English

M7VIK Features

 Use VIA KT400 / VT8235 Chipset, Winbond W83697HF.

 Contains on board I/O facilities, which include two serial ports, a parallel

port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports, a

game port.

 Supports Single Socket-A for an AMD Athlon/ Duron Family processor,

running at 200/266/333 MHz Front Side Bus frequency.

 The AMD Athlon/ Duron system bus supports the 200/266/333 MHz

high-speed, split-transaction AMD Athlon/ Duron system bus interface.

 Supports Ultra DMA 33/66/100/133 Bus Master Modes, PIO Mode 4,

Master Mode, and high performance hard disk drives.

 Supports USB2.0 High Speed Device.

 The KT400 system controller is designed to support 200/266/333/400 MHz

DDR SDRAM DIMMs.

 Supports one CNR Slot (Type B only), one AGP 8X Slot, and five 32-bit

PCI Bus slots.

 Complies with PC ATX form factor specifications.

 Supports popular operating systems such as Windows NT, Windows 98SE,

Windows 2000, Windows ME, Windows XP and LINUX.

 DIMM Power Selection by BIOS setup to adjust DDR DIMM voltage. (If you

meet the DDR DIMM compatible program, try to adjust the DDR Voltage to

fix the compatible program.) (Optional)

 CPU over temperature protection.

 Intel® AC’97 2.2 compatible. High S/N ratio meets PC 99 requirements.

 Line-in phonejack and Mic-in jack share with rear Audio out for 6 channels

Audio.

 6-Channel Hardware Audio. (Change Line-In to Back-Audio Out and Mic-In

to Bass/ Center Out by Audio Utility.) (Optional)

 IEEE1394 ports (Optional).

 Serial-ATA Connector (Optional).

Package contents

 HDD Cable X 1, FDD Cable X 1, Fully Setup Driver CD X 1

 Flash Memory Writer for BIOS update X 1

 USB Cable X 2 (Optional)

 Rear I/O Panel for ATX Case X 1 (Optional)

 IEEE1394 Cable X1 (Optional)

 Serial ATA Cable X1 (Optional)

Layout of M7VIK

PCI1

CNR1

FDD1

JPANEL1

BAT1

JATXPWR1

AGP SLOT

CNR SLOT

DIMM1

DIMM2

DIMM3

CPU

Socket A

CPU1

JSFAN1

2324

JCMOS1

VT8235

PCI2

PCISLOT

PCI3

PCI4

PCI5

PCISLOT

JPRNT1

JKBV1 JUSBV1

JUSBV2

CMI8738

JUSB3

JGAME1

JCOM2

JCOM1

Sp-Out

Line-InMic-In

Game Port

KT400

JCDIN1

JWOL1

10 1

RAID1

IDE1 IDE2

10 1

JUSB2

JUSBV3

JSATA2JSATA1

Serials

ATA

Controller

1394

CHIP

BIOS

JAUDIO1

Winbond I/O

CPU Installation

1. Pull the lever sideways away from the socket then raise the lever up

to 90-degree angle.

2. Locate Pin A in the socket and lock for the white dot or cut edge in

the CPU. Match Pin A with the white dot/cut edge then insert the

CPU.

3. Press the lever down. Then Put the fan on the CPU and buckle it

and put the fan’s power port into the JCFAN1, then to complete the

installation.

CPU/ System Fan Headers: JCFAN1/ JSFAN1

CPU

DDR DIMM Modules: DIMM1-2-3

DRAM Access Time: 2.5V Unbuffered/ Registered DDR 1600/ 2100/

2700/ 3200 Type required.

DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184

pin)

Only support 4 bank for DDR PC3200 (2pcs Double-Side or 3

pcs Single-Side).

DIMM Socket

Location DDR Module Total Memory

Size (MB)

DIMM 1 64MB/128MB/256MB/512MB/1GB

DIMM 2 64MB/128MB/256MB/512MB/1GB

DIMM3 64MB/128MB/256MB/512MB/1GB

Max is

3GB

* The list shown above for DRAM configuration is only for reference.

 If use FSB333MHz CPU, the Memory support only

DDR333 (PC2700).

List of the status of DDR 400 already passed

Clock Vender Serial No. (Chip) Module

Size MEMTEST

1 DDR400 KINGMAX KDL684T4AA-50 256M Pass

2 DDR400 SAMSUNG K4H560838D-TCC4 256M Pass

3 DDR400 TwinMOS TMD7608F8E50B 256M Pass

4 DDR400 Winbond W942508BH-5 256M Pass

5 DDR400 Winbond W942508BH-5 512M Pass

How to install a DIMM Module

1. The DIMM socket has a

“ Plastic Safety Tab”, and the

DIMM memory module has an

“Asymmetrical notch”, so the

DIMM memory module can only

fit into the slot in one direction.

2. Push the tabs out. Insert the

DIMM memory modules into the

socket at a 90-degree angle, then

push down vertically so that it will

fit into the place.

3. The Mounting Holes and plastic

tabs should fit over the edge and

hold the DIMM memory modules

in place.

Jumpers, Headers, Connectors & Slots

Hard Disk Connectors: IDE1/ IDE2

The motherboard has a 32-bit Enhanced PCI IDE Controller that

provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100/ 133

functionality. It has two HDD connectors IDE1 (primary), IDE2

(secondary) and IDE3.

The IDE connectors can connect a master and a slave drive, so you can

connect up to four hard disk drives. The first hard drive should always be

connected to IDE1.

Serial ATA Connector: (JSATA1/ JSATA2) (Optional)

The motherboard has a PCI to SATA Controller with 2 channels STAT

interface, it satisfies the SATA 1.0 spec and can transfer data with

1.5GHz speed.

Raid Connector: RAID1

This connector supports RAID 1 cofiguration through the onboard Serial

ATA controller chip. You can use the IDE feature to set up a disk array

cofiguration and to support additional IDE devices. However, it can

only support master mode IDE HDD.

Floppy Disk Connector: FDD1

The motherboard provides a standard floppy disk connector that

supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This

connector supports the provided floppy drive ribbon cables.

Accelerated Graphics Port Slot: AGP1 (only support AGP

power 1.5V)

Your monitor will attach directly to that video card. This motherboard

supports video cards for PCI slots, but it is also equipped with an

Accelerated Graphics Port (AGP). An AGP card will take advantage of

AGP technology for improved video efficiency and performance,

especially with 3D graphics.

Communication Network Riser Slot: CNR1

The CNR specification is an open Industry Standard Architecture, and it

defines a hardware scalable riser card interface, which supports audio,

network and modem only.

Peripheral Component Interconnect Slots: PCI1-5

This motherboard is equipped with 5 standard PCI slots. PCI stands for

Peripheral Component Interconnect, and it is a bus standard for

expansion cards, which has, supplanted the older ISA bus standard in

most ports. This PCI slot is designated as 32 bits.

Power Connectors: JATXPWR1

Wake On LAN Header: WOL1

Front USB Header: JUSB2/3

JATXPWR1

(ATX Main Power Conn.)

JATXPWR1

(ATX Power Conn.)

WOL1

5V_SBWake up

Ground

JUSB2/3

Pin1,2 ==> +5V

Pin3,4 ==> Data(-)

Pin5,6 ==> Data(+)

Pin7,8 ==> Ground

Pin9 ==> KEY

Pin10 ==> NA

5V/ 5VSB Selection for USB/KB: JUSBV1/2/3/ JKBV1

Front 1394 Header: J1394A1/J1394B1/J1394C1

Front Panel Connector: JPANEL1

SPK

PWR_LED

HLED

SLP

RST

224

123

IRON/OFF

SPK ==> Speaker Conn.

HLED ==> Hard Driver LED

RST ==> Reset Button

IR ==> Infrared Conn.

SLP ==> Sleep Button

PWR_LED ==> Power LED

ON/ OFF ==> Power-on Button

(+) (-)

(+) (-)(+)

JKBV1

Pin 1-2 on ==> 5V

Pin 2-3 on ==> 5V_SB

JUSBV1/2/3

JUSB3/4

Pin1,2 ==> +5V

Pin3,4 ==> Dato(-)

Pin5,6 ==> Dato(+)

Pin7,8 ==> Tierra

Pin9 ==> KEY

Pin10 ==> NA

J1394A1/B1/C1

1Pin1,2 ==> A+/A-

Pin3,4 ==> Ground

Pin5,6 ==> B+/ B-

Pin7,8 ==> +12V

Pin9 ==> KEY

Pin10 ==> NA

Andere Handbücher für M7 VIK

Inhaltsverzeichnis

Andere Biostar Hauptplatine Handbücher

Biostar

Biostar A690E-IS Benutzerhandbuch

Biostar

Biostar TH61A Bedienungsanleitung

Biostar

Biostar BI94GS-IA Benutzerhandbuch

Biostar

Biostar 945P-A7A Firmware-Update

Biostar

Biostar H110MHV3 Bedienungsanleitung

Biostar

Biostar TZ68K Bedienungsanleitung

Biostar

Biostar NF520-A2 TE - BIOS SETUP Bedienungsanleitung

Biostar

Biostar TA780G M2 Benutzerhandbuch

Biostar

Biostar B250MDC Bedienungsanleitung

Biostar

Biostar NF61S MICRO AM2 SE Benutzerhandbuch

Biostar

Biostar G41U3G Benutzerhandbuch

Biostar

Biostar P31B-A7 - BIOS Bedienungsanleitung

Biostar

Biostar TP43 HP - BIOS Bedienungsanleitung

Biostar

Biostar M6VLA Bedienungsanleitung

Biostar

Biostar M7 VKQ Bedienungsanleitung

Biostar

Biostar TA785GE - SETUP Benutzerhandbuch

Biostar

Biostar Hi-Fi A68U3P Benutzerhandbuch

Biostar

Biostar P4M900-M7 FE Benutzerhandbuch

Biostar

Biostar 945PL-M7 Benutzerhandbuch

Biostar

Biostar M6TSM Bedienungsanleitung

Biostar

Biostar I915G-M7 Bedienungsanleitung

Biostar

Biostar Hi-Fi Z87W 3D Bedienungsanleitung

Biostar

Biostar NF61S-M2 TE Benutzerhandbuch

Biostar

Biostar NF61S-M2 TE Benutzerhandbuch

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
