Beko CN240220 Bedienungsanleitung

CN240220

CN240220X

CN240221T

Refrigerator

Chłodziarko

Chladnička

Please read this user manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and checked

under the most meticulous quality control procedures, will provide you an effective

service.

Therefore, read this entire user manual carefully before using the product and keep it as

a reference. If you handover the product to someone else, give the user manual as well.

The user manual will help you use the product in a fast and safe way.

Read the manual before installing and operating the product.

Make sure you read the safety instructions.

Keep the manual in an easily accessible place as you may need it later.

Read the other documents given with the product.

Remember that this user manual is also applicable for several other models. Differences

between models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

Important information or useful tips.

Warning against dangerous conditions for life and property.

Warning against electric voltage.

1 Your refrigerator 4

2 Important Safety Warnings 5

Intended use.........................................

General safety.......................................

For products with a water dispenser......

Child safety............................................

Compliance with the AEEE Regulation

and Disposing of the Waste Product…..

Package information..............................

HCA warning..........................................

Things to be done for energy saving…..

3 Installation 9

Points to be paid attention to when the

relocation of the refrigerator....................

Before you start the refrigerator,............

Electrical connection............................

Disposing of the packaging..................

Disposing of your old refrigerator.........

Placing and Installation........................

Changing the illumination lamp ...........

Changing the door opening direction…

Adjusting the legs................................

CONTENTS

4 Preparation 12

5 Using your refrigerator 13

Indicator Panel.....................................

Dual cooling system:............................

Freezing fresh food..............................

Recommendations for preservation of

frozen food...........................................

Defrosting............................................

Placing the food...................................

Deep-freeze information.......................

Recommendations for the fresh food

compartment........................................

6 Maintenance and cleaning 19

Protection of plastic surfaces ..............

7 Troubleshooting 20

Your refrigerator

1. Control panel

2. Interior light

3. Fresh Food fan

4. Wine bottles support

5. Adjustable Cabinet shelves

6. Chiller cover and glass

7. Chiller

8. Salad crispers

9. Ice tray support & ice tray

10.Compartment for quickly freezing

11. Compartments for frozen froods keeping

12. Adjustable front feet

13. Dairy Compartment

14. Shelf for jars

15. Shelf for bottles

16. Freezer fan

Optional

Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in

the product you have purchased, then it is valid for other models.

Important Safety Warnings

Please review the following information.

Failure to observe this information may

cause injuries or material damage.

Otherwise, all warranty and reliability

commitments will become invalid.

The service life of your product is 10

years. During this period, original spare

parts will be available to operate the

product properly.

Intended use

This product is intended to be used

indoors and in closed areas such as

homes;

in closed working environments such

as stores and offices;

in closed accommodation areas such

as farm houses, hotels, pensions.

It should not be used outdoors.

General safety

When you want to dispose/scrap

the product, we recommend you

to consult the authorized service in

order to learn the required information

and authorized bodies.

Consult your authorized service for

all your questions and problems

related to the refrigerator. Do not

intervene or let someone intervene to

the refrigerator without notifying the

authorised services.

For products with a freezer

compartment; Do not eat cone ice

cream and ice cubes immediately

after you take them out of the freezer

compartment! (This may cause

frostbite in your mouth.)

For products with a freezer

compartment; Do not put bottled and

canned liquid beverages in the freezer

compartment. Otherwise, these may

burst.

Do not touch frozen food by hand;

they may stick to your hand.

Unplug your refrigerator before

cleaning or defrosting.

Vapor and vaporized cleaning

materials should never be used in

cleaning and defrosting processes of

your refrigerator. In such cases, the

vapor may get in contact with the

electrical parts and cause short circuit

or electric shock.

Never use the parts on your

refrigerator such as the door as a

means of support or step.

Do not use electrical devices inside

the refrigerator.

Do not damage the parts, where

the refrigerant is circulating, with

drilling or cutting tools. The refrigerant

that might blow out when the gas

channels of the evaporator, pipe

extensions or surface coatings are

punctured causes skin irritations and

eye injuries.

Do not cover or block the ventilation

holes on your refrigerator with any

material.

Electrical devices must be repaired

by only authorised persons. Repairs

performed by incompetent persons

create a risk for the user.

In case of any failure or during

a maintenance or repair work,

disconnect your refrigerator’s mains

supply by either turning off the

relevant fuse or unplugging your

appliance.

Do not pull by the cable when pulling

off the plug.

Place the beverage with higher proofs

tightly closed and vertically.

Never store spray cans containing

flammable and explosive substances

in the refrigerator.

Do not use mechanical devices

or other means to accelerate the

defrosting process, other than those

recommended by the manufacturer.

This product is not intended to be

used by persons with physical,

sensory or mental disorders or

unlearned or inexperienced people

(including children) unless they are

attended by a person who will be

responsible for their safety or who will

instruct them accordingly for use of the

product.

Do not operate a damaged

refrigerator. Consult with the service

agent if you have any concerns.

Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

Exposing the product to rain, snow,

sun and wind is dangerous with

respect to electrical safety.

Contact authorized service when

there is a power cable damage to

avoid danger.

Never plug the refrigerator into

the wall outlet during installation.

Otherwise, risk of death or serious

injury may arise.

This refrigerator is intended for only

storing food items. It must not be

used for any other purpose.

Label of technical specifications is

located on the left wall inside the

refrigerator.

Never connect your refrigerator to

electricity-saving systems; they may

damage the refrigerator.

If there is a blue light on the

refrigerator, do not look at the blue

light with optical tools.

For manually controlled refrigerators,

wait for at least 5 minutes to start the

refrigerator after power failure.

This operation manual should be

handed in to the new owner of the

product when it is given to others.

Avoid causing damage on power

cable when transporting the

refrigerator. Bending cable may cause

fire. Never place heavy objects on

power cable.

Do not touch the plug with wet hands

when plugging the product.

Do not plug the refrigerator if the wall

outlet is loose.

Water should not be sprayed on

inner or outer parts of the product for

safety purposes.

Do not spray substances containing

inflammable gases such as propane

gas near the refrigerator to avoid fire

and explosion risk.

Never place containers filled with

water on top of the refrigerator; in the

event of spillages, this may cause

electric shock or fire.

Do not overload the refrigerator with

food. If overloaded, the food items

may fall down and hurt you and

damage refrigerator when you open

the door.

Never place objects on top of the

refrigerator; otherwise, these objects

may fall down when you open or

close the refrigerator's door.

As they require a precise

temperature, vaccines, heat-sensitive

medicine and scientific materials

and etc. should not be kept in the

refrigerator.

If not to be used for a long time,

refrigerator should be unplugged. A

possible problem in power cable may

cause fire.

The plug's tip should be cleaned

regularly with a dry cloth; otherwise, it

may cause fire.

Refrigerator may move if adjustable

legs are not properly secured on the

floor. Properly securing adjustable

legs on the floor can prevent the

refrigerator to move.

When carrying the refrigerator, do not

hold it from door handle. Otherwise, it

may be snapped.

When you have to place your product

next to another refrigerator or freezer,

the distance between devices should

be at least 8cm. Otherwise, adjacent

side walls may be humidified.

For products with a water

dispenser;

Pressure of water mains should be

minimum 1 bar. Pressure of water

mains should be maximum 8 bars.

Use only potable water.

Child safety

If the door has a lock, the key should

be kept away from reach of children.

Children must be supervised to

prevent them from tampering with the

product.

Compliance with the AEEE

Regulation and Disposing of the

Waste Product

The symbol on the product or on

packaging indicates that this product may

not be treated as household waste.

Instead it shall be handed over to the

applicable collection point for the

recycling of electrical and electronic

equipment. By ensuring this product is

disposed of correctly, you will help

prevent potential negative consequences

for the environment and human health,

which could otherwise be caused by

inappropriate waste handling of this

product. For more detailed information

about recycling of this product, please

contact your local city office, you

household waste disposal service or the

shop where you purchased the product.

Package information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations. Do

not dispose of the packaging materials

together with the domestic or other

wastes. Take them to the packaging

material collection points designated

by the local authorities.

Do not forget...

Any recycled substance is an

indispensable matter for nature and our

national asset wealth.

If you want to contribute to the

reevaluation of the packaging materials,

you can consult to your environmentalist

organizations or the municipalities

where you are located.

HCA warning

If your product's cooling system

contains R600a:

This gas is flammable. Therefore, pay

attention to not damaging the cooling

system and piping during usage and

transportation. In the event of damage,

keep your product away from potential

fire sources that can cause the product

catch a fire and ventilate the room in

which the unit is placed.

Type of gas used in the product is

stated in the type label which is on the

left wall inside the refrigerator.

Never throw the product in fire for

disposal.

Things to be done for energy

Saving

Do not leave the doors of your

refrigerator open for a long time.

Do not put hot food or drinks in your

refrigerator.

Do not overload your refrigerator so

that the air circulation inside of it is not

prevented.

Do not install your refrigerator

under direct sunlight or near heat

emitting appliances such as ovens,

dishwashers or radiators. Keep your

refrigerator at least 30cm away from

heat emitting sources and at least

5cm from electrical ovens.

Pay attention to keep your food in

closed containers.

For products with a freezer

compartment; You can store

maximum amount of food items in

the freezer when you remove the

shelf or drawer of the freezer. Energy

consumption value stated for your

refrigerator has been determined

by removing freezer shelf or drawer

and under maximum load. There

is no harm to use a shelf or drawer

according to the shapes and size of

food to be frozen.

Thawing frozen food in fridge

compartment will both provide energy

saving and preserve the food quality.

Installation

In case the information which are

given in the user manual are not

taken into account, manufacturer will

not assume any liability for this.

Points to be paid attention

to when the relocation of the

refrigerator

1. Your refrigerator should be

unplugged.Before transportation of

your refrigerator, it should be emptied

and cleaned.

2. Before it is re-packaged, shelves,

accessories, crisper, etc. inside your

refrigerator should be fixed with

adhesive tape and secured against

impacts. Package should be bound

with a thick tape or sound ropes

and the transportation rules on the

package should be strictly observed.

3. Original packaging and foam

materials should be kept for future

transportations or moving.

Before you start the

refrigerator,

Check the following before you start

to use your refrigerator:

1. Attach 2 plastic wedges as illustrated

below. Plastic wedges are intended

to keep the distance which will ensure

the air circulation between your

refrigerator and the wall. (The picture

is drawn up as a representation and it

is not identical with your product.)

2. Clean the interior of the refrigerator as

recommended in the “Maintenance

and cleaning” section.

3. Connect the plug of the refrigerator

to the wall socket. When the fridge

door is opened, fridge internal lamp

will turn on.

4. When the compressor starts to

operate, a sound will be heard. The

liquid and gases sealed within the

refrigeration system may also give rise

to noise, even if the compressor is

not running and this is quite normal.

5. Front edges of the refrigerator may

feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Beko Kühlschrank Handbücher

Beko

Beko B5RDNE504LXB Bedienungsanleitung

Beko

Beko B5RCNE3651HXB Bedienungsanleitung

Beko

Beko BLSA410M32SN Bedienungsanleitung

Beko

Beko GN168421X Bedienungsanleitung

Beko

Beko GNE 35715 Bedienungsanleitung

Beko

Beko RDSA240K30XPN Bedienungsanleitung

Beko

Beko WSA 14000 Bedienungsanleitung

Beko

Beko RDNE455E20ZX Bedienungsanleitung

Beko

Beko RDSA240K30XBN Bedienungsanleitung

Beko

Beko CNA29120 Bedienungsanleitung

Beko

Beko BU 1152 HCA Bedienungsanleitung

Beko

Beko 674581 EB Bedienungsanleitung

Beko

Beko RBI 6306 HCA Bedienungsanleitung

Beko

Beko BLQSDW377 Bedienungsanleitung

Beko

Beko RCNA366I40ZXB Bedienungsanleitung

Beko

Beko RDSE465K31W Bedienungsanleitung

Beko

Beko RCSA360K21W Bedienungsanleitung

Beko

Beko QFS3682 Bedienungsanleitung

Beko

Beko BCSA306K2S Bedienungsanleitung

Beko

Beko BFTF2716WH Bedienungsanleitung

Beko

Beko CNA 28421 Bedienungsanleitung

Beko

Beko UFS4584W Bedienungsanleitung

Beko

Beko CSA365K30X Bedienungsanleitung

Beko

Beko RDNE390M21W Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung

Matsui

Matsui MTT50W12E Bedienungsanleitung
