Biostar B75S3E Benutzerhandbuch
Hi-Fi B75S3E Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a particular
installation.
The vendor makes no representations or warranties with respect to the contents here and
specially disclaims any implied warranties of merchantability or fitness for any purpose.
Further the vendor reserves the right to revise this publication and to make changes to
the contents here without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the
vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice and we will not
be responsible for any mistakes found in this user’s manual. All the brand and product
names are trademarks of their respective companies.
Dichiarazione di conformità
sintetica
Ai sensi dell’art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever these laws may be applied
Table of Contents
Chapter 1: Introduction ...............................................................1
1.1 Before You Start ................................................................................ 1
1.2 Package Checklist ............................................................................ 1
1.3 Motherboard Specifications............................................................... 2
1.4 Rear Panel Connectors..................................................................... 3
1.5 Motherboard Layout.......................................................................... 4
Chapter 2: Hardware Installation................................................5
2.1 Installing Central Processing Unit (CPU).......................................... 5
2.2 Install a Heatsink............................................................................... 7
2.3 Connect Cooling Fans ...................................................................... 8
2.4 Installing System Memory................................................................. 9
2.5 Expansion Slots .............................................................................. 10
2.6 Jumper Setting................................................................................ 12
2.7 Headers & Connectors.................................................................... 13
Chapter 3: UEFI BIOS & Software.............................................19
3.1 UEFI BIOS Setup............................................................................ 19
3.2 BIOS Update................................................................................... 19
3.3 Software .......................................................................................... 23
Chapter 4: Useful Help ..............................................................31
4.1 Driver Installation Note.................................................................... 31
4.2 AMI BIOS Beep Code ..................................................................... 32
4.3 Troubleshooting .............................................................................. 32
Appendix: SPEC In Other Languages......................................34
German....................................................................................................... 34
French ........................................................................................................ 36
Italian .......................................................................................................... 38
Spanish....................................................................................................... 40
Portuguese ................................................................................................. 42
Polish.......................................................................................................... 44
Russian....................................................................................................... 46
Arabic ......................................................................................................... 48
Japanese.................................................................................................... 50
Hi-Fi B75S3E
1
CHAPTER 1: INTRODUCTION
1.1 Before You Start
Thank you for choosing our product. Before you start installing the
motherboard, please make sure you follow the instructions below:
Prepare a dry and stable working environment with sufficient
lighting.
Always disconnect the computer from power outlet before
operation.
Before you take the motherboard out from anti-static bag,
ground yourself properly by touching any safely grounded
appliance, or use grounded wrist strap to remove the static
charge.
Avoid touching the components on motherboard or the rear
side of the board unless necessary. Hold the board on the
edge, do not try to bend or flex the board.
Do not leave any unfastened small parts inside the case after
installation. Loose parts will cause short circuits which may
damage the equipment.
Keep the computer from dangerous area, such as heat
source, humid air and water.
The operating temperatures of the computer should be 0 to
45 degrees Celsius.
To avoid injury, be careful of:
Sharp pins on headers and connectors
Rough edges and sharp corners on the chassis
Damage to wires that could cause a short circuit
1.2 Package Checklist
;Serial ATA Cable x2
;Rear I/O Panel for ATX Case x1
;User’s Manual x1
;Fully Setup Driver DVD x1
Note: The package contents may be different due to the sales region or models in which it was
sold. For more information about the standard package in your region, please contact your dealer
or sales representative.
Motherboard Manual
2
1.3 Motherboard Specifications
SPEC
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pentium / Celeron processor
(TDP: 95W)
Supports Execute Disable Bit / Enhanced Intel SpeedStep® /
Intel Architecture-64 / Extended Memory 64 Technology /
Virtualization Technology / Hyper Threading
Chipset B75
Super I/O
IT8728F-EX
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
Hardware Monitor Controller
Fan Speed Controller
ITE's "Smart Guardian" function
Main Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 1066 / 1333
Supports DDR3 1600 (depending on CPU)
Registered DIMM and ECC DIMM is not supported
SATA 2 & 3 Integrated Serial ATA Controller Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
LAN Realtek RTL 8111G 10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound Codec ALC892
7.1 channels audio out
(2-channel output is from front audio header)
High Definition Audio, Biostar Hi-Fi
USB3.0 B75 Data transfer rates up to 600 MB/s
PCI slot x1 Supports PCI expansion cards
PCI Express Gen3 x 16 slot x1 Supports PCI-E Gen3 x16 expansion card
Slots
PCI Express Gen2 x 1 slot x2 Supports PCI-E Gen2 x1 expansion cards
SATA3 Connector x1 Each connector supports 1 SATA3 devices
SATA2 Connector x5 Each connector supports 1 SATA2 devices
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x2 System Fan Power supply
Clear CMOS Header x1 Restore CMOS data to factory default
USB2.0 Connector x2 Each connector supports 2 front panel USB2.0 ports
USB3.0 Connector x1 Each connector supports 2 front panel USB3.0 ports
Printer Port Connector x1 Each connector supports 1 Printer port
Consumer IR Connector x1 Supports infrared function
Serial Port Connector x1 Connects to RS-232 Port
S/PDIF out Connector x1 Supports digital audio out function
Power Connector (24pin) x1 Connects to Power supply
On Board
Connectors
Power Connector (4pin) x1 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard/ Mouse x1
HDMI Port x1
Connects to PS/2 Keyboard/ Mouse
Connects to HDMI cable
Hi-Fi B75S3E
3
SPEC
VGA Port x1
DVI Port x1
LAN port x1
USB2.0 Port x2
USB3.0 Port x2
Audio Jack x3
Connect to D-SUB monitor
Connect to DVI monitor
Connect to RJ-45 Ethernet cable
Connect to USB2.0 devices
Connect to USB3.0 devices
Provide Audio-In/Out and Mic. connection
Board Size 200 (W) x 244 (L) mm uATX
OS Support Windows XP / Vista / 7 / 8 Biostar reserves the right to add or remove support for any OS
with or without notice
1.4 Rear Panel Connectors
Note1: HDMI, DVI-D & VGA ports only work with an Intel integrated Graphics Processor
Note2: USB3.0 ports (only supported by Windows 7/8) are backward compatible with
USB2.0/USB1.X devices.
Note3: Maximum resolution:
HDMI: 1920 x 1200 @60Hz, compliant with HDMI 1.4a
DVI: 1920 x 1200 @60Hz
VGA: 2048 x 1536 @75Hz
Note4: This motherboard supports dual video output:
Display Devices VGA DVI-D HDMI
VGA X O O
DVI-D O X O
HDMI O O X
Note5: To configure 7.1-channel audio, you have to use a chassis with HD front panel audio
module and enable the multi-channel audio feature through O.S. Audio Utility.
The 2/ 4/ 5.1/7.1-channel configuration
Port 2-channel 4-channel 5.1 channel 7.1 channel
Blue (Rear Panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out
Green (Rear Panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink (Rear Panel) Mic In Mic In Center/Subwoofer Out Center/Subwoofer Out
Green (Front Panel) -- -- -- Side Speaker Out
Motherboard Manual
4
1.5 Motherboard Layout
Note: ■represents the 1st pin.
Hi-Fi B75S3E
5
CHAPTER 2: HARDWARE INSTALLATION
2.1 Installing Central Processing Unit (CPU)
Note:
1. Remove Pin Cap before installation, and make good preservation for future use. When the
CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be
damaged.
2. The motherboard might equip with two different types of pin cap. Please refer below
instruction to remove the pin cap.
Step 1: Pull the socket locking lever out from the socket and then raise
the lever up.
Step 2: Remove the Pin Cap.
Motherboard Manual
6
Step 3: Hold processor with your thumb and index fingers, oriented as
shown. Align the notches with the socket. Lower the processor
straight down without tilting or sliding the processor in the socket.
Note1: The LGA1150 CPU is not compatible with LGA 1155 socket. Do not install a LGA 1150 CPU
on the LGA 1155 socket.
Note2: The CPU fits only in one correct orientation. Do not force the CPU into the socket to prevent
damaging the CPU.
Step 4: Hold the CPU down firmly, and then lower the lever to locked
position to complete the installation.
Step 5: Put the CPU Fan and heatsink assembly on the CPU and buckle it
on the retention frame. Connect the CPU FAN power cable into
the CPU_FAN1 to complete the installation.
Hi-Fi B75S3E
7
2.2 Install a Heatsink
Step 1: Place the CPU fan assembly on top of the installed CPU and make sure
that the four fasteners match the motherboard holes. Orient the assembly
and make the fan cable is closest to the CPU fan connector.
Step 2: Press down two fasteners at one time in a diagonal sequence to secure
the CPU fan assembly in place. Ensure that all four fasteners are secured.
Note1: Do not forget to connect the CPU fan connector.
Note2: For proper installation, please kindly refer to the installation manual of your CPU heatsink.
Motherboard Manual
8
2.3 Connect Cooling Fans
These fan headers support cooling-fans built in the computer. The fan cable and
connector may be different according to the fan manufacturer.
CPU_FAN1: CPU Fan Header
Pin Assignment
1 Ground
2 +12V
3 FAN RPM rate sense
4 Smart Fan Control
SYS_FAN1/2: System Fan Headers
Pin Assignment
1 Ground
2 +12V
3 FAN RPM rate sense
Note:The SYS_FAN1/2 supports 3-pin head connectors; the CPU_FAN1 supports 4-pin head
connector. When connecting with wires onto connectors, please note that the red wire is the
positive and should be connected to pin#2, and the black wire is Ground and should be
connected to GND.
Inhaltsverzeichnis
Andere Biostar Computerhardware Handbücher
Beliebte Computerhardware Handbücher anderer Marken
EMC2
EMC2 VNX Series Betriebsanleitung
Panasonic
Panasonic DV0PM20105 Bedienungsanleitung
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung
Gigabyte
Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung
Raidon
Raidon iT2300 Bedienungsanleitung
National Instruments
National Instruments PXI-8186 Bedienungsanleitung
