DNE 26000

DNE 26000 S

DNE 26020

DNE 26020 S

EN ES SQ SB

Please read this user manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

Therefore, read this entire user manual carefully before using the product and

keep it as a reference. If you handover the product to someone else, give the

user manual as well.

The user manual will help you use the product in a fast and safe way.

• Read the manual before installing and operating the product.

• Make sure you read the safety instructions.

• Keep the manual in an easily accessible place as you may need it later.

• Read the other documents given with the product.

Remember that this user manual is also applicable for several other models.

Differences between models will be identified in the manual.

Explanation of symbols

Throughout this user manual the following symbols are used:

CImportant information or useful tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

CONTENTS

1 Your refrigerator 3

2 Important Safety

Warnings 4

Intended use .....................................4

General safety ..................................4

For products with a ..........................7

water dispenser;................................7

Child safety........................................7

Compliance with WEEE Directive and

Disposing of the Waste Product: .......7

Package information..........................7

HC warning .......................................8

Things to be done for energy saving..8

Recommendations for the fresh food

compartment.....................................8

3 Installation 9

Points to be paid attention to when the

relocation of the refrigerator...............9

Electrical connection.......................... 9

Disposing of the packaging .............10

Disposing of your old refrigerator .....10

Placing and Installation ....................10

Adjusting the legs ............................11

Door Open Warning.........................11

Changing the illumination lamp .......11

Reversing the doors ........................12

Reversing the doors ........................13

4 Preparation 14

5 Using your refrigerator 15

Fridge compartment thermostat setting

button ............................................15

Making ice.......................................16

Dual cooling system: .......................16

Freezing fresh food..........................16

Freezer compartment thermostat

setting button .................................16

Deep-freeze information ..................17

Recommendations for preservation of

frozen food ...................................... 18

Defrosting........................................18

Placing the food ..............................18

6 Maintenance and

cleaning 19

Protection of plastic surfaces ..........19

Troubleshooting 20

1Your refrigerator

*11

*12

Freezer compartment shelf

Ice container

Fridge compartment temperature

setting button

Adjustable body shelves

Illumination lens

Crisper cover

Crisper

Adjustable legs

Freezer compartment door shelf

10.

Egg tray

11.

Fridge compartment door shelf

12.

Key

13.

Freezer compartment

14.

Fridge compartment

Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

* OPTIONAL

2Important Safety Warnings

Please review the following

information. Failure to observe

this information may cause

injuries or material damage.

Otherwise, all warranty and

reliability commitments will

become invalid.

Original spare parts will be

provided for 10 years, following

the product purchasing date.

Intended use

This product is intended to be used

• indoors and in closed areas such

as homes;

• in closed working environments

such as stores and offices;

• in closed accommodation areas

such as farm houses, hotels,

pensions.

• It should not be used outdoors.

General safety

• When you want to dispose/

scrap the product, we

recommend you to consult the

authorized service in order to

learn the required information

and authorized bodies.

• Consult your authorized

service for all your questions

and problems related to the

refrigerator. Do not intervene or

let someone intervene to the

refrigerator without notifying the

authorised services.

• For products with a freezer

compartment; Do not eat

cone ice cream and ice cubes

immediately after you take them

out of the freezer compartment!

(This may cause frostbite in your

mouth.)

• For products with a freezer

compartment; Do not put

bottled and canned liquid

beverages in the freezer

compartment. Otherwise,

these may burst.

• Do not touch frozen food by

hand; they may stick to your

hand.

• Unplug your refrigerator before

cleaning or defrosting.

• Vapor and vaporized cleaning

materials should never be

used in cleaning and defrosting

processes of your refrigerator.

In such cases, the vapor may

get in contact with the electrical

parts and cause short circuit or

electric shock.

• Never use the parts on your

refrigerator such as the door as

a means of support or step.

• Do not use electrical devices

inside the refrigerator.

• Do not damage the parts,

where the refrigerant is

circulating, with drilling or

cutting tools. The refrigerant

that might blow out when the

gas channels of the evaporator,

pipe extensions or surface

coatings are punctured causes

skin irritations and eye injuries.

• Do not cover or block the

ventilation holes on your

refrigerator with any material.

• Electrical devices must be

repaired by only authorised

persons. Repairs performed by

incompetent persons create a

risk for the user.

• In case of any failure or during

a maintenance or repair work,

disconnect your refrigerator’s

mains supply by either

turning off the relevant fuse or

unplugging your appliance.

• Do not pull by the cable when

pulling off the plug.

• Ensure highly alcoholic

beverages are stored securely

with the lid fastened and

placed upright.

• Never store spray cans

containing flammable and

explosive substances in the

refrigerator.

• Do not use mechanical devices

or other means to accelerate

the defrosting process, other

than those recommended by

the manufacturer.

• This product is not intended

to be used by persons with

physical, sensory or mental

disorders or unlearned or

inexperienced people (including

children) unless they are

attended by a person who

will be responsible for their

safety or who will instruct them

accordingly for use of the

product

• Do not operate a damaged

refrigerator. Consult with the

service agent if you have any

concerns.

• Electrical safety of your

refrigerator shall be guaranteed

only if the earth system in

your house complies with

standards.

• Exposing the product to

rain, snow, sun and wind is

dangerous with respect to

electrical safety.

• Contact authorized service

when there is a power cable

damage to avoid danger.

• Never plug the refrigerator

into the wall outlet during

installation. Otherwise, risk of

death or serious injury may

arise.

• This refrigerator is intended

for only storing food items. It

must not be used for any other

purpose.

• Label of technical specifications

is located on the left wall inside

the refrigerator.

• Never connect your refrigerator

to electricity-saving systems;

they may damage the

refrigerator.

• If there is a blue light on the

refrigerator, do not look at the

blue light with optical tools.

• For manually controlled

refrigerators, wait for at least 5

minutes to start the refrigerator

after power failure.

• This operation manual should

be handed in to the new owner

of the product when it is given

to others.

• Avoid causing damage on

power cable when transporting

the refrigerator. Bending cable

may cause fire. Never place

heavy objects on power cable.

Do not touch the plug with

wet hands when plugging the

product

• Do not plug the refrigerator if

the wall outlet is loose.

• Water should not be sprayed

on inner or outer parts of the

product for safety purposes.

• Do not spray substances

containing inflammable gases

such as propane gas near the

refrigerator to avoid fire and

explosion risk.

• Never place containers filled

with water on top of the

refrigerator; in the event of

spillages, this may cause

electric shock or fire.

• Do not overload the refrigerator

with food. If overloaded, the

food items may fall down

and hurt you and damage

refrigerator when you open the

door.

• Never place objects on top

of the refrigerator; otherwise,

these objects may fall down

when you open or close the

refrigerator’s door.

• As they require a precise

temperature, vaccines,

heat-sensitive medicine and

scientific materials and etc.

should not be kept in the

refrigerator.

• If not to be used for a long

time, refrigerator should be

unplugged. A possible problem

in power cable may cause fire.

• The plug’s tip should be

cleaned regularly with a dry

cloth; otherwise, it may cause

fire.

• Refrigerator may move if

adjustable legs are not properly

secured on the floor. Properly

securing adjustable legs on

the floor can prevent the

refrigerator to move.

• When carrying the refrigerator,

do not hold it from door

handle. Otherwise, it may be

snapped.

• When you have to place

your product next to another

refrigerator or freezer, the

distance between devices

should be at least 8cm.

Otherwise, adjacent side walls

may be humidified.

• The product shall never be

used while the compartment

which is located at the top or

back of your product and in

which electronic boards are

available (electronic board box

cover) (1) is open.

For products with a

water dispenser;

• Pressure for cold water inlet

shall be maximum 90 psi (6.2

bar). If your water pressure

exceeds 80 psi (5.5 bar), use a

pressure limiting valve in your

mains system. If you do not

know how to check your water

pressure, ask for the help of a

professional plumber.

• If there is risk of water

hammer effect in your

installation, always use a

water hammer prevention

equipment in your installation.

Consult Professional

plumbers is you are not

sure that there is no water

hammer effect in your

installation.

• Do not install on the hot

water inlet. Take precautions

against of the risk of

freezing of the hoses. Water

temperature operating

interval shall be 33°F (0.6°C)

minimum and 100°F (38°C)

maximum.

• Use only potable water.

Child safety

• If the door has a lock, the key

should be kept away from

reach of children.

• Children must be supervised to

prevent them from tampering

with the product.

Compliance with WEEE

Directive and Disposing of

the Waste Product:

This product complies

with EU WEEE Directive

(2012/19/EU). This product

bears a classification

symbol for waste electrical

and electronic equipment

(WEEE).

This product has been manufactured

with high quality parts and materials

which can be reused and are suitable

for recycling. Therefore, do not dispose

the product with normal domestic

waste at the end of its service life. Take

it to a collection point for the recycling

of electrical and electronic equipment.

Please consult your local authorities to

learn the nearest collection point. Help

protect the environment and natural

resources by recycling used products.

For children’s safety, cut the power

cable and break the locking mechanism

of the door, if any, so that it will be

non-functional before disposing of the

product.

Package information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations. Do

not dispose of the packaging materials

together with the domestic or other

wastes. Take them to the packaging

material collection points designated by

the local authorities.

Do not forget...

Any recycled substance is an

indispensable matter for nature and our

national asset wealth.

If you want to contribute to the

re-evaluation of the packaging

materials, you can consult to your

environmentalist organizations or the

municipalities where you are located.

HC warning

If your product's cooling system

contains R600a:

This gas is flammable. Therefore, pay

attention to not damaging the cooling

system and piping during usage and

transportation. In the event of damage,

keep your product away from potential

fire sources that can cause the

product catch a fire and ventilate the

room in which the unit is placed.

Ignore this warning if your

product's cooling system contains

R134a.

Type of gas used in the product is

stated in the type label which is on the

left wall inside the refrigerator.

Never throw the product in fire for

disposal.

Things to be done for energy

saving

• Do not leave the doors of your

refrigerator open for a long time.

• Do not put hot food or drinks in your

refrigerator.

• Do not overload your refrigerator so

that the air circulation inside of it is not

prevented.

• Do not install your refrigerator

under direct sunlight or near heat

emitting appliances such as ovens,

dishwashers or radiators. Keep your

refrigerator at least 30cm away from

heat emitting sources and at least

5cm from electrical ovens.

• Pay attention to keep your food in

closed containers.

• For products with a freezer

compartment; You can store

maximum amount of food items in

the freezer when you remove the

shelf or drawer of the freezer. Energy

consumption value stated for your

refrigerator has been determined

by removing freezer shelf or drawer

and under maximum load. There

is no harm to use a shelf or drawer

according to the shapes and size of

food to be frozen.

• Thawing frozen food in fridge

compartment will both provide energy

saving and preserve the food quality.

Recommendations for the

fresh food compartment

*May not be available in all models

Do not allow the food to touch the

temperature sensor in fresh food

compartment. To allow the fresh food

compartment keep its ideal storage

temperature, sensor must not be

hindered by food.

Do not place hot foods in the product.

3Installation

BIn case the information which are

given in the user manual are not

taken into account, manufacturer will

not assume any liability for this.

Points to be paid attention

to when the relocation of the

refrigerator

1. Your refrigerator should be

unplugged.Before transportation of

your refrigerator, it should be emptied

and cleaned.

2. Before it is re-packaged,

shelves, accessories, crisper, etc.

inside your refrigerator should be

fixed with adhesive tape and secured

against impacts. Package should

be bound with a thick tape or sound

ropes and the transportation rules

on the package should be strictly

observed.

3. Original packaging and foam

materials should be kept for future

transportations or moving.

Before you start the refrigerator,

Check the following before you

start to use your refrigerator:

1. Attach 2 plastic wedges as

illustrated below. Plastic wedges

are intended to keep the distance

which will ensure the air circulation

between your refrigerator and the

wall. (The picture is drawn up as a

representation and it is not identical

with your product.)

2. Clean the interior of the

refrigerator as recommended in the

“Maintenance and cleaning” section.

3. Connect the plug of the

refrigerator to the wall socket. When

the fridge door is opened, fridge

internal lamp will turn on.

4. When the compressor starts to

operate, a sound will be heard. The

liquid and gases sealed within the

refrigeration system may also give rise

to noise, even if the compressor is not

running and this is quite normal.

5. Front edges of the refrigerator

may feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Electrical connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

The connection must be in compliance

with national regulations.

• The power plug must be easily

accessible after installation.

• Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

• The voltage stated on the label

located at left inner side of your

product should be equal to your

network voltage.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Beko Kühlschrank Handbücher

Beko

Beko BSSA820M3SN Bedienungsanleitung

Beko

Beko BCSA285K2S Bedienungsanleitung

Beko

Beko RCNA366E60LZXRN Bedienungsanleitung

Beko

Beko RDM 6106 Bedienungsanleitung

Beko

Beko RDNE350K20X Bedienungsanleitung

Beko

Beko RDSE465K20W Bedienungsanleitung

Beko

Beko RDM 6106 Bedienungsanleitung

Beko

Beko refrigerator Bedienungsanleitung

Beko

Beko DN161220X Bedienungsanleitung

Beko

Beko B1 9426 NM Bedienungsanleitung

Beko

Beko BCSA285K41SN Bedienungsanleitung

Beko

Beko BDSA250K4SN Bedienungsanleitung

Beko

Beko RCSA330K21PT Bedienungsanleitung

Beko

Beko RFNE 270 K21 W Bedienungsanleitung

Beko

Beko RDNT230I50VZWB Bedienungsanleitung

Beko

Beko GNE60532DXPN Bedienungsanleitung

Beko

Beko CN 232120 Bedienungsanleitung

Beko

Beko RCSA350K21W Bedienungsanleitung

Beko

Beko RDNT270I20VP Bedienungsanleitung

Beko

Beko RFNE312E13S Bedienungsanleitung

Beko

Beko GN163220S/1 TRB Bedienungsanleitung

Beko

Beko ASML142B Bedienungsanleitung

Beko

Beko DS227030N Bedienungsanleitung

Beko

Beko DSA25020 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung

Matsui

Matsui MTT50W12E Bedienungsanleitung
