UL483APW

ULC532W

Under the Counter

Larder Fridge

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in a 1st-class manufacturing

facility and checked under the most meticulous quality control procedures, will

provide you with years of good service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future reference.

This manual

• Will help you use your appliance quickly and safely.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

1 Your refrigerator 3

2 Warnings 4

Electrical requirements.......................5

Warning! This appliance must be

earthed..............................................5

Energy saving tips .............................6

Compliance with WEEE Directive and

Disposing of the Waste Product: .......6

Compliance with rohs directive: ........6

Package information..........................6

3 Installation 7

Points to be considered when re-

transporting your refrigerator .............7

Before operating your refrigerator ......7

Adjusting the feet...............................8

Disposing of the packaging ...............8

Disposing of your old refrigerator .......8

Placing and Installation ......................8

Replacing the interior light bulb .........9

Reversing the doors ........................10

Reversing the door ..........................11

4 Preparation 12

5 Using your refrigerator 13

Using interior compartments............13

Cooling............................................13

Stopping your product.....................14

Defrosting........................................14

6 Maintenance and cleaning 15

Protection of plastic surfaces ..........15

7 Do's and don'ts 16

8 Guarantee details 17

9 How to obtain service 18

1Your refrigerator

1. Top trim

2. Movable shelves

3. Interior light & Thermostat knob

4. Defrost water collection channel -

Drain tube

5. Crisper cover

6. Crisper

7. Adjustable front feet

8. Door shelves

9. 2L Bottle storage position

10.Bottle shelf

CFigures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

Congratulations on your choice of a BEKO quality Appliance which has been

designed to give you service for many years.

2Warnings

• Do not connect your appliance to

the electricity supply until all packing

and transit protectors have been

removed.

• If transported horizontally leave

to stand upright for at least 4

hours before switching on to allow

compressor oil to settle

• If you are discarding an old

refrigerator with a lock or latch fitted

to the door, disable the lock/latch,

ensure that it is left in a safe condition

to prevent the entrapment of young

children.

• This fridge/freezer must only be used

for its intended purpose i.e the storing

and freezing of edible foodstuff.

• Do not dispose of the appliance on a

fire. At BEKO, the care and protection

of our environment is an ongoing

commitment. This appliance which

is among the latest range introduced

is particularly environment friendly.

Your appliance contains non CFC

/ HFC natural substances in the

cooling system (Called R600a) and in

the insulation (Called cyclopentane)

which are potentially flammable

if exposed to fire. Therefore, take

care not to damage, the cooling

circuit / pipes of the appliance in

transportation and in use. In case of

damage do not expose the appliance

to fire or potential ignition source and

immediately ventilate the room where

the appliance is situated.

• We suggest you contact your local

authority for disposal information and

facilities available.

• See Installation Instructions on on

page 8 for information on suitable

location.

• To obtain the best possible

performance and trouble free

operation from your appliance it is

very important to carefully read these

instructions.

• On delivery, check to make sure that

the product is not damaged and that

all the parts and accessories are in

perfect condition.

• Ensure that the plug remains readily

accessible. Do not use multiple

adapter or extension cable.

• Failure to observe these instructions

may invalidate your right to free

service during the guarantee period.

• Keep ventilation openings, in the

appliance enclosure or in the built-in

structure, clear of obstruction.

• Do not use mechanical devices

or other means to accelerate the

defrosting process, other than those

recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances

inside the food storage

compartments of the appliance,

unless they are of the type

recommended by the manufacturer.

• We suggest you keep these

instructions in a safe place for easy

reference.

FITTED WITH

BS 1362 13A FUSE ALWAYS

FIT BS 1362 REPLACEMENT

CARTRIDGE FUSE

GREEN &

YELLOW

GREEN

BLUE

BLACK

BROWN

RED

22mm.

6mm.

6mm. 32mm.

12mm.

FUSE

CORD GRIP

• This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

• Children should be supervised to

ensure that they do not play with the

appliance.

Electrical requirements

Before you insert the plug into the

wall socket make sure that the voltage

and the frequency shown on the rating

plate inside the appliance corresponds

to yourelectricity supply.

Rating label is on the left hand side of

fridge inner liner.

We recommend that this appliance be

connected to the mains supply via a

Suitable switched and fused socket.

The appliance must be positioned so

that the plug is accessible.

Should the mains lead of the appliance

become damaged or should it need

Replacing at any time, it must be

replaced by a special purpose made

mains lead which can only be obtained

from a BEKO authorised service agent.

Warning! This appliance

must be earthed

If the fitted moulded plug is not suitable

for your socket, then the plug should be

cut off and an appropriate plug fitted.

Destroy the old plug which is cut off as

a plug with bared cord could cause a

shock hazard if inserted into a socket

elsewhere in the house.

The moulded plug on this appliance

incorporates a 13 A fuse. Should the

fuse need to be replaced an ASTABEAB

approved BS 1362 fuse of the same

rating must be used. Do not forget

to refit the fuse cover. In the event of

losing the fuse cover the plug must not

be used until a replacement fuse cover

has been fitted.

Colour of the replacement fuse cover

must be the same colour as that visible

on the pin face of the plug. Fuse covers

are available from any good electrical

store.

Important! Fitting A Different Plug

As the colours of the wires in the

mains lead of this appliance may not

correspond with the coloured markings

identifying the terminals in your plug

proceed as follows: (See diagram).

1. Connect the green-yellow or green

(Earth) wire to the terminal in the plug

marked ‘E’ or with the symbol or

coloured green and yellow or green.

2. Connect the blue (Neutral) wire to

the terminal in the plug marked ‘N’ or

coloured black.

3. Connect the brown (Live) wire to the

terminal in the plug marked ‘L’ or

coloured red.

With alternative plugs a 13 A fuse must

be fitted either in the plug or adaptor or

in the main fuse box. If in doubt contact

a qualified electrician.

Energy saving tips

1. Ensure your appliance is installed in a

well ventilated area.

2. Ensure the time between buying

chilled/frozen food and placing

them in your appliance is kept at

minimum, particularly in summer. We

recommend you use a cool bag or a

special carrier bag to carry perishable

food.

3. Do not leave the door (s) of your

appliance open longer than

necessary and ensure they are closed

properly after each opening.

4. Defrost frozen food in the fridge

compartment, so that frozen food

acts as an ice pack to assist cooling

in the fridge.

Compliance with WEEE

Directive and Disposing of

the Waste Product:

This product complies with EU WEEE

Directive (2012/19/EU). This

product bears a classification

symbol for waste electrical

and electronic equipment

(WEEE).This product has

been manufactured with

high quality parts and

materials which can be reused and are

suitable for recycling. Do not dispose of

the waste product with normal domestic

and other wastes at the end of its

service life. Take it to the collection

center for the recycling of electrical and

electronic equipment. Please consult

your local authorities to learn about

these collection centers.

Compliance with rohs

directive:

The product you have purchased

complies with EU RoHS Directive

(2011/65/EU). It does not contain

harmful and prohibited materials

specified in the Directive.

Package information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations. Do

not dispose of the packaging materials

together with the domestic or other

wastes. Take them to the packaging

material collection points designated

by the local authorities.

3Installation

BPlease remember that the

manufacturer shall not be held liable if

the information given in the instruction

manual is not observed.

Points to be considered

when re-transporting your

refrigerator

1. Your refrigerator must be

emptied and cleaned prior to any

transportation.

2. Shelves, accessories, crisper and etc.

in your refrigerator must be fastened

securely by adhesive tape against any

jolt before repackaging.

3. Packaging must be tied with thick

tapes and strong ropes and the

rules of transportation printed on the

package must be followed.

Please do not forget…

Every recycled material is an

indispensable source for the nature and

for our national resources.

If you wish to contribute to recycling the

packaging materials, you can get further

information from the environmental

bodies or local authorities.

Before operating your

refrigerator

Before starting to use your refrigerator

check the following:

1. Is the interior of the refrigerator dry

and can the air circulate freely in the

rear of it?

2. Please install the 2 plastic wedges

as illustrated in the figure. Plastic

wedges will provide the required

distance between your refrigerator

and the wall in order to allow the air

circulation. (The illustrated figure is

only an example and does not match

exactly with your product.)

3. Clean the interior of the refrigerator as

recommended in the “Maintenance

and cleaning” section.

4. Plug the refrigerator into the wall

outlet. When the fridge door is open,

the fridge compartment interior light

will come on.

5. You will hear a noise as the

compressor starts up. The liquid and

gases sealed within the refrigeration

system may also give rise to noise,

even if the compressor is not running

and this is quite normal.

6. Front edges of the refrigerator may

feel warm. This is normal. These

areas are designed to be warm to

avoid condensation.

Electric connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Adjusting the feet

If your refrigerator is unbalanced;

You can lever your refrigerator by

turning the front feet as shown in the

illustration below. The corner where the

feet exists is lowered when you turn it in

the direction of black arrow and raised

when you turn in the opposite direction.

Getting help from someone to slightly

lift the refrigerator will facilitate this

process.

Important:

• The connection must be in

compliance with national regulations.

• The power cable plug must be easily

accessible after installation.

• The specified voltage must be equal

to your mains voltage.

• Extension cables and multiway plugs

must not be used for connection.

BA damaged power cable must be

replaced by a qualified electrician.

BProduct must not be operated before

it is repaired! There is danger of

electric shock!

Disposing of the packaging

The packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose of them by

classifying them in accordance with the

waste instructions. Do not dispose of

them along with the normal household

waste.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old refrigerator without

giving any harm to the environment.

• You may consult your authorised

dealer or waste collection center of

your municipality about the disposal

of your refrigerator.

Before disposing of your refrigerator,

cut out the electric plug and, if there

are any locks on the door, make them

inoperable in order to protect children

against any danger.

Placing and Installation

1. Install your refrigerator to a place that

allows ease of use.

2. Keep your refrigerator away from heat

sources, humid places and direct

sunlight.

3. There must be appropriate air

ventilation around your refrigerator

in order to achieve an efficient

operation. If the refrigerator is to be

placed in a recess in the wall, there

must be at least 5 cm distance with

the ceiling and at least 5 cm with

the wall. If the floor is covered with

a carpet, your product must be

elevated 2.5 cm from the floor.

4. Place your refrigerator on an even

floor surface to prevent jolts.

Replacing the interior light

bulb

Should the light fail to work switch

off at the socket outlet and pull out

the mains plug. Follow the below

instructions to check if the light bulb

has worked itself loose.

If the light still fails to work obtain

a replacement E14 screw cap type

15 Watt (Max) bulb from your local

electrical store and then fit it as follows:

1. Switch off at the socket outlet and

pull out the mains plug. You may find

it useful to remove shelves for easy

access.

2. Remove the light diffuser cover as

shown in figure (a-b).

3. Replace the burnt-out light bulb.

4. Reassemble the light diffuser cover

as shown in figure (c).

“Push firmly to ensure cover is fitted

properly.”

5. Carefully dispose of the burnt-out

light bulb immediately.

“Replacement light bulb can easily be

obtained from a good local electrical or

DIY store.”

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Beko Kühlschrank Handbücher

Beko

Beko BCSA306KFSN LH Bedienungsanleitung

Beko

Beko BK 8182 Bedienungsanleitung

Beko

Beko RCSA406K30W Bedienungsanleitung

Beko

Beko CXFG1675DS Bedienungsanleitung

Beko

Beko CNE60530DX Bedienungsanleitung

Beko

Beko CN 136120 Bedienungsanleitung

Beko

Beko RCSA330K30BN Bedienungsanleitung

Beko

Beko GNE134750X Bedienungsanleitung

Beko

Beko RCNA406K30XB Bedienungsanleitung

Beko

Beko CFD6643AP Handbuch

Beko

Beko BFFD3620SS Bedienungsanleitung

Beko

Beko FN127920 Bedienungsanleitung

Beko

Beko DN153720DX Bedienungsanleitung

Beko

Beko CN236220X Bedienungsanleitung

Beko

Beko ASP33B32VPZ Bedienungsanleitung

Beko

Beko WSA 14000 Bedienungsanleitung

Beko

Beko CBI 7771 Bedienungsanleitung

Beko

Beko CSE 24007 Bedienungsanleitung

Beko

Beko RFNE312L25W Bedienungsanleitung

Beko

Beko TS 190340N Bedienungsanleitung

Beko

Beko nstallation & operating instructions and washing... Bedienungsanleitung

Beko

Beko DSE 25012 Bedienungsanleitung

Beko

Beko LCSM1545W Bedienungsanleitung

Beko

Beko RCNA366K34XBN Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Teledyne

Teledyne 6712FR and Betriebsanleitung

Matsui

Matsui MTT50W12E Bedienungsanleitung
