Bestway InflateYourFun 58233 Bedienungsanleitung

Trademarks used in some countries under license from/

Marques utilisées dans certains pays sous la licence de/

Marcas comerciales utilizadas en algunos países bajo la licencia de/

Die Warenzeichen werden in einigen Ländern verwendet unter Lizenz der/

Marchi utilizzati in alcuni paesi concessi in licenza a

Bestway Inflatables & Material Corp., Shanghai, China

Manufactured, distributed and represented in the European Union by/

Fabriqués, distribués et représentés dans l’Union Européenne par/Fabricado, distribuido y representado en la Unión Europea por/

Hergestellt, vertrieben und in der Europäischen Union vertreten von/Prodotto, distribuito e rappresentato nell'Unione Europea da

Bestway Europe S.p.a., Via Resistenza, 5, 20098 San Giuliano Milanese (Milano), Italy

Distributed in Latin America by/Distribué en Amérique latine par/Distribuido en Latinoamérica por/Distribuído na América Latina por

Bestway Central & South America Ltda, Salar Ascotan 1282, Parque Enea, Pudahuel, Santiago, Chile

Distributed in Australia & New Zealand by Bestway Australia Pty Ltd, Unit 2/98-104 Carnarvon St Silverwater, NSW 2128, Australia

Tel: Australia: (+61) 2 9037 1388; New Zealand: 0800 142 101

Distributed in United Kingdom by Bestway Corp UK Ltd. 8 Wentworth Road, Heathfield Industrial Estate, Newton Abbot, Devon, TQ12 6TL

Exported by/Exporté par/Exportado por/Exportiert von/Esportato da

Bestway (Hong Kong) International Ltd./Bestway Enterprise Company Limited

Suite 713, 7/Floor, East Wing, Tsim Sha Tsui Centre, 66 Mody Road, Kowloon, Hong Kong

www.bestwaycorp.com

58233

P6525ASS16P6818ASS16

Skimmer

Body Screw Basket Float Adjustable

Pole Frame Hook Hook

P6521ASS16 P6522ASS16 P6523ASS16

Cover Rim

P6817ASS16 P6526ASS16 P6527ASS16 P6528ASS16

Arm

P03868

Hose Adapter

P6531ASS16

Hose

Parts Reference

Overview

POOL SURFACE SKIMMER

OWNER’S MANUAL

WARNING

IMPORTANT SAFETY INSTRUCTIONS. READ AND FOLLOW ALL INSTRUCTIONS.

WARNING:To reduce the risk of injury, do not permit children to use this product.

WARNING:Assembly and disassembly of this product should only be performed by adult.

WARNING: Do not remove or obstruct the float opening while the filter pump/sand filter is operating.

WARNING: Keep hands and hair away from the Skimmer while the filter pump/sand filter is operating.

WARNING: Do not use the filter pump/sand filter while the pool is occupied.

WARNING: Ensure the filter pump/sand filter is unplugged before preforming any maintenance or there

will be a severe risk of injury or death.

NOTE: Remove the product from the pool before placing a cover over the pool.

NOTE: Please examine and verify all components are present before use. Notify Bestway at the customer

service address listed on this manual for any damaged or missing parts at the time of purchase.

NOTE: Drawings are for illustration purposes only and may not reflect actual product. Drawings are not to

scale.

SAVE THESE INSTRUCTIONS

Specification

Filter Pump/Sand Filter Compatibility：

Pool Compatibility：For use with all above ground pools

except steel wall pools

2,006 L/h (530 gal./h) flow rate and above

NOTE:

1. Assemble the hook: put the adjustable pole (P6525) through the adjustable fastener on the hook (P6527 or

P6526). Attach the assembled hook to the skimmer body and tighten it with the provided screw (P6521).

(See Fig.2)

2. FOR FAST SET

AND OVAL FAST SET

POOLS (See Fig. 3(a)) Place the assembled hook onto the

pool’s inflatable ring near the outlet valve, and attach the arm (P6528). You can adjust the opening of the hook

by pressing and sliding the arm at the same time.

3. FOR STEEL PRO

FRAME AND RECTANGULAR FRAME POOLS (See Fig. 3(b)) Place the assembled frame

hook onto the pool’s top rail near the outlet valve. Adjust the hook if necessary and tighten the nut on the

frame hook (P6526).

NOTE:

We supply Hose Adapter, use it for your pool. (See Step 4a1)

If there are two outlet valves on your pool, please block one of them. (See Step 4a2)

Operation

1. The float should be floating off the skimmer body by 5 cm to 10.1 cm (2 in. to 4 in.). To adjust the float height,

loosen the screw (P6521), slide the skimmer body (P6818) up or down, and tighten the screw. (See Fig.6)

IMPORTANT: The skimmer must be perpendicular to the water surface at all times.

2. Plug in the filter pump/sand filter to activate the skimmer.

Storage

1. Disassemble the product.

2. Clean and dry all the parts thoroughly.

3. Store in a warm dry place.

P6817ASS16

P6523ASS16

P6522ASS16

P6521ASS16

P6818ASS16

P6531ASS16

P6525ASS16

P6526ASS16

P6528ASS16

P6527ASS16

4.(a1)

4.(a2) 4.(b)

P03868

(1)

(2) (3)

P6818ASS16

P6527ASS16

P6521ASS16

P6525ASS16

P6526ASS16

P6531ASS16

P6817ASS16

P6523ASS16

P6522ASS16

P6528ASS16

3.(a) 3.(b)
