collection points designated

by the local authorities.

Please visit the following website to get more information on the product.

http://www.beko.com

10 / 60 EN

Dryer / User Manual

Important instructions for safety and environment

1.7 Technical Specifications

* Min. height: Height with adjustable feet are closed.

Max. height: Height with adjustable feet are opened maximum.

** Dry laundry weight before washing.

*** Type label is located behind the loading door.

CTechnical specifications of the dryer are subject to specification

without notice to improve the quality of the product.

CFigures in this manual are schematic and may not match the

product exactly.

Values stated on markers on the dryer or in the other published

documentation accompanying with the dryer are obtained in

laboratory in accordance with the relevant standards. Depending

on operational and environmental conditions of the dryer, these

values may vary.

Height (min. / max.) 84,6 cm / 86,6 cm*

Width 59,5 cm

Depth 60,9 cm

Capacity (max.) 7 kg**

Net weight (plastic front door usage) 50,5 kg

Net weight (glass front door usage) 52,5 kg

Voltage

See type label***Rated power input

Model code

Inhaltsverzeichnis

Sprachen:

Andere Beko Trockner Handbücher

Beko

Beko DS8539CH Bedienungsanleitung

Beko

Beko DPY 8507 GXB1 Bedienungsanleitung

Beko

Beko DP 8045 CW Montageanleitung

Beko

Beko DTKCE70021W Bedienungsanleitung

Beko

Beko DRX 823 N Bedienungsanleitung

Beko

Beko DCU 7330 XB Bedienungsanleitung

Beko

Beko DU 8112 GA0 Bedienungsanleitung

Beko

Beko DS 7139 TX Bedienungsanleitung

Beko

Beko BT393SB Bedienungsanleitung

Beko

Beko DRY 733 CI Bedienungsanleitung

Beko

Beko DPS 7205 GB5 Bedienungsanleitung

Beko

Beko DH 8736 RX0 Bedienungsanleitung

Beko

Beko DCY 9316 W Bedienungsanleitung

Beko

Beko DF7330PX0 Bedienungsanleitung

Beko

Beko DTBP10011W Bedienungsanleitung

Beko

Beko B3T43113W Bedienungsanleitung

Beko

Beko DCY 9316 W Bedienungsanleitung

Beko

Beko DV 2570 X Bedienungsanleitung

Beko

Beko B5T69253W Bedienungsanleitung

Beko

Beko BDV 7200X Bedienungsanleitung

Beko

Beko DG 8540 SX Bedienungsanleitung

Beko

Beko DPS 7405 W3 Bedienungsanleitung

Beko

Beko DCU 7230BX Bedienungsanleitung

Beko

Beko DCU 9330 Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung

Frigidaire

Frigidaire CAQE7077KW0 Betriebsanleitung
