Belgacom IDS 310
Operator station manual
Forum IS16/48/80/160
1
2
3
User guide
The present User guide describes the services provided by the BELGACOM IDS 310
operator station, when connected to an IS16/48/80/160 system.
The guide only covers functions specific to the IDS 310 (refer to the station user
guide for information concerning the other services):
restricted service,
reserving a group of outside lines for exclusive operator use,
diverting operator calls to another number,
broadcasting background music on the external loudspeaker,
answering a night call,
programming.
The operator station receives incoming calls and routes them to the appropriate
extensions within the system.
epending on the amount of traffic handled, your system can have one or
more operator stations:
grouped: all stations ring simultaneously,
assigned to specified time periods: only stations currently operational will ring.
This option is set up by your installation technician.
44
Symbols used
in the documentation
Actions, occurrences
Navigator
Display and display keys
Programmable keys and icons
Preprogrammed key
(function represented by icon).
“Services”
programmed key
Key accessing a service,
if programmed by installation technician.
Icon corresponding to key.
Line key.
isplay key.
Partial view of display.
Indicates movement required.
Indicates result of action.
escription of action or
context.
text on blue
background
Hang up.
Lift receiver.
Press.
Keypads
Audio keys
Other ixed keys
Other symbols used
Choice of operating mode within
an action sequence.
Other alternative
to action sequence.
Indicates a remark.
Indicates important information.
Hang up
or wait 2 seconds.
Fixed key.
Adjustment “increase".
Adjustment “decrease".
Hands free.
Loudspeaker.
Specific key
on numeric keypad.
Alphabetic keypad.
Numeric keypad.
Symbols can be enriched by small icons or text.
5
Contents
Description o operator station............................................ p. 6
Operator station unctions..................................................... p. 9
Setting restricted service, reserving a group of lines,
manually diverting operator calls to another number,
broadcasting background music on an external loudspeaker,
answering a night call, using a headset.
Programming unctions.......................................................... p. 13
Accessing the “Subscriber" function, programming the date,
time and system directory.
Setting up “Subscriber" terminals..................................... p. 15
Accessing the “Subscriber" function, subscriber's name,
entering a password, display language,
personal directories, discrimination criteria.
“Expert" supplementary unctions..................................... p. 19
Accessing “Expert" mode, business codes table,
direct numbers of extensions, greeting and holding messages,
ECT cordless phones, changing an operator password,
reconfiguring the system.
Index ................................................................................................ p. 25
6
Description o operator station
Mute key - so that
your correspondent
can no longer hear you.
Alphabetic ke pad
Protected by a flap and is used for call by name,
message services and programming.
A self-adhesive “Memo" label is supplied to be
placed inside the flap.
to increase loudspeaker
or receiver volume.
Loudspeaker:
to share a conversation.
Hands free:
to take a line or answer a call without lifting the receiver.
Audio ke s
Navigator
Enables several display pages
to be scanned for the selection of a line
(by default, the bottom line is selected).
Previous page Next page
Top line
Bottom line
Guide ke : check or change your programming.
efine function of unassigned display
keys and preprogrammed keys.
+
Change value assigned to a key.
+
Identity of terminal.
+
•Terminate
a call or
programming.
to reduce loudspeaker
or receiver volume.
•
•
•
•
•
•
•
•
7
Description o operator station
Displa and displa ke s
isplay comprises several pages, with two lines per page, giving information concerning
your call and functions accessible using the keys corresponding to the lines on the screen.
Make a call. ivert your calls to another number.
Redial the last number dialled. isplay more information.
Prevent outside calls. Customize your terminal.
Request appointment reminder call. Programme company data.
Intercept a call to another extension Programme and manage the system.
Programmable ke s and icons
To make a call, activate a service or manage your calls.
Each key has corresponding icons:
Call icons Function icons
Preprogrammed function ke s:
Some other ke s can be programmed b our installation technician as a function
of our requirements:
Key which must be programmed by your installation technician to access a service.
Accessing your personal directory.
Transfer a call to another number.Access various message services.
Make an IS N call.ivert calls to another number.
Normal or restricted mode.
Lines 1 to 15: Outside line key on
your system.
Group supervision.Internal or outside line key.
Call on common hold.
Terminal or line busy.Call on hold.
Function requiring action.Call in progress.
Function active.Incoming call (flashing).
Three-colour indicator light
The indicator light on your terminal enables you to monitor the system. The light has five
possible statuses (colours and/or flashing):
Flashing green: message received (voice or screen) or call received
in the “calls received" memory.
Orange fixed: indicates traffic overload level 1 (1 is calls on hold).
Flashing orange: terminal on test.
Red fixed: indicates traffic overload level 2 (call unanswered within
20 seconds or number of calls on hold exceeds number of operator stations).
Flashing red: several low priority system messages present or one very serious system
message indicating a system hardware fault.
8
Handling precautions
Never allow your telephone to be in contact with water. However, the telephone can be cleaned
using a soft, slightly damp, cloth.
Never use solvents (trichlorethylene, acetone, etc.) which can damage the plastic surface
of the telephone. Never use cleaning aerosols.
Installing the programmable ke labels
Printed labels are supplied with the terminal, to be
installed under the programmable keys.
Insert a “ flat blade " into the slot
(1 slot per key block).
Raise the key block cover..
Slide the printed label into position.
Replace the cover.
11
22
33
44
Description o operator station
9
Operator
station functions
Setting restricted service ....................................................................................................... p. 10
Reserving a group of lines ................................................................................................... p. 10
Manually diverting operator calls to another number........................................... p. 10
Broadcasting background music on
an external loudspeaker......................................................................................................... p. 11
Answering a doorphone call ............................................................................................... p. 11
Using a headset.......................................................................................................................... p. 11
