Beko WMY10148C2 Bedienungsanleitung
2820526139_EN/06-07-18.(11:12)
Document Number=
Front-Loading
Automatic Washer
Owner’s Guide & Installation
Instructions
WMY10148C2
EN
As an ENERGY STAR® partner,
BEKO has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.
To prevent accidents and machine damage, read these
instructions before installation or use. Use the washer only as
instructed in this owner’s guide and installation instructions
included with your washer. Keep this guide for future reference
2 / English Front-Loading Automatic Washer
Please read this guide first!
Dear Customer,
We hope that your product which has been manufactured in modern
facilities and passed through a strict quality control procedure will give
you the best results.
Therefore, we advise you to read through this document carefully
before using your product and keep it for future reference.
This guide will…
…help you use your washer in a fast and safe way.
• Please read the guide before installing and starting your washer.
• Particularly follow the instructions related to safety.
• Keep this guide within easy reach. You may need it in the future.
• Please read all additional documents supplied with this washer.
Please note that this owner’s guide & installation instructions may be
applicable for several other models. Differences between models will
be identified in the guide.
This product was manufactured using the latest technology in environmentally friendly conditions.
Owner’s Guide & Installation Instructions 3 / English
Explanation of symbols
Throughout this guide the following symbols are used:
CCAUTION
• Important information or useful hints about usage.
AWARNING
• Warning for hazardous situations with regard to life and property.
BWARNING
• Warning for electrical shock
Please contact your authorized Beko dealer or visit www.beko.us to
locate and get information for the closest authorized Beko service
center
Please fill in the information below for future reference.
Model no.:
Serial no.:
Purchase date:
4 / English Front-Loading Automatic Washer
TABLE OF CONTENTS
1 Your Washer 6
Overview .......................................................6
Specifications ....................................................7
2 Important Safety Instructions 8
3 Installation Instructions 13
The Right Location of Installation ....................................13
Installation Clearances ............................................14
Allowable Clearances for Undercounter Installation.......................15
Allowable Clearances for Closet Installation ............................16
Stacked Installation ..............................................16
Removing packaging reinforcement ..................................16
Removing shipping bolts ..........................................17
Leveling the washer ..............................................18
Electrical Connection .............................................18
Power supply and circuit ..........................................20
Water Supply Connection..........................................21
Drainage.......................................................23
Installation Checklist ..............................................24
Transportation ..................................................24
Disposal Information..............................................25
Appliance Disposal ...............................................25
4 Operating Instructions 26
First Use.......................................................26
Laundry Tips ...................................................27
Preparing the laundry .............................................28
Loading the washer ..............................................29
Detergent Use ..................................................30
Detergent Quantity ...............................................31
Detergent Dispenser..............................................32
(II) Main Wash Detergent Compartment ...............................33
Liquid Fabric Softener Compartment .................................34
Using liquid detergents ............................................34
(I) Liquid Chlorine Bleach Compartment ...............................35
Water Consumption ..............................................35
Owner’s Guide & Installation Instructions 5 / English
TABLE OF CONTENTS
5 Selecting a Program and Operating Your Washer 36
Control panel ...................................................36
Programs .....................................................37
Program selection ...............................................40
Program and consumption table.....................................42
Temperature selection ............................................45
Spin speed selection .............................................46
Rinse Hold .....................................................46
Auxiliary function selection .........................................47
End Time ......................................................49
Changing the selections after program has started .......................50
Child Lock .....................................................51
6 Preparation 52
Starting the program .............................................52
Door locking system..............................................53
Adding or taking out laundry........................................53
Cancelling the program ...........................................54
Re-spinning the laundry ...........................................54
End of program .................................................55
Energy saving mode..............................................55
7 User maintenance instructions 56
Cleaning detergent dispenser .......................................56
Cleaning the door seal ............................................57
Cleaning the drum ...............................................57
Cleaning the outer cabinet and control panel ...........................58
Cleaning the water inlet strainers ....................................58
Cleaning the drain pump filter ......................................59
Descaling the washer .............................................61
8 Troubleshooting 62
9 WARRANTY STATEMENT FOR THE BEKO CLOTHES WASHERS 75
10 HOW TO GET SERVICE 76
6 / English Front-Loading Automatic Washer
1Your Washer
1
2
3
4
5
6
7
8
Overview
1- Power cable
2- Top panel
3- Control panel
4- Drain hose
5- Loading door
6- Filter cap
7- Adjustable feet
8- Detergent drawer
Owner’s Guide & Installation Instructions 7 / English
Your Washer
Specifications
Specifications of this appliance may change without notice to improve
the quality of the product. Figures in this guide are schematic and
may not match your product exactly.
Values stated on the washer labels or in the documentation
accompanying it are obtained in laboratory in accordance with the
relevant standards. Depending on operational and environmental
conditions of the appliance, these values may vary.
Front Loading Automatic Washer
Models WMY10148C2
Height (in) / (cm) 33.1 / 84
Width (in) / (cm) 23.6 / 60
Depth (in) / (cm) 26.3 / 67
Net Weight (lbs) / (kg) 167.6 / 76
Electricity (V/Hz.) 208-240 / 60
Total Current (A) 10
Total Power (W) 2000-2350
Water pressure (psi) / (bar) (15-145) / (1-10)
Drain height (ft.) / (m.) 4.9 / 1.5
Wash capacity (cu. Ft.) 2.5
Dry Load Capacity (lbs)/(kg) 22.26 / 10.1
8 / English Front-Loading Automatic Washer
2Important Safety Instructions
BWARNING
• To reduce the risk of fire, electric shock or injury to persons while
using your appliance follow basic safety precautions, including
the following:
• Read all instructions before using the washer.
• Do not wash articles that have been previously cleaned in, washed
in, soaked in, or spotted with gasoline, dry-cleaning solvents,
or other flammable or explosive substances (acetone, alcohol,
kerosene, some liquid household cleaners, some spot removers,
turpentine, waxes and wax removers) as they give off vapors that
could ignite or explode.
• Do not add gasoline, dry-cleaning solvents, or other flammable or
explosive substances to the wash water. These substances give off
vapors that could ignite or explode.
• Under certain conditions, hydrogen gas may be produced in a
hot-water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using a washing machine, turn
on all hot-water faucets and let the water flow from each for several
minutes. This will release any accumulated hydrogen gas. As the
gas is flammable, do not smoke or use an open flame this time.
• Do not allow children to play on or in the appliance. Close
supervision of children is necessary when the appliance is used
near children.
• Before the appliance is removed from service or discarded, remove
the door and the power cord / main plug to prevent accidents.
• Do not reach into the appliance if the drum is moving. Wait until the
drum has completely stopped before opening the door.
• Do not install or store this appliance where it will be exposed to the
weather and direct sunlight.
• Do not tamper with controls.
Owner’s Guide & Installation Instructions 9 / English
Important Safety Instructions
• Do not repair or replace any part of the appliance or attempt any
servicing unless specifically recommended in the user-maintenance
instructions or in published user-repair instructions that you
understand and have the skills to carry out.
• This appliance must only be used for the purpose of washing,
rinsing and spinning machine-washable items using laundry
additives that are suitable for use in washers . The appliance
manufacturer cannot be held responsible for damage caused by
improper or unintended use of the appliance.
• Only detergents, softeners and additives suitable for use in
HE (High-efficiency) washers may be used. Always follow the
instructions and information given by the laundry detergent
manufacturers when using these products.
• Always follow the fabric care instructions of garment manufacturers.
• Do not touch the door glass while washing at high temperatures.
Danger of burning!
• Do not sit on top of the washer.
• Do not climb onto the washer.
• Destroy the shipping carton, plastic bag and other packing
materials after the washer is unpacked. Keep children away from
these packing materials. Danger of suffocation from plastic sheets
and cartons!
• Do not mix chlorine bleach with ammonia or acids such as vinegar
and/or rust remover when washing. This mixture can produce
hazardous fume which may cause death.
• Do not operate this appliance if it is damaged, malfunctioning,
partially disassembled, or has missing or broken parts, including a
damaged cord or plug.
10 / English Front-Loading Automatic Washer
Important Safety Instructions
• Store laundry detergents and additives in a cool, dry place out
of children’s reach due to danger of chemical poisoning and skin
irritation. Follow the manufacturers’ instructions when using laundry
products.
• Do not machine wash fiberglass materials. Small particles can stick
to fabrics washed in following cycles and may lead to skin irritation.
• Do not wash items stained with vegetable oil, cooking oil or
petroleum. These items may contain some flammable oils after
laundering and the fabric may smoke or catch fire by itself.
• Be sure to unplug the power cable before attempting maintenance
or cleaning of your appliance to minimize the risk of electric shock.
Always unplug the cable by grasping the plug, not the cord.
• Do not use wet hands when plugging/unplugging the power cable.
• Check the water inlet and drain hose connections regularly for any
leakage. Hoses should be replaced every 5 years.
• Do not leave the washer door open to prevent children hurt
themselves by hanging on the door or going inside the drum.
• Be careful when the appliance is draining hot water. Danger of
burning!
• At the end of a washing day, turn off the water faucets to prevent
any leakage that may occur due to a faulty condition of the
appliance.
• Check the appliance and inlet hose connections for water leakage
after each use. If there is leakage, turn off the appliance and water
faucets and call service.
• Do not machine wash items having large or heavy metal parts such
as buttons or buckles. These items could severely damage the
appliance.
• Always be sure to empty all foreign materials from the pockets of
your clothing as small items such as coins, pins etc. could severely
damage the appliance.
• Do not install and operate the appliance in places exposed to
temperatures below freezing. Frozen water may cause severe
damage by bursting hoses and pump.
Inhaltsverzeichnis
Andere Beko Waschmaschine Handbücher
Beko
Beko WTE 5411 B0 Bedienungsanleitung
Beko
Beko WMB 61011 CS N Bedienungsanleitung
Beko
Beko WJ842443W Bedienungsanleitung
Beko
Beko WTV 7512 XMCI2 Bedienungsanleitung
Beko
Beko WUX71032WI-IT Bedienungsanleitung
Beko
Beko WTE10744X0D Bedienungsanleitung
Beko
Beko WCV 8616 X0 Bedienungsanleitung
Beko
Beko WTE 7532 BCX Bedienungsanleitung
Beko
Beko D 6102 B Bedienungsanleitung
Beko
Beko WTV 8636 XS Bedienungsanleitung
Beko
Beko BFLB902ADW Bedienungsanleitung
Beko
Beko WTE7512BO Bedienungsanleitung
Beko
Beko B5W5941AW Bedienungsanleitung
Beko
Beko WTL 11019 G Bedienungsanleitung
Beko
Beko WTIK74151F Bedienungsanleitung
Beko
Beko WITV 8712 XW0 Bedienungsanleitung
Beko
Beko WTL104121W Bedienungsanleitung
Beko
Beko WTB620E1W Bedienungsanleitung
Beko
Beko WTE 7512 XS0 Bedienungsanleitung
Beko
Beko B3W5841IG Bedienungsanleitung
