Beko HSM23049 Bedienungsanleitung

HSM23049

Chest Freezer

Instruction of use

Horizontale Gefrieranlage

Gebrauchsanweisung

Congélateur Horizontal

Notice d’utilisation

Diepvrieskist

Gebruiksaanwijzing

EN-D-FR-NL

WARNING!

In order to ensure a normal operation of your refrigerating appliance, which uses a completely environmentally

friendly refrigerant the R600a (flammable only under certain conditions) you must observe the following rules:

Do not hinder the free circulation of the air around the appliance.

Do not use mechanical devices in order to accelerate the defrosting, others than the ones recommended by

the manufacturer.

Do not destroy the refrigerating circuit.

Do not use electric appliances inside the food keeping compartment, other than those that might have been

recommended by the manufacturer.

WARNUNG!

Ihr Gerät verwendet ein umweltverträgliches Kältemittel, R600a (nur unter bestimmten Umständen brennbar).

Um einen einwandfreien Betrieb Ihres Gerätes sicherzustellen, beachten Sie bitte folgende Vorschriften:

Die Luftzirkulation um das Gerät darf nicht behindert sein.

Verwenden Sie außer der vom Hersteller empfohlenen, keine mechanischen Hilfsmittel, um den Abtauprozess

zu beschleunigen.

Der Kältemittelkreislauf darf nicht beschädigt werden.

Verwenden Sie im Lebensmittelaufbewahrungsbereich Ihres Gerätes keine elektrischen Geräte, es sei denn,

sie sind vom Hersteller empfohlen.

ATTENTION!

Pour assûrer un fonctionnement normal de votre appareil qui utilise un agent frigorifique complètement

écologique, R600a (infammable seulement dans certaines conditions) vous devez respecter les règles

suivantes:

N’empêchez pas la libre circulation de l’air autour de l’appareil.

N’ utilisez pas des dispositifs mécaniques pour accélérer le dégivrage, autres que ceux récommendés par le

fabriquant.

Ne détruissez pas le circuit frigorifique.

N’utilisez pas des appareils électiques à l’intérieur du compartiment pourconserver les denrées, apart celles

qui sont éventuellement récommendés par le fabriquant.

WAARSCHUWING!

U moet de volgende regels in acht nemen om de normale werking van uw koelkast, die het volledig

milieuvriendelijke koelmiddel R600a gebruikt, te verzekeren:

Hinder de vrije luchtcirculatie rond het toestel niet.

Gebruik geen andere mechanische toestellen om het ontdooien te versnellen dan de toestellen die door de

fabrikant worden aangeraden.

Vernietig het koelcircuit niet.

Gebruik geen andere elektrische toestellen in de bewaarlade voor etenswaren dan de toestellen die eventueel

door de fabrikant worden aangeraden.

EN Content

Advice for recycling of the old appliance /1

Packing Recycling /2

Transport instructions /2

Warnings and special advice /2

Setting up /3

Electric connection /3

Switching off /4

Appliance description /4

Freezer operation /4

Advice for food conservation /5

Defrosting of the appliance /5

Cleaning of the appliance /6

Replacing the interior light bulb /6

Defects finding guide /6

Empfehlungen zum Recycling

Ihres alten Gerätes /8

Recycling der Verpackung /9

Transportvorschriften /9

Allgemeine Vorsichtsmaßnahmen

und Empfehlungen /9

Die Umgebungstemperatur /10

Anschließen an das Spannungsnetz /10

Inbetriebnahme /11

Beschreibung des Gerätes /11

Einstellen der Temperatur /11

Tiefgefrieren von Lebensmitteln /12

Empfehlungen für das Enteisen des

Gerätes /12

Innere Reinigung /13

Äußere Reinigung /13

Erneuern der inneren Glübirne /13

Fehlersuchplan /14

Recyclage de votre ancien appareil /15

Recyclage de l'emballage /16

Instructions de transport /16

Avertissements et conseils /16

Installation /17

Raccordement au réseau électrique /17

Mise en fonctionnement /18

Description de l'appareil /18

Fonctionnement du congélateur /18

Conseils pour conserver les denrées /18

Dégivrage de l'appareil /19

Nettoyage de l'appareil /20

Remplacement de la lampe /20

Dysfonctionnements /20

Caractéristiques techniques /21

DInhalt

FR Table de matieres

Advies voor het recycleren van het

oude toestel /22

Recycleren van de verpakking /23

Transportinstructies /23

Waarschuwingen en speciaal advies /23

Installatie /24

Elektrische aansluiting /24

Uitschakelen /24

Beschrijving van toepassing /25

Invriezen /25

Advies voor voedselbewaring /25

Ontdooien van het apparaat /26

Reinigen van het apparaat /27

Het binnenlichtje vervangen /27

Probleemoplossing /27

NL Inhoud

This product is equipped with a lighting

source of the "G" energy class. The

lighting source in this product shall only

be replaced by professional repairers.

Cet appareil est doté d'une source

d'éclairage de classe énergétique

"G".Seuls des réparateurs qualifiés sont

autorisés à procéder au remplacement

de la source d'éclairage de cet appareil.

Dieses Produkt ist mit einer Lichtquelle

der Energieklasse „G“ ausgestattet.Die

Lichtquelle in diesem Produkt darf nur

von professionellen Reparaturtechnikern

ersetzt werden.

Dit product is uitgerust met een lichtbron

van de "G"-energieklasse.De lichtbron in

dit product mag enkel worden vervangen

door professionele reparateurs.

Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If

the subject parts are not included in the product you have purchased, then it is valid for other models.

Les illustrations présentées dans cette notice d’utilisation sont schématiques et peuvent ne pas correspondre

exactement à votre produit. Si des pièces présentées ne sont pas comprises dans le produit que vous avez acheté,

elles sont valables pour d’autres modèles.

Abbildungen und Angaben in dieser Anleitung sind schematisch und können etwas von Ihrem Produkt abweichen.

Falls Teile nicht zum Lieferumfang des erworbenen Gerätes zählen, gelten sie für andere Modelle.

De afbeeldingen in deze gebruiksaanwijzing zijn schematisch en hoeven niet exact met uw product overeen te

komen. Wanneer onderdelen niet tot het product behoren dat u hebt gekocht, gelden deze voor andere modellen.

Congratulations for your choice!

The chest freezer you have purchased is one in the BEKO

products range and represents a harmonious joinng between

the refrigeration technique with the aestetical outlook. It has a

new and attractive design and is built according to the

European and national standards which guarantee its operation

and safety features. At the same time, the used refrigerant,

R600a, is environment-friendly and it does not affect the ozone

layer.

In order to use the best your freezer, we advise you to read

carefully the information in these user instructions.

Advice for recycling your old appliance

If your newly purchased appliance replaces an older appliance,

you must consider a few aspects.

The old appliances are not valueless scrap. Their disposal,

while preserving the environment, allows the recovery of

important raw materials.

Make your old appliance useless :

- disconnect the appliance from the supply;

- remove the supply cord (cut it);

- remove the eventual locks on the door to avoid the blocking of

children inside, while playing, and the endangering of their lives.

The refrigerating apliances contain insulating materials and

refrigerants which require a proper recycling.

Original Spare parts will be provided for 10 years, following the

product purchasing date.

EN Instruction for use

This appliance is not intended for use by person with reduced physical, sensory or mental

capabilities or lack of experience and knowledge unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Packing Recycling

WARNING!

Do not allow children to play with the

packing or with parts of it. There is the risk

of suffocation with parts of corrugated

cardboard and with plastic film.

In order to get to you in good condition, the

appliance was protected with a suitable

packing. All the materials of the packing are

compatible with the environment and

recyclable. Please help us recycle the packing

while protecting the environment !

IMPORTANT!

Before putting the appliance in operation, read

carefully and entirely these instructions. They

contain important information concerning the

setting up, use and maintenance of the

apliance.

The manufacturer is free of any responsibility if

the information in this document are not

observed. Keep the instructions in a safe place

in order to reach them easily in case of need.

They can also be useful subsequently by

another user.

ATTENTION!

This appliance must be used only for its

intended purpose, (household use), in

suitable areas, far from rain, moisture or

other weather conditions.

Transport instructions

The appliance must be transported, as much

as possible, only in vertical position. The

packing must be in perfect condition during

transport.

If during transport the appliance was put in

horisontal position (only according to the

markings on the packing), it is advised that,

before putting it into operation, the appliance

is left to rest for 4 hours in order to allow the

settling of the refrigerating circuit.

The failure to to observe these instructions

can cause the breakdown of the

motorcompressor and the cancellation of its

warranty.

Warnings and general advice

Do not plug in the appliance if you noticed a

failure.

The repairs must be done only by qualified

personel.

In the following situations please unplug the

appliance from the mains:

- when you defrost completely the appliance;

- when you clean the appliance.

To unplug the appliance, pull by the plug,

not by the cable!

Ensure the minimum space between the

appliance and the wall against which it is

placed.

Do not climb on the appliance.

Do not allow the children to play or hide

inside the appliance.

Never use electric appliances inside the

freezer, for defrosting.

Do not use the appliance near heating

appliances, cookers or other sources of heat

and fire.

Do not leave the freezer door open more

than it is necessary to put in or take out the

food.

Do not leave the food in the appliance if it is

not working.

Do not keep inside products containing

flammable or explosive gases.

Do not keep inside fizzy drinks (juice,

mineral water, champagne, etc.) in the

freezer: the bottle can explode! Do not freeze

drinks in plastic bottles.

Do not eat ice cubes or icecream

immediately after having taken them out of the

freezer because they may cause „freezer

burns”.

Never touch cold metal parts or frozen food

with wet hands because your hands can

quickly freeze on the very cold surfaces.

For the protection of the appliance during

warehousing and transport, it is provided with

spacers between the door and the cabinet (in

the front and rear side). These spacers will be

removed before putting the appliance into

operation.

EN Instruction for use

Excess deposit of ice on the frame and the

baskets should be removed regularly with the

plastic scraper provided. Do not use any

metal parts to remove the ice.

The presence of this ice build-up makes

impossible to close the door correctly.

If you do not use your appliance for a few

days, it is not advisable to switch it off. If you

do not use it for a longer period, please

proceed as follows :

- unplug the appliance;

- empty the freezer;

- defrost it and clean it;

- leave the door open to avoid the formation of

unpleasant smells.

If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualified persons in order to

avoid a hazard.

If your appliance has a lock, keep it locked

and store the key in a safe place, out of the

reach of children. If you are discarding an

appliance with lock, make sure that, is made

ineffective. This is very important so as to

avoid children being trapped inside, which

may cause their loss of life.

Setting up

Your product was designed to operate at an

ambient temperature between -15°C and

+43°C.

If the ambient temperature is above +430C,

inside the appliance the temperature can

increase.

Set up the appliance far from any source of

heat and fire. Placing it in a warm room, the

direct exposure to sunbeams or near a heat

source (heaters, cookers, ovens), will

increase the energy consumption and shorten

the product life.

Please observe the following minimun

distances:

100 cm from the cookers working with

coal or oil;

150 cm from the electric and gas

cookers.

Ensure the free circulation of the air around

the appliance, by observing the distances

shown in Item 2.

Assemble on the condenser (in the rear side)

the supplied spacers. (Item 3).

Place the appliance in a perfectly even, dry

and well ventilated place.

Assemble the supplied accessories.

Electric connection

Your appliance is intended to operate at a

single-phase voltage of 220-240V/50 Hz. Before

plugging in the appliance, please make sure

that the parameters of the mains in your house

(voltage, currect type, frequency) comply to the

operation parameters of the appliance.

The information concerning the supply voltage

and the absorbed power isgiven on the marking

label placed in the back side of the freezer.

The electric installation must comply with

the law requirements.

The earthing of the appliance is

compulsory. The manufacturer has no

responsibility for any damage to persons,

animals or goods which may arise from

the failure to observe the specified

conditions.

The appliance is endowed with a supply

cord and a plug (European type, marked

10/16A) with double earthing contact for

safety. If the socket is not the same type with

the plug, please ask a specialised electrician

to change it.

Do not use extension pieces or multiple

adapters.

EN Instruction for use

Switching off

The switching off must be possible by taking

the plug out of the socket or by means of a

mains two-poles switch placed before the

socket.

Operation

Before putting into operation, clean the inside

of the appliance (see chapter „Cleaning").

After finishing this operation please plug

in the appliance, adjust the thermostat

knob to an average position. The green and

red LEDs in the signalling block must light.

Leave the appliance work for about 2

hours without putting food inside it.

The freezing of the fresh food is possible

after min. 20 hours of operation.

Appliance description

(Item. 1)

1. Door handle

2. Door

3. Lamp housing

4. Baskets

5. Tray

6. Lock housing

7. Thermostat box

8. Spacer for transport

Freezer operation

Temperature adjustment

The temperature of the freezer is adjusted by

means of the knob assembled on the

thermostat (item. 4), position „MAX” being the

lowest temperature.

The achieved temperatures can vary

according to the conditions of use of the

appliance, such as: place of the appliance,

ambient temperature, frequency of door

opening, extent of filling with food of the

freezer. The position of the thermostat knob

will change according to these factors.

Normally, for an ambient temperature of

approx. 430C, the thermostat will be adjusted

on an average position.

The signalling system is placed on the front

side of the freezer (Item 5).

It includes:

1. Thermostat adjustment knob –the inside

temperature is adjusted.

2. green LED –shows that the appliance is

supplied with electric energy.

3. red LED –damage –lights if the

temperature in the freezer is too high. The

LED will operate 15-45 minutes after the

putting into operation of the freezer, then it

must go off. If the LED goes on during the

operation, this means that defects have

occurred.

4. LED Orange –fast freeze function

activated –by setting the knob to

Superfreeze position the orange led goes

on, showing that the appliance entered

into the "fast freeze" mode. The exit of this

mode is done automatically after 50 hours

then the appliance runs in economic

mode, and the orange led goes off.

The three LEDs give information about the

mode of operation of the freezer.

EN Instruction for use

Inhaltsverzeichnis

Sprachen:

Andere Beko Gefrierschrank Handbücher

Beko

Beko RFNE270K31WN Bedienungsanleitung

Beko

Beko FNE312E41WN Bedienungsanleitung

Beko

Beko RFSM200T40WN Bedienungsanleitung

Beko

Beko FROST FREE COMBI CDA 563 F Montageanleitung

Beko

Beko CF41186W Bedienungsanleitung

Beko

Beko FSA13020 Bedienungsanleitung

Beko

Beko HSA47520F Bedienungsanleitung

Beko

Beko BC50F Bedienungsanleitung

Beko

Beko BFNA247E20F Bedienungsanleitung

Beko

Beko HSS225523S Bedienungsanleitung

Beko

Beko RFSA240M33X Bedienungsanleitung

Beko

Beko FSA21000 Bedienungsanleitung

Beko

Beko HSA32540 Bedienungsanleitung

Beko

Beko HSA32521 Bedienungsanleitung

Beko

Beko HSA20542 Bedienungsanleitung

Beko

Beko RFNA450XP Bedienungsanleitung

Beko

Beko HSA46330 Bedienungsanleitung

Beko

Beko HSA 24531 Bedienungsanleitung

Beko

Beko TZDA629F Bedienungsanleitung

Beko

Beko RFSA240M30WN Bedienungsanleitung

Beko

Beko RFNE270K32W Bedienungsanleitung

Beko

Beko RFNE448E45W Bedienungsanleitung

Beko

Beko TZS 492 Bedienungsanleitung

Beko

Beko BFNA247E30SN Bedienungsanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung

Electrolux

Electrolux SG235NFCN Bedienungsanleitung
