Beko UFC524W Bedienungsanleitung

Instructions for Use 51

Instructions for Use

Upright Freezer

Thank you for your trust and for buying this appliance. We hope it will

successfully serve the purpose for many years.

The upright freezer for domestic use is intended for freezing fresh

food and for long-term storing of frozen food (up to one year,

depending on the kind of food).

Before Putting Into Use 52-53

Important 54-55

Placing and Installation 56

Description of the appliance 57

Operation Control 58-59

Use 60-61

Maintenance And Cleaning 62-63

Trouble Shooting Guide 64-65

Instructions for Use52

Before Putting Into Use

• Before connecting the appliance to the mains supply, leave it stand

for about 2 hours which will reduce the possibility of malfunctions in

the cooling system that might have occurred due to transport

handling.

• Clean the appliance thoroughly, especially the interior (see Cleaning

and Maintenance).

Instructions for Use

These instructions for use were prepared for the user. They describe

the appliance and its correct and safe use. They were prepared for

various types/models of appliances therefore you might find in it

description of some functions and accesories that do not apply to your

appliance.

Mounting Instructions

Integrated appliances are equipped with instructions for mounting the

appliance into the kitchen unit.

The appliance should be professionally mounted by qualified technician

and instructions are for his use only.

We Care for the Environment

• Our products use environmentally friendly packaging, which can be

either recycled or disposed of in an environmentally friendly manner.

To this end, individual packaging materials are clearly marked.

• These instructions are printed either on recycled paper or chlorine

free bleached paper.

• When your appliance finally wears out, please try not to burden the

environment with it; call your nearest authorised service agent. (See

Disposing of the Worn Out Appliance)

Tips for Energy Saving

• This is especially important if you have an upright model.

• Check periodically if the appliance is provided with sufficient cooling

(undisturbed circulation of air through the bottom rail openings).

• Turn the thermostat knob from higher to lower setting as soon as

possible (depends on how loaded the appliance is, ambient

temperature...)

Instructions for Use 53

• Never use continuous operation unless

unnecessarily required; switch the

operation mode selection switch to the

setting for automatic operation as soon as

possible.

• Before freezing packages of fresh foods,

make sure they are cooled to ambient

temperature. (except for the soup)

• Ice and frost layer increase energy

consumption, so do clean the appliance

as soon as the layer is 3-5 mm thick.

• If the gasket is damaged or if it turns out that the sealing is poor, the

energy consumption is substantially higher. To restore efficiency,

replace the gasket.

• Condenser at the bottom of the appliance must always be clean and

dust free (see Section Cleaning of the Appliance).

• Always consider instructions stated in sections Positioning and

Energy Saving Tips, otherwise the energy consumption is

substantially higher.

Instructions for Use54

Important

• If you've bought this appliance to replace an old one equipped with a

lock that cannot be opened from inside (lock, bolt), make sure that

the lock is broken. This will make it impossible for the children to lock

themselves in

• the appliance and suffocate.

• Mind to connect the appliance correctly to the mains supply (see

Connection to the Mains Supply).

• Do not touch the cooled surfaces while the appliance operates,

especially not with wet hands, because the skin might stick to the

cold surfaces.

• Do not freeze bottled drinks, especially not fizzy ones such as mineral

water, sparkling wine, beer, cola etc., because liquid expands during

freezing and the glass bottle is very likely to blow up.

• Never try to eat frozen food (bread, fruit, vegetables), because you

may get frostbites.

• Carefully check the foods for color and smell and if you are in doubt

about their quality, throw them away because they may be spoiled

and therefore dangerous to eat.

• Disconnect the appliance from the mains before repairing (only a

qualified technician should repair it) and before cleaning.

• Use only enclosed tools or tools recommended by the manufacturer.

• For the sake of environment protection - be careful not to damage

the rear wall of the appliance (the condenser unit or the tubes - for

example when moving the appliance) or any part of the refrigerating

system inside the appliance. Do not use sharp object for defrosting

the appliance. Use only enclosed tools or tools recommended by the

manufacturer.

• The refrigerating system of the appliance is filled with refrigerant and

oil, so when the appliance is damaged, handle it with care and

dispose it of in compliance with environmental protecting

precautions. (See We Care for the Environment).

• Heating element incorporated in the appliance, all around the rim, is

controlled by the operation of the compressor and it prevents the

door gasket to freeze on to the freezer housing.

• In the supply cord is damaged, it must be replaced by the

manufacturer or his service agent or a qualified person in order to

avoid hazard.

• The rating plate is in the interior or on the rear wall of the appliance.

Instructions for Use 55

Storing Time During Power Supply Interruption

Avoid opening the freezer in case of failure or power supply

interruption! In case the interruption is extended over longer period of

time (15 hours).

Disposing of the Worn Out Appliance

• When your appliance finally wears out, dispose it of. If the appliance

has a lock, break it, in order to prevent eventual accidents (danger of

children get locked inside the appliance).

• The refrigerating system of the appliance is filled with refrigerant and

insulating substances which should be separately treated and

processed. Call your nearest authorised service agent or specialised

servicing centre. If you don't find one, contact your local authorities or

your distributor. Be careful not to damage the tubes on the rear wall

of the appliance (danger of pollution).

• To avoid pollution of the environment make sure not to damage the

hose at the bottom of the appliance.

Instructions for Use56

Placing and Installation

Choosing the Right Place

Place the appliance in dry and well ventilated room. Allowed ambient

temperature depends on the model (class) of the appliance and is

stated on the rating plate of the appliance. Never place the appliance

near heat emitting devices (e.g. cooker, radiator, water heater and

similar devices) and do not expose it to direct sunlight.

The appliance should be positioned at least 3 cm away from the

electric or gas cooker and at least 30 cm away from the oil or coal

stove. If this is not possible, use an appropriate insulation.

Class Ambient temperature

SN (sub-normal) from + 10°C to + 32°C

N (normal) from + 16°C to + 32°C

Connection to Power Supply

Connect the appliance with the cable and plug to the power supply

socket outlet with a ground terminal (safety socket).

Required nominal voltage and frequency are indicated on the rating

plate.

The connection to the mains supply and earthing have to be made

according to current standards and regulations. The appliance resists

temporary voltage tolerance up to -15 to +10 %.

Adjusting the height of the appliance

The appliance is equipped with four adjustable legs, so that the height

may be adjusted from 82 to 90 cm. The height must be adjusted prior

building the appliance into the opening slot, and it should be set at such

height that the top panel of the appliance fits exactly below the kitchen

worktop (see Mounting Instructions).

Instructions for Use 57

Description of the Appliance

Freezing Compartment (1)

is used for freezing fresh foods.

Storing Basket (2)

is used for storing packages of frozen foods.

Control Panel (3)

See Operation Controls

Instructions for Use58

Operation Control

The freezer is controlled with switches and thermostat button,

incorporated in the bottom section of the appliance.

Control panel

1ON/OFF switch (green signal lamp)

2Continued operation button (yellow signal lamp)

3 Alarm off button (red signal lamp)

ON/OFF Switch (1)

The appliance is switched on - the green light is on.

The appliance is switched off - the green light is off.

Continued operation button (2)

This switch is used to select one of the two operation modes:

continuous and automatic.

Continuous operation - the yellow light is on.

The cooling system operates continuously. This mode is selected when

you want to freeze large amounts of fresh foods and in case you want

to deep freeze already frozen foods.

Automatic operation - the yellow light is off.

The interior temperature is controlled by the thermostat which turns the

cooling system on and off.

The frequency of switching the cooling system on and off depends on:

− the thermostat knob position (thermostat setting),

− how often you open the door; and

− ambient temperature.

Instructions for Use 59

Alarm off button and the red signal lamp (3)

The sound of the alarm is switched off by pressing the Alarm Off

button. The alarm goes off because of high temperature inside the

freezer (red signal lamp is on), or because of the excessive dust

collected at the condenser (red signal lamp is off).

Consult the Section Troubleshooting Guide

Temperature Selection

When the freezer operates automatically, the

interior temperature is controlled by the

thermostat.

The most suitable thermostat position is in the

middle between max (7) and min (1).

We recommend setting the thermostat on

positions towards max (7) only in case you want

to accelerate cooling, as for example before

loading smaller amounts of fresh foods or when

the operation mode shall correspond to the ambient temperature.

Thermostat settings towards min (1) help you save energy provided

that the freezer is loaded with smaller amount of frozen foods.

Changes of the ambient temperature affects temperature in the interior

of the appliance. Choose correct setting of the thermostat knob.

Instructions for Use60

Use

Starting the empty freezer

Switch the freezer on. Sound alarm is on because of inappropriate

temperature. It may be switched off by pressing the alarm button .

Put the mode selection switch to the continuous operation position. All

three signal lamps are on. Place fresh food into the freezer several

hours after the red signal lamp goes off.

Freezing Fresh Foods

Proper use of the appliance, adequately packed food, correct

temperature and taking into account hygienic precautions will

substantially influence the quality of freezing the food or storing of the

frozen foodstuffs.

• Carefully select food to be frozen: it should be of adequate quality and

suitable for freezing.

• Choose correct packaging for each kind of food and pack it correctly.

− The packaging should be air tight and well sealed without leaking

since this could cause substantial vitamin loss and dehydration.

− Foils and bags should be soft enough to tightly wrap around the food.

• Mark packages with following data: kind and amount of foods and the

date of loading.

• It is most important that the food is frozen as quickly as possible. We

therefore recommend the size of the package not to be too large and to

be cooled before loading into the freezer.

• The amount of the fresh foods that can be loaded in the freezer within

24 hours is stated on the rating plate. If the loaded amount is too large,

the quality of freezing is reduced which affects the quality of frozen

foods.

Proper freezing procedure

Freeze the food in the freezing compartment (see Section Description

of the Appliance)

− 24 hours prior freezing of fresh food switch the continued operation

button (2) to the uninterrupted operation (yellow lamp is on). At the

end of this period load fresh food into the freezing compartment.

− After 24 hours move the frozen food to the storage compartment of

the freezer and repeat the freezing procedure with new load if

required. Fresh food should not touch the already frozen packages.

− Approximately 24 hours after the last loading of fresh food press the

continued operation button again (2) and switch to the automatic

operation (yellow signal lamp is off).

Andere Handbücher für UFC524W

Inhaltsverzeichnis

Andere Beko Gefrierschrank Handbücher

Beko

Beko HS14530 Bedienungsanleitung

Beko

Beko HSA 29530 Bedienungsanleitung

Beko

Beko FNE290E24W Bedienungsanleitung

Beko

Beko RFSM200T40WN Bedienungsanleitung

Beko

Beko B3RMFNE314XB Bedienungsanleitung

Beko

Beko GF200E40WCHN Bedienungsanleitung

Beko

Beko HS210520S Bedienungsanleitung

Beko

Beko HSA40540 Bedienungsanleitung

Beko

Beko RCSA400K31W Bedienungsanleitung

Beko

Beko CDA 659 F Montageanleitung

Beko

Beko RFNE290L25W Bedienungsanleitung

Beko

Beko FSA 21320 X Bedienungsanleitung

Beko

Beko UF584APS Bedienungsanleitung

Beko

Beko FS 127320 Bedienungsanleitung

Beko

Beko FG941 Bedienungsanleitung

Beko

Beko RDSA240K20XB Bedienungsanleitung

Beko

Beko FC 175F Betriebsanleitung

Beko

Beko HSA 32502 S Bedienungsanleitung

Beko

Beko HSM30031 Bedienungsanleitung

Beko

Beko RFNE312E22W Bedienungsanleitung

Beko

Beko CF1300APW Bedienungsanleitung

Beko

Beko HSA 32520 Bedienungsanleitung

Beko

Beko FFG3545 Bedienungsanleitung

Beko

Beko FSA14921 Bedienungsanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung

Electrolux

Electrolux SG235NFCN Bedienungsanleitung
