Beyerdynamic Byron BTA Bedienungsanleitung
Byron BTA
BLUETOOTH IN-EAR HEADSET
Manual
english
Byron BTA – In-ear headset 3
Contents
1. Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. ow to wear the in-ear headset . . . . . . . . . . . . . . . . . . . . 8
7. Button Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8. Getting started with your Byron BTA . . . . . . . . . . . . . . . 11
8.1 Pairing to your mobile phone . . . . . . . . . . . . . . . . 11
8.2 Multi point setting . . . . . . . . . . . . . . . . . . . . . . . . 11
8.3 Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8.4 Factory reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8.5 Playing music . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9. What does the LED colour mean? . . . . . . . . . . . . . . . . . 13
10. FAQ & Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . 13
11. Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
12. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
13. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
14. Battery disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
15. Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
16. Simplified EU Declaration of Conformity . . . . . . . . . . . . 15
Byron BTA – In-ear headset
4
Thank you for selecting the Byron BTA stereo Bluetooth in-ear head-
set from beyerdynamic. Please take some time to read carefully
through this manual before using the product. Please keep the
manual. When passing on the headset to a third party, please pass
on the manual as well.
1. Safety instructions
Warning: When connecting the in-ear headset, make sure that
you have turned the volume down to the minimum.
Adjust the volume only after the in-ear headset are in
place. To avoid any potential damage to your hearing,
do not use the in-ear headset at loud volumes for
extended periods of time. As a rule of thumb, when you
have the in-ear headset on, set the volume to a level at
which you can still hear your own voice when you speak
at a normal volume while listening.
We would like to point out that listening at high
volumes over a long period of time may damage your
hearing irreversibly.
Make sure that the set volume is not too high.
Rule of thumb: The higher the volume, the shorter the
time of listening. According to employer’s regulations
for safety and health the noise exposure should not
exceed 85 dB (low volume) when working with an
allowed time of listening of 8 hours at maximum. If the
volume is increased by 3 dB, the allowed time of
listening is halved, i.e. with 88 dB the time of listening
is 4 hours, with 91 dB 2 hours and so on.
Danger!
In-ear headsets dramatically reduce your ability to hear ambient
noise. Using the in-ear headsets while in road traffic is potentially
very dangerous and is therefore prohibited by law. Also, please make
sure that you do not use your in-ear headset when in the vicinity of
possibly dangerous machines and tools.
Risk of injury!
When wearing wired in-ear headphones, avoid any sudden move-
ments. You could seriously injure yourself, especially if you have any
piercings or wear earrings or glasses, etc. that can get caught in the
wire.
Altered auditory perception
Many people need some time to get used to wearing in-ear headsets.
Your auditory perception of your own voice and body, and even the
sounds in your inner ear while walking, are different from “normal”
situations when you are not wearing an in-ear headset. This strange
sensation will usually abate after wearing in-ear headsets for a while.
english
Byron BTA – In-ear headset 5
2. Features
• Premium Sound
(MSTS™ Tuning Technology & apt-X codec & AAC codec)
MSTS™ Tuning Technology together with compression codec
apt-X & AAC codec enables you to enjoy premium hi-fi stereo
sound.
With a built-in DSP chip, it supplies optimal call quality by noise
reduction and echo cancellation.
• Multi Point
• Bluetooth 4.2
• Voice prompts
• Firmware upgrade
The latest firmware is available for optimised usage.
Its functions are variable depending on the mobile phone.
• Fixing magnet
There is a built-in magnet to hold the L&R earphone together,
making it easier to carry when not using.
Caution:
American eart Association and British Drug Administration warn
that magnets can affect medical equipments (pacemaker,
defibrillators, insulin pump and other electronic medical equip-
ment) if the distance between magnets and medical equipment
is within 15 cm).
Please do not use this product before you consult with your
doctor, if you are using the mentioned medical equipment.
Please do not place this product around areas, influenced by
magnetism.
Of magnetic products such as a credit card, telephone card, bank
account or ticket, the information can be deleted.
3. Accessories
1 pair of in-ear headset
4 pairs of eartips (1x S, 2x M, 1x L)
1 pair of ear hooks
1 charging cradle
1 cable clip
Byron BTA – In-ear headset
6
4. Controls and indicators
햸
햲
햳
햴
햵
햶
햷
햹
햲Microphone
햳LED guide light for headset
status LED
햴Charging contacts
햵Volume up, next song etc.
햶Main function button (MFB)
for turning on/off, answer/
reject/convert a call/ play/ etc.
햷Volume down, previous song
etc.
햸Ear hook for comfortable
wearing
햹Fixing magnet for holding
L/R earphone together while
not in use
english
Byron BTA – In-ear headset 7
Charging
Make sure that your headset is fully charged before you use it.
The LED glows “red” during charging and will turn “blue” when fully
charged.
5. Operating instructions
When turning the headset on/off or selecting the pairing mode, you
will hear a voice prompt.
Turn on the in-ear headset
Press the MFB button until you hear “Power on” and the blue LED
glows.
Turn off the in-ear headset
When you press the MFB button for a longer time (approx. 5 seconds),
the purple LED will glow and the headset is turned off after you hear
“Power off”.
Byron BTA – In-ear headset
8
6. How to wear the in-ear headset
Fix the ear hook first, if you
need a stronger fit.
Then attach the eartip to the
earphone.
Fix the eartip to the ear.
Wear the earphone as shown in
the illustration.
Tip
Select the eartip size that fits
you best. It is comfortable to
wear the in-ear headset with
the supporting ear hook.
english
Byron BTA – In-ear headset 9
7. Button guide
You can easily control the in-ear headset with these 3 buttons.
Volume up
Volume down
MFB
Basic button control
Press the MFB button
Answer a call . . . . . . . . . Press briefly
End a call. . . . . . . . . . . . Press briefly
Turn on headset . . . . . . . Press for 2 seconds
(If there is a paired device, it connects to the paired device.)
Turn off headset . . . . . . . Press for 4 seconds
If you press the MFB button for a longer time, the purple LED glows
and the in-ear headset will be turned off after you hear “Power off”.
Pairing mode . . . . . . . . . Press for 4 seconds when you turn on
(if the headset has been connected to a
device before, the headset must be
turned off and turned on again as
described before)
Reject a call . . . . . . . . . . Press for 1 second
Convert a call . . . . . . . . . Press briefly during call
Play/Pause . . . . . . . . . . . Press briefly
Stop. . . . . . . . . . . . . . . . Press for 1 second (during play)
Byron BTA – In-ear headset
10
Press the Volume up button
Volume up (+). . . . . . . . . Press briefly
Mic mute . . . . . . . . . . . . Press for 1 second (during call)
Next song . . . . . . . . . . . . Press for 1 second (during play)
Press the Volume down button
Volume down (-) . . . . . . . Press briefly
Mic mute . . . . . . . . . . . . Press for 1 second (during call)
Previous song . . . . . . . . . Press for 1 second (during play)
Factory reset
Press the buttons in the following order:
The purple LED will glow and the in-ear headset will be initialised.
After a factory reset, pair the in-ear headset again for use.
