Table of Contents
1. Introduction . . . . . . . . . . . 2
2. Features & Applications . . . . . . . . . . . 2
3. Product Specifications . . . . . . . . . . . 3
3.1 Front Panel . . . . . . . . . . . 3
3.2 Battery Specs . . . . . . . . . . . 4
3.3 BMS Specs . . . . . . . . . . . 5
3.4 BMS Protections . . . . . . . . . . . 7
3.5 Control Panel Indicators . . . . . . . . . . . 8
4. Warnings & Precautions . . . . . . . . . . 10
5. Parts & Components . . . . . . . . . . 11
5.1 Installation Safety Guidelines . . . . . . . . . . 11
5.2 Parts & Components . . . . . . . . . . 11
5.3 Environmental Requirements . . . . . . . . . . 12
5.4 Battery Installation . . . . . . . . . . 12
6. PC Software Operation . . . . . . . . . . 15
7. Recycling . . . . . . . . . . 16
8. Warranty & Returns . . . . . . . . . . 17
1
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
1. Introduction
Introducing BigBattery’s 48V LYNX! The LYNX is designed specifically for your
telecom and off-grid applications, packing 5.3 kWh of capacity in a compact and
portable housing! This is the BEST battery money can buy. These units utilize a
lithium iron phosphate (LiFePO4/LFP) chemistry, which is the SAFEST battery
chemistry in the world. This User Manual is designed to provide you with an
understanding of the specs, features, capabilities, and installation of the 48V LYNX.
Read and take note of all safety information prior to installing or operating your
battery. This document applies to the BigBattery 48V LYNX (FLYNX-48053-G1).
2. Features & Applications
Applications
●Telecom
●Solar
●Emergency Power
●Data Centers
●Off-Grid
●Backup Power
Features
●Advanced BMS (Battery
Management System)
●Lithium-Ion LiFePO4/LFP
Chemistry
●LED BMS Alarm Indicators
●Dual Ethernet ports (RS485
Communications)
●DIP Dial Switch
●High quality & durable steel
construction
●Standardized 175-amp
connector for battery power
source
●LED SoC Indicators & Voltage
Display
●Internal Fire Extinguisher
BigBattery’s 48V LYNX is the ultimate solution for your telecom and data center
power supplies, solar and off-grid systems, emergency power storage, and more.
These batteries come equipped with our advanced BMS, and can operate safely
within a wide temperature range. They will last at least 3,700 – 8,000 Complete Full
Charge/Discharge Cycles, and are incredibly versatile, allowing you to easily connect
to and provide power to a variety of larger power systems. The battery utilizes a
standard 175 connection, which easily and safely secures power to your battery unit.
Equipped with the 48V LYNX from BigBattery, you’ll stay powered and prepared!
2
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
3. Product Specifications
3.1 Front Panel
No.
Name
Description
Notes
1
Handles
For carrying and handling
2
Fixture
Rack mount enclosure
3
LED Voltmeter
Displays battery voltage
4
100A Safety
Breaker
Switch the battery output between
on and off
5
BB175
Connector
Easy and safe connection for
charging and discharging
6
Reset
Reset battery to default specs
7
RS485
RS485 communication interface
8
ID (Dial Switch)
Assign addresses to each module
See Section 5.4
9
RUN
Operating LED indicator
ON = Constant
CHRG/DISCHRG =
Flashing
10
ALARM
Alarm LED indicator
11
SoC
State of Charge
Four green LEDs (25%
each)
3
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
3.2 Battery Specs
Parameter
Specification
Unit
Chemistry
Lithium Iron Phosphate,
LiFePO4/LFP
Cell Configuration
16S
n/a
Nominal Voltage
48
Volts (DC)
Capacity (kWh)
5.3
Kilowatt-hours
Capacity (Ah)
103
Amp-hours
Operating Voltage Range
43 – 58.8
Volts (DC)
Charging Voltage Range
55.2 - 57.6
Volts (DC)
Max Charging Voltage
58.8
Volts (DC)
WARNING: Do NOT exceed max charging voltage.
Charging Current Limit
(Continuous)
90
Amps
Discharging Current Limit
(Continuous)
130
Amps
Max Peak Discharge Current
(Over 6 seconds)
350
Amps
Charge Temp Range
0 - 55
(32 - 131)
°C
(°F)
Discharge Temp Range
-30 - 55
(-22 – 131)
°C
(°F)
Optimal Discharge Temp Range
15 - 35
(59 - 95)
°C
(°F)
Storage Temperature Range
(Max 6 months)
(Humidity < 90%)
-5 - 35
(23 - 95)
°C
(°F)
Optimal Storage Temp Range
15 - 35
(59 - 95)
°C
(°F)
Weight
49
(108)
kg
(lb)
Length
62.23
(24.5)
cm
(in)
Width
48.26
(19)
cm
(in)
Height
13.34
(5.25)
cm
(in)
4
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
Safety Features
BMS (Over/Under Voltage & Over-Current
Protection, Thermal Management System)
100A Breaker
Max Battery Connections
Series: Not series capable
Parallel: Max. 8 connections
3.2 BMS Specs
Category
Function
Specification
Unit
Charge Voltage
Protection
Maximum Charger
Voltage (CC-CV)
58.8
Volts (DC)
Overcharge Voltage Limit
Cutoff Protection (each
cell)
3.8 - 3.9
Volts (DC)
Overcharge Voltage Limit
Protection Delay Time
2000
Milliseconds
Overcharge Protection
Recovery Voltage
3.45
Volts (DC)
Discharge
Voltage
Protection
Low Voltage Protection
Limit Range
2.5 - 2.3
Volts (DC)
Low Voltage Protection
Delay Time
2000
Milliseconds
Low Voltage Protection
Recovery
3.1
Volts (DC)
Overcurrent
Protection
Charge Overcurrent
Protection Value Range
102
(120)
Amps
Charge Overcurrent Delay
10
(3)
Seconds
Charge Overcurrent
Release Recovery
Condition
Reconnection delayed 180
seconds
Scenario 1:
Discharge Overcurrent
Protection
130
(150)
Amps
Scenario 1:
Discharge Overcurrent
Protection Delay
10
(3)
Seconds
Scenario 2 (Short Circuit):
Discharge Overcurrent
Protection Range
350
Amps
5
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
Scenario 2 (Short Circuit):
Discharge Overcurrent
Protection Delay Range
1
Second
Discharge Overcurrent
Protection Recovery
Condition
Reconnection delayed 60
seconds
Balance
Function
Maximum Cell Voltage to
Activate Cell Balancing
3.4
Volts (DC)
Voltage Difference to
Activate Cell Balancing
40
Millivolts
(DC)
Balancing Mode
Balance when charging
Balancing Current Range
100
Milliamps
Temperature
Protection
High Temperature
Protection Value when
Charging
60
(140)
°C
(°F)
High Temperature
Protection Release Value
when Charging
55
(131)
°C
(°F)
Low Temperature
Protection Value when
Charging
-5
(23)
°C
(°F)
Low Temperature
Protection Release Value
when Charging
0
(32)
°C
(°F)
High Temperature
Protection Value when
Discharging
60
(140)
°C
(°F)
High Temperature
Protection Release Value
when Discharging
55
(131)
°C
(°F)
Low Temperature
Protection Value when
Discharging
-20
(-4)
°C
(°F)
Low Temperature
Protection Release Value
when Discharging
-10
(14)
°C
(°F)
6
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
3.3 BMS Protections
For all BMS protection and recovery values, refer to Section 3.2 above.
Over Charge Protection
During charging, if the voltage of any cell exceeds the setting for cell protection or
the total voltage of the system is greater than the Max Charging Voltage, the BMS
stops charging. When the voltage of each cell and the total voltage of the battery
drops to the recovery values, the protection is removed.
Over Discharge Protection
During discharge, if the voltage of any cell or the total voltage of the battery is lower
than the protection values, the BMS stops discharging. When all cell voltages and the
total voltage reach the recovery values, the protection is removed.
Charging Over Current Protection
During charging, if the current surpasses the protection value, the BMS will limit the
charging current to less than the protection value.
Discharging Over Current Protection
During discharging, if the current surpasses the protection value, the BMS stops
discharging. Remove the load or charge the battery to remove the protection.
Short Circuit Protection
During discharging, if the current is so much bigger than the normal working current,
it’s considered a short circuit, the BMS will stop discharging.
Reverse Polarity Protection
When the battery and rectifier are in reverse connection, the BMS will immediately
enter a state of polarity protection to protect the battery and rectifier from being
damaged by high currents.
7
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
Cell Temperature Protection
If the temperature of any cell surpasses 70°C or drops below 0°C, the BMS will stop
charging. If the temperature of any cell surpasses 75°C or drops below -20°C, the
BMS will stop the discharge.
PCB High Temperature Protection
If the PCB temperature surpasses 95 °C, the BMS will stop charging or discharging
until the temperature drops below the recovery value.
Cell Balancing
During charging, if all cell voltages are greater than 3.4V and the voltage difference
between cells (ΔU) is > 40mV (ΔU = Max. Cell Voltage - Min. Cell Voltage), the BMS
will trigger the balancing process.
3.4 Control Panel Indicators
BMS Protection Indicators
When the LED alarm light comes on, a BMS protection has been triggered and the
battery has been protected. Please refer to the table below for individual warning
indicators and their recovery process and take the appropriate action.
State
Protection
Indicator
Recovery
Charging
Over Voltage
ALARM
Stop charging. Check module
voltage and charger.
Over Current
ALARM
Stop charging. Check settings and
limitations.
Temperature
ALARM
Stop charging. Wait for the
temperature recovery condition.
Discharging
Under Voltage
ALARM
Stop discharging. Begin charging.
Over Current
ALARM
Stop discharging. Check for current
overload.
Temperature
ALARM
Stop discharging. Wait for the
temperature recovery condition.
8
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
General LED Indicators
State
Warning/N
ormal
RUN
ALARM
SOC LED*
25%
50%
75%
100%
Standby
Normal
ON
OFF
ON as battery capacity indicates
Warning
ON
Flash 2*
Protection
OFF
ON
Charge
Normal
Flash 1*
OFF
Warning
Flash 1*
Flash 2*
Protection
OFF
ON
Discharge
Normal
Flash 2*
OFF
Warning
Flash 2*
Flash 2*
Protection
OFF
ON
BMS Failure
OFF
Flash 2*
OFF
*For State of Charge (SOC), each ON LED indicates an increment of 25% SOC.
**Flash 1 = One flash every 1.2 seconds; Flash 2 = One flash every 2.4 seconds.
9
Need Further Assistance?
Email us @ Support@BigBattery.com (OR) Call us @ # (818) 280-3091.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Beliebte Server Handbücher anderer Marken
iRobo
iRobo IPC2U Bedienungsanleitung
Nortel
Nortel 1000 Con?guration guide Bedienungsanleitung
Asus
Asus AP7500 Bedienungs- und Wartungshandbuch
Avid Technology
Avid Technology AirSpeed 5000 Bedienungsanleitung
HP
HP Integrity rx2600 Installationsanleitung
Milestone
Milestone Husky IVO 350T Bedienungsanleitung
