TP45E Combo/TP43E Combo Setup Manual

FCC Information and Copyright

This equipment has been tested and found to comply with the limits of a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. There is no guarantee

that interference will not occur in a particular installation.

The vendor makes no representations or warranties with respect to the

contents here and specially disclaims any implied warranties of merchantability

or fitness for any purpose. Further the vendor reserves the right to revise this

publication and to make changes to the contents here without obligation to

notify any party beforehand.

Duplication of this publication, in part or in whole, is not allowed without first

obtaining the vendor’s approval in writing.

The content of this user’s manual is subject to be changed without notice and

we will not be responsible for any mistakes found in this user’s manual. All the

brand and product names are trademarks of their respective companies.

Table of Contents

Chapter 1: Introduction ........................................ 1

1.1 Before You Start......................................................................................... 1

1.2 Package Checklist ..................................................................................... 1

1.3 Motherboard Features.............................................................................. 2

1.4 Rear Panel Connectors.............................................................................. 3

1.5 Motherboard Layout................................................................................. 4

Chapter 2: Hardware Installation .......................... 5

2.1 Installing Central Processing Unit (CPU) ............................................... 5

2.2 FAN Headers .............................................................................................. 7

2.3 Installing System Memory ........................................................................ 8

2.4 Connectors and Slots................................................................................ 10

Chapter 3: Headers & Jumpers Setup .................. 14

3.1 How to Setup Jumpers............................................................................. 14

3.2 Detail Settings.......................................................................................... 14

Chapter 4: T-Series BIOS & Software................... 19

4.1 T-Series BIOS............................................................................................. 19

4.2 T-Series Software...................................................................................... 27

Chapter 5: Useful Help ........................................ 36

5.1 Driver Installation Note.......................................................................... 36

5.2 Extra Information.................................................................................... 37

5.3 AMI BIOS Beep Code............................................................................... 38

5.4 Troubleshooting....................................................................................... 39

Appendix: SPEC In Other Languages ................... 40

German.................................................................................................................. 40

French .................................................................................................................... 42

Italian..................................................................................................................... 44

Spanish ................................................................................................................... 46

Portuguese ............................................................................................................ 48

Polish...................................................................................................................... 50

Russian ................................................................................................................... 52

Arabic..................................................................................................................... 54

Japanese ................................................................................................................ 56

TP45E Combo/TP43E Combo

CHAPTER 1: INTRODUCTION

1.1 BEFORE YOU START

Thank you for choosing our product. Before you start installing the

motherboard, please make sure you follow the instructions below:

Prepare a dry and stable working environment with

sufficient lighting.

Always disconnect the computer from power outlet

before operation.

Before you take the motherboard out from anti-static

bag, ground yourself properly by touching any safely

grounded appliance, or use grounded wrist strap to

remove the static charge.

Avoid touching the components on motherboard or the

rear side of the board unless necessary. Hold the board

on the edge, do not try to bend or flex the board.

Do not leave any unfastened small parts inside the

case after installation. Loose parts will cause short

circuits which may damage the equipment.

Keep the computer from dangerous area, such as heat

source, humid air and water.

The operating temperatures of the computer should be

0 to 45 degrees Celsius.

1.2 PACKAGE CHECKLIST

HDD Cable X 1 (optional)

Serial ATA Cable X 3

Rear I/O Panel for ATX Case X 1

User’s Manual X 1

Fully Setup Driver CD X 1

FDD Cable X 1 (optional)

USB 2.0 Cable X1 (optional)

Serial ATA Power Cable X 1 (optional)

Note: The package contents may be different due to area or your motherboard version.

Motherboard Manual

1.3 MOTHERBOARD FEATURES

TP45E Com bo TP43E Com bo

CPU

LGA 775

Intel Core2 Extreme / Core2 Duo / Core2 Quad /

Pent iu m Dua l-Co re / C e leron Du a l-Core /

Celeron 4xx processor

Supports Execute D isab le Bit / Enhanced Intel

SpeedStep® / Intel Architecture-64 / Extended

Memory 64 Technology / Virtualization

Technology

LGA 775

Intel Core2 Extreme / Core2 Duo / Core2 Quad /

Pent iu m Dua l-Co re / C e leron Du a l-Core /

Celeron 4xx processor

Supports Execute D isab le Bit / Enhanced Intel

SpeedStep® / Intel Architecture-64 / Extended

Memory 64 Technology / Virtualization

Technology

FSB Support 800 / 1066 / 1333 / 1600 MHz Support 800 / 1066 / 1333 / 1600 MHz

Chipset Intel P45

Int el ICH1 0

Intel P43

Int el ICH1 0

Super I/O

ITE 8718F

Provides the most commonly used legacy Super

I/O functionality.

Low Pin Count Interface

Env ironment Co ntrol in it iatives ,

Hardware Monitor Controller

Fan Speed Controller

ITE's "Smart Guardian" funct ion

ITE 8718F

Provides the most commonly used legacy Super

I/O functionality.

Low Pin Count Interface

Env ironment Co ntrol in it iatives ,

Hardware Monitor Controller

Fan Speed Controller

ITE's "Smart Guardian" funct ion

Main

Memory

DDR3 x 2, each DIMM supports 256MB / 512MB

/ 1GB / 2GB

DDR2 x 2, each DIMM supports 256MB / 512MB

/ 1GB / 2GB / 4GB

DDR3 Max Memory Capacity 4GB

DDR2 Max Memory Capacity 8GB

Dual Channel Mode DDR2 & DDR3 memory

modu le

Supports DDR2 1066 / 800 / 667

Supports DDR3 1333 / 1066 / 800

Registered DIMM and ECC D IMM is not

supported

DDR3 x 2, each DIMM supports 256MB / 512MB

/ 1GB / 2GB

DDR2 x 2, each DIMM supports 256MB / 512MB

/ 1GB / 2GB / 4GB

DDR3 Max Memory Capacity 4GB

DDR2 Max Memory Capacity 8GB

Dual Channel Mode DDR2 & DDR3 memory

modu le

Supports DDR2 1066 / 800 / 667

Supports DDR3 1333 / 1066 / 800

Registered DIMM and ECC D IMM is not

supported

IDE

JMicro JMB368

Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode

supports PIO Mode 0~4

JMicro JMB368

Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode

supports PIO Mode 0~4

SATA 2

Integrated Serial ATA Controller

Data transfer rates up to 3.0 Gb/s.

SATA Version 2.0 specif icat ion co mp liant

Integrated Serial ATA Controller

Data transfer rates up to 3.0 Gb/s.

SATA Version 2.0 specif icat ion co mp liant

LAN

Realtek RTL 8111C / 8111D / 8111DL

10 / 100 Mb/s / 1Gb/s auto negotiation

Half / Full duplex capability

Realtek RTL8111C / 8111D / 8111DL

10 / 100 Mb/s / 1Gb/s auto negotiation

Half / Full duplex capability

TP45E Combo/TP43E Combo

TP45E Com bo TP43E Com bo

Sound

Codec

ALC662

5.1 channels audio out

High Definition Audio

ALC662

5.1 channels audio out

High Definition Audio

PCI slot x3 PCI slot x3

PCI Express Gen2 x 16 slot x1 PCI Express Gen2 x 16 slot x1

Slots

PCI Express x 1 slot x2 PCI Express x 1 slot x2

Floppy connector x1 Floppy connector x1

IDE Conn ect or x 1 IDE Co nn ect or x 1

SATA Connector x6 SATA Connector x6

Front Panel Connector x1 Front Panel Connector x1

Front Audio Connector x1 Front Audio Connector x1

CD-in Connector x1 CD-in Connector x1

S/PDIF out Connector x1 S/PDIF out Connector x1

CPU Fan header x1 CPU Fan header x1

System Fan header x2 System Fan header x2

Clear CMOS header x1 Clear CMOS header x1

USB connector x2 USB connector x2

Power Connector (24pin) x1 Power Connector (24pin) x1

On Board

Connector

Power Connector (4pin) x2 Power Connector (4pin) x2

Back Panel

I/O

PS/2 Keyboard x1

PS/2 Mouse x1

LAN port x1

USB Port x6

Audio Jack x3

PS/2 Keyboard x1

PS/2 Mouse x1

LAN port x1

USB Port x6

Audio Jack x3

Board Size 220 (W) x 305 (L) mm 220 (W) x 305 (L) mm

OS Support

Windows 2000 / XP / Vista / 7

Biostar Reserves the right to add or remove

support for any OS with or without notice

Windows 2000 / XP / Vista / 7

Biostar Reserves the right to add or remove

support for any OS with or without notice

1.4 REAR PANEL CONNECTORS

PS/2

Mouse

PS/2

Keyboard

USBX2USBX2

LAN

Line In/

Surround

Line Out

Mic In 1/

Bass/ Cent er

USBX2

Motherboard Manual

1.5 MOTHERBOARD LAYOUT

KB M S1

USB1

USB2

RJ45USB1

AUDIO1

CD_I N1

SP D I F 1

F_AUDIO1

LA N

CODEC

Super

I/O

FDD1

PCI1

PCI2

PCI3

PEX16_1

PEX1_2

PEX1_1

AUXPWR1

NB_FAN1

CPU_FAN1

JUSBV1

ATXPWR2

JUSBV2 F_USB2 F_USB1

LED1

LED2

JPANEL1

SW_RST1

SW_PWR1

IDE1

ATXPWR1

JCMOS1

SYS_FAN1

SATA1SATA2

SATA3SATA4

SATA5

SATA6

DDR 3_ A1

DDR3_A2

DDR 2_ B1

DDR2_B2

BIOS

IDE

BAT1

LGA775

CPU1

Intel

P45/P43

Intel

ICH10

PH 1 PH2

PH4

PH 3

Note: represents the 1■st pin.

TP45E Combo/TP43E Combo

CHAPTER 2: HARDWARE INSTALLATION

2.1 INSTALLING CENTRAL PROCESSING UNIT (CPU)

Special Notice:

Remove Pin Cap before installation, and make good preservation

for future use. When the CPU is removed, cover the Pin Cap on the

empty socket to ensure pin legs won’t be damaged.

Pin Cap

Step 1: Pull the socket locking lever out from the socket and then raise

the lever up to a 90-degree angle.

Motherboard Manual

Step 2: Look for the triangular cut edge on socket, and the golden dot on

CPU should point forwards this triangular cut edge. The CPU will

fit only in the correct orientation.

Step 2-1:

Step 2-2:

Step 3: Hold the CPU down firmly, and then lower the lever to locked

position to complete the installation.

Step 4: Put the CPU Fan and heatsink assembly on the CPU and buckle it

on the retention frame. Connect the CPU FAN power cable into

the CPU_FAN1. This completes the installation.

TP45E Combo/TP43E Combo

2.2 FAN HEADERS

These fan headers support cooling-fans built in the computer. The fan

cable and connector may be different due to the fan manufacturer.

Connect the fan cable to the connector while matching the black wire to

pin#1.

CPU_FAN1: CPU Fan Header

Assignment

1 Ground

2 +12V

3 FAN R PM rate

sense

4 Smart Fan

Control

NB_FAN1/SYS_FAN1: System Fan Headers

Assignment

1 Ground

2 +12V

JSFAN1

JNFAN1

3 FAN RPM rate

sense

Note:

The NB_FAN1/SYS_FAN1 support 3-pin head connectors; the CPU_FAN1 supports

4-pin head connector. When connecting with wires onto connectors, please note that the

red wire is the positive and should be connected to pin#2, and the black wire is Ground

and should be connected to GND.

Motherboard Manual

2.3 INSTALLING SYSTEM MEMORY

A. Memory Modules

DDR3_A1

DDR3_A2

DDR2_B1

DDR2_B2

1. Unlock a DIMM slot by pressing the retaining clips outward. Align a

DIMM on the slot such that the notch on the DIMM matches the

break on the Slot.

2. Insert the DIMM vertically and firmly into the slot until the retaining

chip snap back in place and the DIMM is properly seated.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Biostar Hauptplatine Handbücher

Biostar

Biostar TA785-A3 - BIOS Benutzerhandbuch

Biostar

Biostar NF325-A7 Bedienungsanleitung

Biostar

Biostar B550MH 3.0 Bedienungsanleitung

Biostar

Biostar H61MGV3 Bedienungsanleitung

Biostar

Biostar A85W 3D Bedienungsanleitung

Biostar

Biostar 945GC-M7 TE Benutzerhandbuch

Biostar

Biostar M6VCF Bedienungsanleitung

Biostar

Biostar P4TSG PRO Bedienungs- und Montageanleitung

Biostar

Biostar TZ590-BTC DUO Bedienungsanleitung

Biostar

Biostar P4 TDQ Bedienungs- und Montageanleitung

Biostar

Biostar P4TSG PRO Bedienungsanleitung

Biostar

Biostar TH55 HD - BIOS Bedienungsanleitung

Biostar

Biostar 915GV-M7 Bedienungsanleitung

Biostar

Biostar VIOTECH 3100 PLUS - BIOS Benutzerhandbuch

Biostar

Biostar B350GT5 Bedienungsanleitung

Biostar

Biostar M7TDF Bedienungsanleitung

Biostar

Biostar TP45EXE Bedienungsanleitung

Biostar

Biostar M6VLA Bedienungsanleitung

Biostar

Biostar H110MHV3 Bedienungsanleitung

Biostar

Biostar Hi-Fi Z77X Bedienungsanleitung

Biostar

Biostar A320MH 2.0 Bedienungsanleitung

Biostar

Biostar TFORCE 6100 Bedienungsanleitung

Biostar

Biostar K8NBP Bedienungsanleitung

Biostar

Biostar A690G-M2 Benutzerhandbuch

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
