T4.6

UM - T 4 . 6 - 2 0 0 9 0 5 0 7 v e r A

User Manual

4 x 6 line array full

range column speaker

10.

Read the instruction first before using this product.

Pay attention to all warnings.

Obey all operating instructions.

Do not expose this product to rain or moisture.

Do not block any ventilation openings. Install according to instructions .

Do not install this product near any heat source, such as , heater, burner, or any other equipment with heat radiation .

Only use spare parts by manufacturer.

Pay attention to the safety symbol on the of the cover.

manual

Please keep this manual for future reference

Clean this equipment with a dry cloth.

manufacturer's

supplied the

outside

SAFETY INSTRUCTIONS

PLEASE READ THIS MANUAL FIRST

Thank you for a buying product. Read this manual first as it will help you operate the system properly. Please keep this manual

for future reference.

WARNING:

This product must be installed by professionals. When using hanging brackets or rigging other than those supplied with

the product, please ensure they comply with the local safety codes.

The exclamation point within an equilateral triangle is intended to alert you to the presence of important

operating and servicing instructions.

ATTENTION: Don't refit the system or spare parts without being authorized as this will .void the warranty

WARNING: Don't (such as candles) the equipment.place naked flames close to

T4.6

CONTENT

PRODUCT INTRODUCTION

Main Features

Product Description

Applications

CONNECTION

INSTALLATION

Optional Installation Accessories

Installation Options

TECHNICAL SPECIFICATIONS

Specifications

Frequency Response and Impedance Curve

CONTENT

Dimensions

T series full range speaker line array column

Product information updated without

notification, please visit www.elderaudio.com for

latest update.

may be

Push Terminals

System Reference Diagram

The β3 T4.6 line array full range column speaker is one

T4.6

Frequency response 90Hz-16KHz(-3dB).

Sensitivity 92dB, Max SPL 115dB.

Dispersion 180° x 25°.

Rated power 180w, max power 720w.

Plywood cabinet with durable textured paint finish.

optional accessories.Suitable for many venues including

inside and outside undercover environments.

Can be installed alone or stacked in multiples using the

Patents pending for central diffuser plate.

A vertical line array of 6 x 4" full range transducers providing

high fidelity sound.

Designed for high speech intelligibility and natural

sounding music.

Main Features

Adding the optional line transformer accessory makes the

T4.6 line array speaker very versatile in 70/100v systems.

To enhance the already great performance of the T4.6 you

can use the EQ filters provided.

Product Description

A diffuser plate (patent pending) is fitted to the centre

drivers to assist with the vertical pattern control.

The T4.6 speaker can either be used in singles, multiples

or stacked using the optional accessories in many indoor

applications such as Houses of Worship, Shopping Malls,

Transport Terminals, Theme Parks, Meeting Rooms, Schools,

Small Auditoriums. When stacking the T4.6 end on end to

create a taller line array the height of the line array must

correspond to the ear height range of the listeners in both

seated or standing positions.

The T4.6 is manufactured from 15 mm plywood meeting a

tensile strength of 3500N and is finished in either black or

white using a very durable textured paint. The metal speaker

grill is powder coated and passes all rust resistance tests.

The T4.6 is shipped with a quick install U bracket.

o three speakers in the T Series. This attractively designed, f

180W RMS, innovative speaker delivers high speech

intelligibility and natural sounding music in a wide range

of applications through its 4" full range drivers. A vertical

line array of 6 drivers provides control over a horizontal

and vertical pattern of 180° x 25° and reproduces the critical

vocal range 90Hz-16kHz without requiring a processor.

Applications

churches/temples

small auditoriums

multifunction halls

meeting rooms

schools

shopping malls

transport terminals

theme parks

PRODUCT INTRODUCTION T series full range speaker line array column

4 x 6 line array full range column speaker

Quick install U bracket included.

T4.6

1+ 1- 2+ 2-

CHA

BRIDGE IN

CHB

SIGNAL GND

SIGNAL +

SIGNAL -

BRIDGE

PARALLEL

STEREO ON

OFF

50HZ

25HZ

OFF

CHB OUTPUT

CHA OUTPUT

POWER

CABLE

FUSE

5HZ

CAUTION

BRIDGE

OUTPUT ASSIGNMENT:

BRIDGE MONO OUTPUT:

CHA :

PIN1+ : SIGNAL GND

CHA: PIN 1+ :

PIN 1 - :

PIN 2+ :

PIN 2 - :

CHA SIGNAL

CHA GND

CHB SIGNAL

CHB GND

CHB: PIN 1+ :

PIN 1 - :

PIN 2+ :

PIN 2 - :

CHB SIGNAL

CHB GND

PIN2+ :

Serial no:

Special design for big power！

RISK OF ELECTRIC SHOCK

DO NOT OPEN

MODE LF FILTER GROUND

CLIPLIMITER

INPUT

PIN1:

PIN2:

PIN3:

T4.6

1+ 1- INPUT

OUTPUT

INPUT

MUTE

DOWN

DISPLAY

RECALL

/ENTER

MUTE MUTE MUTE MUTE MUTE MUTE MUTE

-6

-10

-20

-40

COMP

OVER

LOCK

IN-1

IN-2

SLF

LIMITER

OVER

-6

-10

-20

-40 SLF

IN-2

IN-1

-40

-20

-10

OVER

LIMITER IN-1

IN-2

SLF

LIMITER

OVER

-6

-10

-20

-40 SLF

IN-2

IN-1

-40

-20

-10

-6

OVER

LIMITER IN-1

IN-2

SLF

LIMITER

OVER

-6

-10

-20

-40 SLF

IN-2

IN-1

-40

-20

-10

-6

OVER

LIMITER

-6

PROGRAM

STATUS

REMOTE/ID

21 CBA D E F

POWER

T4.6

LOW

NL4

1+ 1+

Speakon NL4

CONNECTION

The T4.6 rear panel has two input connectors. You can choose to use either the 4 way push terminal connector or the NL4

speakon connector. The two connectors are paralleled for through connection.

Push Terminals

System Reference Diagram

Processor (Optional EQ curves available on CD)

Warning: Please make sure the speaker impedance and polarity match the amplifiers.

T series full range speaker line array column

T4.6

INSTALLATION

1.Wall bracket

1.Flying

Optional Installation Accessories

The T4.6 cabinet has 3 flying points, plus a stand mount

adaptor to ensure fast and easy installation. To install

stacked speakers there are an optional coupling brackets.

3.Stand mount adaptor

4.Tripod

Installation Options

Extension mount

2. Stand mount 3. Speaker coupling

Warning: Always ensure the mounting accessories

safety factor is not less than 5:1 or that it meets the

local standards.

T series full range speaker line array column

2.Speaker coupling brackets Ceiling mount Wall mount

T4.6

Sensitivity (dB)

100

110

120

7.5

Frequency (Hz)

Impedance (Ohms)

50 100 200 500 2k 5k 10k 20k

Frequency response curve (with control)

Frequency response curve (without control)

Impedance curve

Sensitivity(1W@1m):

Frequency Response(-3dB):

Frequency Response(-10dB):

Product:

Transducer:

Power:

Rated Impedance:

Cabinet:

Installation:

Grill:

Connector:

Net Weight:

Gross Weight:

Optional Accessories:

90Hz-16kHz

92dB

8 ohms

180° x 25°

135x169x800mm

(5.3x6.7x31.5in)

115dB/121dB( )PEAK

80Hz-17kHz

9kg (19.8 lbs)

10kg (22.0 lbs)

240x205x900mm

(9.4x8.1x35.4in)

Passive Wooden Speaker

180W (RMS)

360W (MUSIC)

720W (PEAK)

TECHNICAL SPECIFICATIONS

Specifications

Technical Specifications

Speaker Testing Method

1. Frequency Response

Use Pink noise to test the speaker in the anechoic chamber, adjust the

level to make the speaker work at its rated impedance and set the output

power at 1W, then test the frequency response 1m away from the

speaker.

2. Sensitivity

Use full range Pink noise which has been modified using an EQ

curve to test the speaker in the anechoic chamber, increasing the

signal to make the speaker work at its rated impedance and set the

power output at 1W, then test the sensitivity 1m away from the

speaker.

3. MAX.SPL

Use full range Pink noise which has been modified using an EQ

curve to test the speaker in the anechoic chamber , increase the

signal to make the speaker work at its maximum power output

level, then test the SPL1m away from the speaker.

4. Rated Power

Use Pink noise to the IEC#268-5 standard to test the speaker,

increase the signal for a continuous period of 100 hours, the

rated power is the power whenthe speaker will show no visible

or measurable damage.

T series full range speaker line array column

6 x 4'' Full range transducers

15mm plywood construction

White powder coated ,

0.8mm steel mesh.

Screw terminal and 1 NL4 Speakon

Packing Dimension(WxDxH):

Dispersion Angle（HxV）:

Dimension(WxDxH):

Maximum. SPL(1m):

Mounting U bracket included and

optional mounting points provided.

Paint: White durable textured finish

Coupling bracket, Stand adaptor,

Tripod

T4.6

135mm

[5.32in]

169mm

[6.65in]

800mm

[31.50in]

300mm

[11.81in]

100 mm

[3.94in]

52mm

[2.05in]

93mm

[3.66in]

Top view

Front viewSide view Back view

Bottom view

Dimensions

TECHNICAL SPECIFICATIONS T series full range speaker line array column

Notes:

www.beta3pro.com

Inhaltsverzeichnis

Andere Beta Three Sprecher Handbücher

Beta Three

Beta Three T15a THUNDER Series Pro Bedienungsanleitung

Beta Three

Beta Three T4.8 Bedienungsanleitung

Beta Three

Beta Three WS2218B Bedienungsanleitung

Beta Three

Beta Three S800N Bedienungsanleitung

Beta Three

Beta Three V122a Bedienungsanleitung

Beta Three

Beta Three S800Na Bedienungsanleitung

Beta Three

Beta Three WS115 Bedienungsanleitung

Beta Three

Beta Three MU series Bedienungsanleitung

Beta Three

Beta Three CPM SERIES Bedienungsanleitung

Beta Three

Beta Three Rs12 Bedienungsanleitung

Beta Three

Beta Three Rs10 Bedienungsanleitung

Beta Three

Beta Three S215a Bedienungsanleitung

Beta Three

Beta Three WS112 Bedienungsanleitung

Beta Three

Beta Three BS2002 Bedienungsanleitung

Beta Three

Beta Three S1200Na Bedienungsanleitung

Beta Three

Beta Three TW12a Bedienungsanleitung

Beta Three

Beta Three SS2153II Bedienungsanleitung

Beta Three

Beta Three CSR10 Bedienungsanleitung

Beta Three

Beta Three TH Series Bedienungsanleitung

Beta Three

Beta Three MU series Bedienungsanleitung

Beta Three

Beta Three QS600T Bedienungsanleitung

Beta Three

Beta Three Two-Way Dual 12 Bedienungsanleitung

Beta Three

Beta Three TLA-101 Bedienungsanleitung

Beta Three

Beta Three CSB218A Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung
