Biostar M6TSU Bedienungsanleitung

M6TSU

Federal Communications Commission

(F.C.C) Statement

This device complies with Part 15 of the FCC Rules. Operation of this device is

subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Accessories: This device has been tested and found to comply with the limits of a

Class B digital device, the accessories associated with this equipment are as

follows:

1. Shielded serial cable (Can be obtained from multiple retail outlets)

2. Shielded printer cable (Can be obtained from multiple retail outlets)

3. Shielded video cable (Can be obtained from multiple retail outlets)

4. Shielded power cord (Provided by manufacturer)

These accessories are required to ensure compliance with FCC Rules. It is the

responsibility of the user to provide and use these accessories properly.

This equipment has been tested and found to comply with the limits of a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. There is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, you are

encouraged to try to correct the interference by one or more of the following

measures:

1. Reorient / relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

Caution: Changes or modifications not expressly approved by the manufacturer

could void the user’s authority to operate the equipment.

Disclaimer

The vendor makes no representations or warranties with respect to the contents

hereof and specially disclaims any implied warranties of merchantability or fitness

for any purpose. Further, the vendor reserves the right to revise this publication

and to make changes to the contents hereof without obligation to notify any party

beforehand.

Duplication of this publication, in part or in whole, is not allowed without first

obtaining the vendor’s approval in writing.

Trademarks and Remarks

MS-DOS, Windows NT, Windows 9x, Windows ME, Windows XP and

Windows 2000 are products of Microsoft Corp, with its ownership of trademark,

and are distributed by the Vendor under a license agreement.

All trademarks used in this manual are the property of their respective owners.

Canadian D.O.C. Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus as set out in the radio interference regulations of the

Canadian Department of Communications.

Cet appareil numbérique n’emet pas de bruits radioélectriques dépassant les

limites appliqués aux appareils numbériques de Class B préscrits dans le

reglement du brouillage radioélectrique edict par le ministere Des

Communications du Canada.

Contents

Introduction ................................................................................1-1

1 Motherboard Description .......................................................1-2

1.1 Features...................................................................................................1-2

1.1.1 Hardware.........................................................................................1-2

1.1.2 BIOS................................................................................................1-6

1.1.3 Software ..........................................................................................1-6

1.1.4 Accessories......................................................................................1-6

1.2 Motherboard Installation.........................................................................1-7

1.2.1 System Block Diagram....................................................................1-7

1.2.2 Layout of Motherboard ...................................................................1-8

1.2.3 Quick Reference..............................................................................1-9

1.3 CPU Installation....................................................................................1-10

1.3.1 CPU Installation Procedure: Socket 370.......................................1-10

1.3.2 CPU Fan Header: JCFAN1 ...........................................................1-11

1.3.3 System Fan Header: JSFAN2........................................................1-11

1.4 RAM Module Installation .....................................................................1-12

1.4.1 DIMM ...........................................................................................1-12

1.4.2 How to install a DIMM Module....................................................1-13

1.5 Slots ......................................................................................................1-14

1.5.1 AGP (Accelerated Graphics Port) Slot..........................................1-15

1.5.2 CNR (Communication Network Riser) Slot (Slave only)..............1-15

1.5.3 PCI (Peripheral Component Interconnect) Slots ...........................1-15

Contents

1.6 Connectors, Headers & Jumpers...........................................................1-16

1.6.1 Front Panel Connector: JPANEL1 ................................................1-17

1.6.2 ATX 20-pin Power Connector: JATXPWR1................................1-19

1.6.3 DIMM Power Header: JDIMMPWR1 ..........................................1-19

1.6.4 Hard Disk Connectors: IDE1/IDE2...............................................1-20

1.6.5 Floppy Disk Connector: FDD1 .....................................................1-20

1.6.6 Wake On LAN Header: JWOL1 ...................................................1-20

1.6.7 CMOS Function Selection: JCMOS1............................................1-21

1.6.8 Front USB Header: JUSB2 ...........................................................1-21

1.7 Back Panel Connectors .........................................................................1-22

1.7.1 PS/2 Mouse / Keyboard Connectors: JKBMS1.............................1-22

1.7.2 USB Connector: JUSB1................................................................1-23

1.7.3 Serial and Parallel Interface Ports.................................................1-24

1.7.3.1 The Serial Interface: JCOM1/JCOM2...............................................1-24

1.7.3.2 Parallel Interface Port: JPRNT1........................................................ 1-26

1.7.4 Game (Joystick/MIDI) Port Connector: JGAME1........................1-27

1.7.5 Audio Port Connectors: JSPKR1/JLIN1/JMIC1...........................1-27

1.7.6 Audio Subsystem...........................................................................1-28

1.7.6.1 AUX Audio in Header: JAUX1 (Optional)....................................... 1-28

1.7.6.2 Telephony Header: JTAD1................................................................1-29

1.7.6.3 Front AUDIO Header: JAUDIO1 .....................................................1-29

1.7.6.4 CD Audio-In Headers: JCDIN1/JCDIN2.......................................... 1-29

2. BIOS Setup..............................................................................2-1

Contents

iii

2.1 Main Menu..............................................................................................2-3

2.2 Standard CMOS Features........................................................................2-6

2.3 Advanced BIOS Features........................................................................2-9

2.4 Advanced Chipset Features...................................................................2-12

2.5 Integrated Peripherals ...........................................................................2-14

2.6 Power Management Setup.....................................................................2-19

2.7 PnP/PCI Configurations........................................................................2-24

2.8 PC Health Status ...................................................................................2-27

2.9 Frequency/Voltage Control...................................................................2-29

3. RAID BIOS Setting (Optional)..............................................3-1

3.1 Getting Started ........................................................................................3-1

3.1.1 Introduction.....................................................................................3-1

3.1.2 Main Features & Benefits................................................................3-1

3.2 Installation of Driver...............................................................................3-2

3.2.1 Introduction.....................................................................................3-2

3.2.2 Windows 98/ME .............................................................................3-2

3.2.3 Windows NT4.0..............................................................................3-4

3.2.4 Windows 2000 ................................................................................3-6

3.3 Use RAID Administrator ........................................................................3-9

3.3.1 Install RAID Administrator.............................................................3-9

3.3.2 Run RAID Administrator ..............................................................3-10

3.3.3 Create Stripe Array (RAID 0, for Performance)............................3-11

3.3.4 Create Mirror Array (RAID 1, for Data Protection)......................3-16

Contents

3.3.5 Add/Remove Spare Disk...............................................................3-21

3.3.6 Synchronize/Validate/Verify Mirror Array ...................................3-22

3.3.7 Create Span Array.........................................................................3-24

3.3.8 Create 0+1 Array (For Performance & Data Protection)...............3-25

3.3.9 Remove Disk Array.......................................................................3-28

3.3.10 Set Transfer Mode.......................................................................3-29

3.3.11 Device Status...............................................................................3-30

3.3.12 Hot-swapping Hard Disks of Mirror Array .................................3-31

3.3.13 Event Log....................................................................................3-32

3.4 BIOS Configuration..............................................................................3-33

3.4.1 Enter into BIOS Configuration Utility ..........................................3-33

3.4.2 Create RAID..................................................................................3-34

3.4.3 Delete RAID..................................................................................3-35

3.4.4 Rebuild Mirror Array ....................................................................3-35

3.4.5 Add Spare Disk .............................................................................3-36

3.4.6 Remove Spare Disk.......................................................................3-36

3.4.7 Set Disk Mode...............................................................................3-36

3.4.8 Set Boot Disk. ...............................................................................3-37

4. Trouble Shooting....................................................................4-1

Chapter1 Motherboard Description

1-1

Introduction

System Overview

Congratulations on the purchase of your new system! This motherboard is designed

to take advantage of the latest industry technology to provide you with the ultimate

solution in data processing. In the tradition of its predecessors, this motherboard

continues a commitment to reliability and performance and strives for full compliance

and compatibility with industry software and hardware standards.

M6TSU Highlights:

8 Contains on board I/O facilities, which include two serial ports, a parallel port, a

PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports and a game port.

8 Contains on board IDE facilities for IDE devices such as hard disks and CD-ROM

Drives.

8 Supports the Intel Pentium®!!! (Socket 370) processor, a leading edge processor

which brings to you the latest technology in microarchitecture design, graphics

performance, system bus design, cache architecture and much more.

8 Complies with PC ATX form factor specifications.

8 Supports popular operating systems such as Windows 95/98, Windows NT,

Windows 2000, Windows ME, Windows XP, Novell, UNIX, LINUX and SCO

UNIX.

Chapter1 Motherboard Description

1-2

1 Motherboard Description

1.1 Features

1.1.1 Hardware

CPU −The Pentium®

!!!

processors (FC-PGA) and CeleronTM (FC-PGA)

processor (533MHz and > 566MHz) and Tualatin (FC-PGA2)

processor the new generation power for high-end workstations and

servers.

−Provides Socket 370.

−Running at 66 MHz,100 MHz and 133MHz Front Side Bus frequency.

Speed −Supports from 533 MHz to 1.2 GHz CPU core speeds.

−Supports 33MHz PCI Bus speed.

DRAM Memory

−Provides three DIMM module sockets.

−Supports 3.3V unbuffered 168pin Synchronous DRAM modules.

−Supports a maximum memory size of 512 MB with SDRAM.

−100/133MHz Bus frequency.

−Supports up to 3 double sided DIMMs at 100 MHz system memory

bus.

−Supports up to 2 double sided or 3 single sided DIMMs at 133 MHz

system memory bus.

−No registered DIMM supported.

−No ECC SDRAM supported.

Shadow RAM

−Supports shadowing of system BIOS into RAM for faster performance.

Green PC Power Management Functionality

−BIOS supported power management.

−Power down timer from 1 min to 1 Hour.

Chapter1 Motherboard Description

1-3

−Wakes up by any key pressed or mouse activity.

−Wake On LAN connector.

−S3 (suspend to RAM) support.

BUS Slots

−Provides six PCI Bus slots, one CNR slot (slave only) and one AGP

Bus slot.

Integrated IDE controller

−Supports 4 IDE hard disk drives.

−Supports PIO mode 5, Master Mode high performace hard disk drives.

−Supprots Ultra DMA 33/ 66/ 100 Bus Master Mode.

−Supports IDE interface with CD-ROM.

−Supports high capacity hard disk drives.

−Supports LBA mode.

−Driver detected by BIOS.

Accelerated Graphics Port (AGP)

−Supports AGP 2.0 including 4X AGP data transfers.

−High priority access support.

−Hierarchical PCI configuration mechanism.

−Supports via dual mode buffers to allow AGP 2.0, 3.3V or 1.5V

signaling.

AC’97 Sound Codec Onboard

−AC-LINK protocol compliance.

−AC’97 2.1 compliant.

−Single chip audio CODEC with high S/N ratio (>90 dB)

−18-bit ADC and DAC resolution.

−18-bit stereo full-duplex CODEC with independent and variable

sampling rate.

LPC I/O Built-in Onboard

−LPC Interface.

−PC98, PC99 Compliant.

−Game Port Interface.

Chapter1 Motherboard Description

1-4

−MPU-401 MDI Support.

−Intelligent Auto Power Management.

−2.88MB Super I/O Floppy Disk Controller.

−Floppy Disk Available on Parallel Port Pins.

Supports 360KB, 720KB, 1.2MB, 1.44MB, and 2.88MB floppy

disk drives.

−Enhanced Digital Data Separator.

−Serial Ports.

Two full Function Serial Ports.

Supports 230K and 460K Baud Programmable Baud Rate

Generator Modem Control Circuitry.

−Infrared Port.

−Multi-Mode™ Parallel Port with ChipProtect™.

HPT370 is designed to enable you add high performance

ATA/ATAPI devices. (Optional)

−Ultra DMA 100MB/S operation per ATA channel.

−Support up to 66MHz PCI bus Clock.

−One PCI function supports two independent ATA channels.

−Dedicated ATA Bus.

−ATA clock independent from PCI bus.

−Optional between external 50Hz ATA bus clock or internal PLL.

−256Byte FIFO per ATA channel.

−Large FIFO independent.

−Easy Plug-and-Play feature.

−Supports up to 4 IDE devices. (Coexist with on-board IDE)

−Supports Hard Drive with capacity larger than 30GB.

−RAID function supported (RAID 0,1,0+1).

−Supports the most popular Windows 95/98,Windows NT4.0, Windows

2000, Windows ME and Linux.

−Supports booting function with Flash Memory interface.

−Automatically fine tunes to the best performance for each IDE/ATAPI

device.

−Concurrent PIO and bus master access(ATA port accessible during

DMA transfer)

Inhaltsverzeichnis

Andere Biostar Hauptplatine Handbücher

Biostar

Biostar A740GM2 Benutzerhandbuch

Biostar

Biostar J3710NH Benutzerhandbuch

Biostar

Biostar M7VIW-D Bedienungsanleitung

Biostar

Biostar M6TZA Bedienungsanleitung

Biostar

Biostar B350GT3 Bedienungsanleitung

Biostar

Biostar M7VIG Pro D Benutzerhandbuch

Biostar

Biostar Hi-Fi B150Z3 Bedienungsanleitung

Biostar

Biostar M7 VIK Bedienungsanleitung

Biostar

Biostar TA790GXB A2 PLUS - BIOS Bedienungsanleitung

Biostar

Biostar M7 VIK Benutzerhandbuch

Biostar

Biostar TF570 Benutzerhandbuch

Biostar

Biostar B550M-SILVER Bedienungsanleitung

Biostar

Biostar M7MKE Anleitungen und Rezepte

Biostar

Biostar H510MHP 2.0 Bedienungsanleitung

Biostar

Biostar TB85-BTC Bedienungsanleitung

Biostar

Biostar P4 SFA Bedienungsanleitung

Biostar

Biostar B560MH-E 2.0 Bedienungsanleitung

Biostar

Biostar PT890 775 SE Benutzerhandbuch

Biostar

Biostar NF500-A2G Benutzerhandbuch

Biostar

Biostar IDEQ 200T Benutzerhandbuch

Biostar

Biostar M7 VIQ Bedienungsanleitung

Biostar

Biostar M7MIA Bedienungsanleitung

Biostar

Biostar B660GTN Bedienungsanleitung

Biostar

Biostar PT890 775 SE Benutzerhandbuch

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
