Freezer

User manual

Please read these instructions first before using your appliance

Thank you for choosing a Beko appliance.

Please take some time to read this user manual before using your appliance, to

ensure you know how to safely operate the controls and functions.

Carefully follow all unpacking and installation instructions to ensure the

appliance is correctly connected and fitted prior to use.

Please write your product model and serial number on the last page of this

user manual, and store in a safe location close to the appliance for easy future

reference.

This user manual may also be applicable for several other models. Differences

between models will be listed.

If you have any questions or concerns, please call our contact centre or find

help and information online at www.beko.co.uk

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

SUPPLIER’S NAME MODEL IDENTIFIER (*)

INFORMATION

The model information as stored in the product data base

can be reached by entering following website and searching

for your model identiﬁer (*) found on energy label.

https://eprel.ec.europa.eu/

1 Your Freezer 3

2 Warnings 4

Electrical requirements........................... 5

Warning! This appliance must be

earthed.......................................................... 5

Energy saving tips.....................................6

Compliance with WEEE Directive and

Disposing of the Waste Product: ....... 7

Compliance with rohs directive: ......... 7

Package information................................ 7

3 Installation 8

Points to be paid attention to when the

relocation of the freezer ........................8

Electrical connection ...............................9

Disposing of the packaging...................9

Disposing of your old freezer...............9

Placing and Installation.........................10

4Before operating 12

Starting........................................................12

5 Using your freezer 13

6 Maintenance and

cleaning 14

7 Do's and Don'ts 15

Problem Solving .......................................16

CFigures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1Your Freezer

Congratulations on your choice of a Beko quality Appliance which has been

designed to give you service for many years.

1. Thermostat

2. Flap (Fast-Freeze compartment)

3. Drawers

4. Adjustable front feet

2Warnings

 Do not connect your

appliance to the electricity

supply until all packing and

transit protectors have been

removed.

 If transported horizontally

leave to stand upright for at

least 4 hours before switching

on to allow compressor oil to

settle

 If you are discarding an old

refrigerator with a lock or latch

fitted to the door, disable the

lock/latch, ensure that it is left

in a safe condition to prevent

the entrapment of young

children.

 This freezer must only be

used for its intended purpose

i.e the storing and freezing of

edible foodstuff.

 Do not dispose of the

appliance on a fire. At Beko,

the care and protection

of our environment is an

ongoing commitment. This

appliance which is among

the latest range introduced

is particularly environment

friendly. Your appliance

contains non CFC / HFC

natural substances in the

cooling system (Called

R600a) and in the insulation

(Called cyclopentane) which

are potentially flammable if

exposed to fire. Therefore,

take care not to damage, the

cooling circuit / pipes of the

appliance in transportation

and in use. In case of damage

do not expose the appliance

to fire or potential ignition

source and immediately

ventilate the room where the

appliance is situated.

 We suggest you contact your

local authority for disposal

information and facilities

available.

 See Installation Instructions

on page 11 for information on

suitable location.

 To obtain the best possible

performance and trouble free

operation from your appliance

it is very important to carefully

read these instructions.

 On delivery, check to make

sure that the product is not

damaged and that all the parts

and accessories are in perfect

condition.

 Ensure that the plug remains

readily accessible. Do not use

multiple adapter or extension

cable.

 Failure to observe these

instructions may invalidate

your right to free service

during the guarantee period.

 Keep ventilation openings, in

the appliance enclosure or in

the built-in structure, clear of

obstruction.

 Do not damage the refrigerant

circuit.

 Do not use electrical

appliances inside the food

storage compartments of the

appliance, unless they are of

the type recommended by the

manufacturer.

 We suggest you keep these

instructions in a safe place for

easy reference.

 This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory

or mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and understand the

hazards involved. Children

shall not play with the

appliance. Cleaning and user

maintenance shall not be

made by children without

supervision.

 Children should be supervised

to ensure that they do not

play with the appliance.

Electrical requirements

Before you insert the plug into

the wall socket make sure that

the voltage and the frequency

shown on the rating plate inside

the appliance corresponds to

your electricity supply.

Rating label is on the left hand

side of freezer inner liner.

We recommend that this

appliance be connected to the

mains supply via a suitable

switched and fused socket. The

appliance must be positioned

so that the plug is accessible.

WARNING:

When positioning the

appliance ensure the supply

cord is not trapped or damaged.

Should the mains lead of the

appliance become damaged or

should it need replacing at any

time, it must be replaced by a

special purpose made mains

lead which can only be obtained

from a Beko authorised service

agent.

Warning! This appliance

must be earthed

If the fitted moulded plug is

not suitable for your socket,

then the plug should be cut

off and an appropriate plug

fitted. Destroy the old plug

which is cut off as a plug with

bared cord could cause a shock

hazard if inserted into a socket

elsewhere in the house.

The moulded plug on this

appliance incorporates a 13

A fuse. Should the fuse need

to be replaced an ASTABEAB

approved BS 1362 fuse of the

same rating must be used. Do

not forget to refit the fuse

cover. In the event of losing the

fuse cover the plug must not be

used until a replacement fuse

cover has been fitted.

Colour of the replacement

fuse cover must be the same

colour as that visible on the pin

face of the plug. Fuse covers

are available from any good

electrical store.

FITTED WITH

BS 1362 13A FUSE ALWAYS

FIT BS 1362 REPLACEMENT

CARTRIDGE FUSE

GREEN &

YELLOW

GREEN

BLUE

BLACK

BROWN

RED

22mm.

6mm.

6mm. 32mm.

12mm.

FUSE

CORD GRIP

Important! Fitting A

Different Plug

1. As the colours of the wires

in the mains lead of this

appliance may not correspond

with the coloured markings

identifying the terminals in

your plug proceed as follows:

(See diagram).

2. Connect the green-yellow

or green (Earth) wire to the

terminal in the plug marked

‘E’ or with the symbol or

coloured green and yellow or

green.

3. Connect the blue (Neutral)

wire to the terminal in the plug

marked ‘N’ or coloured black.

4.Connect the brown (Live) wire

to the terminal in the plug

marked ‘L’ or coloured red.

5. With alternative plugs a 13

A fuse must be fitted either

in the plug or adaptor or in

the main fuse box. If in doubt

contact a qualified electrician.

Energy saving tips

1. Ensure your appliance is

installed in a well ventilated

area.

2. Ensure the time between

buying chilled/frozen food

and placing them in your

appliance is kept at minimum,

particularly in summer. We

recommend you use a cool

bag or a special carrier bag to

carry perishable food.

3. Do not leave the door (s) of

your appliance open longer

than necessary and ensure

they are closed properly after

each opening.

4.Defrost frozen food in your

fridge compartment, so that

frozen food acts as an ice pack

to assist cooling in your fridge.

5. Energy consumption of this

appliance is measured while

freezer compartment is

loaded without use of top

shelf lid and the drawers

except the bottom drawer.

It is advised that freezer

compartment is loaded

without use of drawers except

the bottom drawer in order

to achieve maximum loading

capacity.

Compliance with WEEE

Directive and Disposing of

the Waste Product:

This product complies

with EU WEEE

Directive (2012/19/

EU). This product

bears a classification

symbol for waste

electrical and electronic

equipment (WEEE).This product

has been manufactured with

high quality parts and materials

which can be reused and are

suitable for recycling. Do not

dispose of the waste product

with normal domestic and other

wastes at the end of its service

life. Take it to the collection

center for the recycling of

electrical and electronic

equipment. Please consult your

local authorities to learn about

these collection centers.

Compliance with rohs

directive:

The product you have

purchased complies with EU

RoHS Directive (2011/65/EU).

It does not contain harmful and

prohibited materials specified

in the Directive.

Package information

Packaging materials of the

product are manufactured

from recyclable materials in

accordance with our National

Environment Regulations. Do

not dispose of the packaging

materials together with the

domestic or other wastes. Take

them to the packaging material

collection points designated by

the local authorities.

3Installation

BThe manufacturer will not be

liable for any event caused by

disregarding the information

supplied in this user manual.

Points to be paid attention

to when the relocation of

the freezer

1. Your freezer should be

unplugged.Before transportation of

your freezer, it should be emptied

and cleaned.

2. Before it is re-packaged,

shelves, accessories, crisper, etc.

inside your freezer should be fixed

with adhesive tape and secured

against impacts. Packaging should

be adequate and the transportation

rules on the package should be

strictly observed.

3. Original packaging and foam

materials should be kept for future

transportations or moving.

Before you start the freezer,

Check the following before you

start to use your freezer:

1. Attach 2 plastic wedges as

illustrated below. Plastic wedges

are intended to keep the distance

which will ensure the air circulation

between your freezer and the

wall. (The picture is drawn up as

a representation and may not be

identical with your product.)

2. Clean the interior of the freezer

as recommended in the “Maintenance

and cleaning” section.

3. Connect the plug of the freezer

to the wall socket. When the freezer

door is opened,freezer internal lamp

will turn on.

The condenser of your appliance is located on the back as shown below. In order

to achieve better energy efficiency with lower energy consumption, please pull

the condenser towards yourself as illustrated in picture below.

*may not be available in all models

better energy

efﬁciency

2-b

initial position

PULL

4. When the compressor starts to

operate, a sound will be heard. The

liquid and gases sealed within the

refrigeration system may also give

rise to noise, even if the compressor

is not running and this is quite normal.

5. Front edges of the freezer may

feel warm. This is normal. These areas

are designed to be warm to avoid

condensation.

Electrical connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

The connection must be in

compliance with national regulations.

 The power plug must be easily

accessible after installation.

 Electrical safety of your freezer

shall be guaranteed only if the earth

system in your house complies with

standards.

 The voltage stated on the label

located at left inner side of your

product should be equal to your

network voltage.

 Extension cables and multi plugs

must not be used for connection.

BA damaged power cable must be

replaced by a qualified electrician.

BFaulty product must not be operated

before it is repaired! There is the risk

of electric shock!

Disposing of the packaging

The packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose of them by

classifying them in accordance with

the waste instructions stated by your

local authorities. Do not throw away

with regular house waste, throw away

on packaging pick up spots designated

by the local authorities.

The packing of your freezer is

produced from recyclable materials.

Disposing of your old

freezer

Dispose of your old freezer without

giving any harm to the environment.

 You may consult your authorized

dealer or waste collection center of

your municipality about the disposal

of your freezer.

Before disposing of your freezer,

cut off the electric plug and, if there

are any locks on the door, make them

inoperable in order to protect children

against any danger.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Beko Gefrierschrank Handbücher

Beko

Beko RFNE 270 L23 W Bedienungsanleitung

Beko

Beko COOL74FDS Betriebsanleitung

Beko

Beko RFSA240M31WN Bedienungsanleitung

Beko

Beko HSA 29530 Bedienungsanleitung

Beko

Beko BC73FC Bedienungsanleitung

Beko

Beko CDA 538 Bedienungsanleitung

Beko

Beko HSA37520 Bedienungsanleitung

Beko

Beko RFNE312I31XBN Bedienungsanleitung

Beko

Beko RFNES312T35X Bedienungsanleitung

Beko

Beko GF390T35XPCH Bedienungsanleitung

Beko

Beko HSA47500 Bedienungsanleitung

Beko

Beko GT29540CHN Bedienungsanleitung

Beko

Beko RFNE10COT23X Bedienungsanleitung

Beko

Beko RFSE200T40WN Bedienungsanleitung

Beko

Beko BUFR2715PSIM Bedienungsanleitung

Beko

Beko RFSA160S Bedienungsanleitung

Beko

Beko RFNE320L24W Bedienungsanleitung

Beko

Beko CDA 653 F Montageanleitung

Beko

Beko FSA21000 Bedienungsanleitung

Beko

Beko TZA6016FF Bedienungsanleitung

Beko

Beko GT24540CHN Bedienungsanleitung

Beko

Beko ICQFDB155 Bedienungsanleitung

Beko

Beko HSA47530 Bedienungsanleitung

Beko

Beko FFP 1671 S Bedienungsanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung

Electrolux

Electrolux SG235NFCN Bedienungsanleitung
