LR200M Mobile Thermal Receipt Printer
USER MANUAL
1
Table of Contents
1Introduction..........................................................................................2
1.1 Safety Information......................................................................................... 2
1.2 Usage Notice ................................................................................................... 2
1.3 Storage Notice ................................................................................................ 3
1.4 Battery Safety Notice .................................................................................... 3
1.5Electromagnetic compatibility statement ................................................. 4
2Overview................................................................................................5
2.1 Appearance...................................................................................................... 5
2.2Accessories ...................................................................................................... 6
3Operation ..............................................................................................7
3.1 Preparation before use .................................................................................. 7
3.2 Basic Functions............................................................................................... 8
3.3 Printer Communication Interface .............................................................. 10
3.4 LED Indicators and Buzzer Signal Description .......................................... 11
3.5 Preventive Maintenance...............................................................................12
4Configuration Utility Software ........................................................ 14
4.1 Basic settings .................................................................................................14
4.2 WiFi settings ..................................................................................................15
4.3 Bluetooth settings ........................................................................................15
4.4 Advanced settings .........................................................................................15
5Troubleshooting................................................................................. 16
6Specifications ..................................................................................... 18
2
1 Introduction
Thank you for purchasing the LR200M mobile thermal receipt printer. Bematech is
committed to continuously improve product quality and provide better after-sales
service. In order to take full advantage of our devices, we strongly recommend that you
take the time to read this manual before diving into software solution.
Note: Information in this manual may change without prior notice.
1.1 Safety Information
(1) This printer can only use battery and power adapter provided by our company,
or it may cause damage to the printer, battery leakage, fire or explosion.
(2) Do not put the battery into the fire, do not make it short circuit, break up or
heating, otherwise it may cause the battery leakage, fire or explosion.
(3) The battery liquid is corrosive. If the user’s improper operation results in
battery leakage and the liquid is contact with the skin or the clothes please use
the clean water to wash immediately. If the liquid accidentally gets into the
eyes, please rinse with plenty of clean water to wash the eyes and go to the
hospital.
(4) When printing or printing just finished, do not open paper cover and use finger
or any part of body to touch the printer mechanism. The high temperature may
cause scald.
(5) Do not use the printer when the operation is failed. Please turn off and unplug
it. Then call the dealer.
1.2 Usage Notice
(1) Do not submerge the printer into the water and do not expose it in rain for
prolonged time; otherwise it may lead the damage to the printer.
(2) Do not open the paper cover when printing.
(3) When using USB interface to print, do not disconnect the USB cable when
printing, otherwise it may result in incompletion of the print data.
(4) The printer could work stably from -10°C to 50°C, but the higher temperature
(>=45°C) or lower temperature (<=5°C) would degrade the print quality. Higher
humidity (>=85%) or lower humidity (<=20%) also may degrade the print quality.
(5) Use of printing paper with bad quality or stored for too long would affect the
print quality and may even damage the printer.
3
1.3 Storage Notice
(1) The printer should be stored in the environment where the temperature is -20°C
to 70°C and relative humidity is 5% to 95%.
(2) If the printer is to be stored for a long time, please take out the battery and
stored it separately, otherwise it may result in the battery lose efficiency and
may even cause leakage that damage the printer.
(3) Do not store the thermal paper in a high temperature or direct sunlight
environment. Seal off the packing and store it in dark and cool place.
1.4 Battery Safety Notice
Please read this user manual carefully before using the printer. Ignoring the
followings may cause overheating, burning, explosion, damage of the battery and/or
degrade the lifespan of the printer.
Warnings:
(1) Do not let water or sea water in or leak into the battery. If the safety device
in it is burned out, any charge of it would lead abnormity current and or voltage
and bring unusual chemistry reaction, then cause the overheating, burning and/
or explosion.
(2) Do not use or place the battery near flame or high temperature environment.
Overheating may cause damage to the resin shell and/or heat insulation
material, and results in short circuit in the battery that leads overheating,
burning and/ or explosion.
(3) Please use the only the charger supplied with the printer for charging. When
charging under the abnormal conditions (such as high temperature, high
voltage/current or using modified charger), it may cause excessive battery
charging, abnormal current and/ or voltage, causing unusual chemistry reaction
and then may result in overheating, burning and/or explosion.
(4) Positive and negative contacts are marked clearly on the battery. The user
should make sure the battery position is correct when inserting into the charger
or printer. Reverse insertion would lead to reverse charging that may cause
unusual chemistry reaction and then may result in overheating, burning and/or
explosion of the battery.
(5) Do not make the battery contact to power socket and/or car cigarette lighting
socket, which may lead high voltage, bring excessive current and result in
overheating, burning and/or explosion of it.
(7) Do not heat the battery or put it into the fire that may melt the heat insulation
material or damage the safety device or equipment and may ignit the
electrolytic that results in overheating, burning and/or explosion.
4
(8) Do not let the battery contacts ((+) and (-)) to any metal objects. Do not store it
with metal materials, such as necklace, hairpin etc. Short circuit in the battery
may cause excessive current, then results in overheating, burning and/or
explosion.
(9) Do not drop the battery and avoid physical damage. If the safety device in the
battery is damaged, charging of the battery would cause abnormal current
and/or voltage that leads to overheating, burning and/or explosion.
1.5 Electromagnetic compatibility statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment. This device
complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This device and its antenna must not be located or
operating in conjunction with any other antenna or transmitter.
5
2 Overview
The LR200M is a high quality mobile printer using thermal technology for printing. It is
compatible with most point-of-sale systems on the market. The LR200M portable printer
optimizes the mobile checkout process and helps accelerate business at the Point of Sale.
The printer is equipped with both Bluetooth and WiFi interface, enabling it to work with
POS applications designed for either wireless communications.
The rubber protection and non-slip design makes the light weight printer drop-resistant
and easy to work with, making it ideal for mobile operations.
2.1 Appearance
1
11
2
4
10
9
8
7
3
5
6
12
6
1. Status Indicator
2. Feed Key
3. Battery indicator
4. Power Key
5. Printer top cover
6. USB interface connector
7. Power supply connector
8. Error indicator
9. Printer body
10. Transparent cover
11. Cover opening lever
12. Battery
2.2 Accessories
Battery
Power Charger
Paper Roll
CD-ROM
Carrying belt clip
USB Cable
7
3 Operation
3.1 Preparation before use
(1) Battery Installation
1. As shown in the picture, put battery into the battery compartment.
2. Press the battery down until it is locked into the battery compartment.
(2) Paper Roll Installation
Transparency
cover
Battery
y
Cover lever
Press on both sides
8
1. Pull up the cover level or press on both sides of cover to open it.
2. As shown in picture, place the paper roll in the printer. Note the correct
direction of paper, otherwise the printer will not work properly.
3. As shown in picture, pull out a length of paper extending it out of the paper
roll compartment.
4. Make sure that the paper roll is properly aligned and close the cover.
3.2 Basic Functions
(1) Power On
Under power off status, press and keep holding "POWER" button for two
seconds, printer will be powered on with a short beep. Then release the power
button. Printer status indicator (green LED) will turn on.
Paper
roll
9
Note: If printer power indicator (blue LEDs) goes out and the error indicator (red
LED) turns on, it means the printer is going to power off. Please change the
battery or recharge it. For recharging steps, please refer to (5) below.
(2) Change font size
Under power off status, press and keep holding "POWER" button. The printer
will be powered on with a short beep sound. If the button is kept holding, it will
make a long beep sound, then follow by groups of 2, 3, 4 and 5 short beeps. If
the power button is released after the groups of 2, 3,4 or 5 beeps, it will change
the font to one of the 4 fonts. The 4 font sizes are defined as follows.
2 beeps - Font A: 12 x 24
3 beeps - Font B: 9 x 24
4 beeps - Font C: 9 x 17
5 beeps - Font D: 8 x 16
Note: The font size can also be selected by application software by issuing font
selection commands.
(3) Power Off
Under power on status, press and keep holding "POWER" button for two seconds,
then the printer will be powered off and all indicator lights will be off.
(4) Self-Test
The printer can run self-test to check the settings and status.
Self-Test method as follows: Power off (if the printer is power on) the printer,
then press "FEED" key and at the same time press and hold "POWER" key to turn
power on. The printer will print out the self-test page which contains the printer
status, setting and printing sample.
(5) Feed (Feed Manually)
Under printer ready status, press "FEED" key, the printer will start feeding paper.
(6) Battery Recharge
When the printer has been working for a long time, the battery will be out of
power. In that case, the printer power indicator (blue lights) will go out , and at
the same time the error indicator (red light) will turn on. This means the battery
needs recharging. If the printer powers off automatically while printing, the
battery need to be recharged.
To recharge the battery, plug the charger power adapter into AC power socket,
and connect the DC plug to the charger socket of the printer. During the charging
process, under power on status, power indicator (blue light) will keep flashing
Andere Handbücher für LR200M
2
Inhaltsverzeichnis
Andere Bematech Drucker Handbücher
Bematech
Bematech LR1100U Bedienungsanleitung
Bematech
Bematech MP-2500 TH Bedienungsanleitung
Bematech
Bematech LR2000 Bedienungsanleitung
Bematech
Bematech MP-2100 TH Bedienungsanleitung
Bematech
Bematech MP-4000 TH Bedienungsanleitung
Bematech
Bematech LR200M Betriebsanleitung
Bematech
Bematech LR2000 Bedienungsanleitung
Bematech
Bematech LR200M Bedienungsanleitung
Bematech
Bematech LR2000 Betriebsanleitung
Bematech
Bematech MP-4000 TH Bedienungsanleitung
